Installing the GC

This section contains installation procedures for the Agilent

Intuvo 9000 GC. Some of the steps in this procedure are

optional based on your installed components, such as plumbing

cryogenic cooling or valve actuator air.

Instructions for connecting cables from the GC to other

instruments in a typical Intuvo 9000 system are included here

and in Appendix B, “Cable Diagrams."

8Agilent Intuvo 9000 GC Installation

1Installing the GC

Overview of Installation

Before installing the GC, read the important safety information

in the Agilent Intuvo 9000 Gas Chromatograph Safety

Information manual (provided with the GC) and the Safety

manual (available from the Agilent GC and GC/MS User

Manuals & Tools DVDs).

Purpose of this procedure

This procedure ensures that instruments and systems are

installed and functioning as designed. Correct installation is the

first step in ensuring that instruments and systems operate

reliably over their lifetimes.

Customer responsibilities

1Make sure your site meets the basic requirements, including

the necessary space, electrical outlets, gases, tubing,

operating supplies, consumables and other usage-dependent

items required for a successful installation. Refer to the

Agilent Intuvo 9000 GC, GC/MS, and ALS Site Preparation

Guide.

2If Agilent is delivering installation and familiarization

services, users of the instrument should be present

throughout these services; otherwise, these users will miss

important operational, maintenance, and safety information.

Additional information is available via the GC Touchscreen,

Browser Interface help & information suite, and the Agilent GC

and GC/MS User Manuals & Tools DVDs and through the

instrument’s website.

Once the GC is turned on, open a browser and connect to the

instrument's help and information system.

If your site complies with all site preparation specifications, the

average installation time for the GC is about 2 hours. Allow

more time for any additional products (for example, an ALS),

add-ons, and software.

About Agilent’s installation service

The installation service does not include:

•Network setup with other computers or to the site or

building LAN.

Installing the GC 1

Agilent Intuvo 9000 GC Installation 9

•Customization of the system.

•Method development and testing.

•Analysis of customer standards or samples.

•Testing against the instrument performance specification.

(Operational qualification and performance verification

services, OQ/PV, can be purchased separately.)

If you need assistance beyond this installation service, please

contact your local Agilent Technologies office. Assistance with

installation and with user-specific services and applications is

available and will be contracted separately.

Tools and additional parts required

Installation requires the following tools, fittings, and hardware.

These items are not included with the instrument.

•Precleaned copper tubing, 1/8-inch or 1/4-inch od.

•Fittings.

•Tubing cutter.

•Filters for gas supplies.

•7/16-inch and 9/16-inch open-end wrenches for assembling

Swagelok fittings.

•Carrier and other gas supplies.

•Pressure regulator for each gas supply.

•A computer, tablet, or other LAN-capable device (for

accessing GC user information and for firmware updates).

•Any additional LAN components, such as cables and a switch

or hub, for connection to the site LAN (not included in

Agilent installation services).

The Agilent Intuvo 9000 GC, GC/MS, and ALS Site Preparation

Guide contains a listing of Agilent installation kits and a

description of parts included with each. These kits contain

filters, fittings, tubing, tools (wrenches, tubing cutter, drivers,

and so on), and other required parts for installing a GC.)

Performing checkout

If using an Agilent data system, you can use it to perform the

checkout procedure. Read these GC installation instructions

and the instructions for installing the data system.

10 Agilent Intuvo 9000 GC Installation

1Installing the GC

System installation

If installing an ALS, the ALS can be used for checkout. Also

refer to the ALS installation documentation.

When installed as part of a complete system including an

Agilent data system, first install the GC up to the checkout step.

Configure the new GC in the data system and open an online

instrument session. Use the data system to perform the

checkout test.

When installed as part of other complete systems, for example

in an Agilent GC/MSD or GC/MS system, see the installation

instructions for that system.

Ship kit contents

Several ship kits will arrive with the GC. Most parts needed for

installation will be found in the 9000 GC System Ship Kit. Ship

kits for the ordered inlet and detector will include the inlet- and

detector-specific parts needed for checkout and maintenance,

for example, the inlet checkout liner, inlet wrench, septa,

detector checkout sample, and typical cleaning tools (varies by

inlet and detector type).

Syringe and plunger button, for manual injection

1/8-in Nut and ferrule set, brass, 10/pk

Certified vial sample pack

LAN cable

Intuvo Torque Driver handle and extension

Torx keys, T10 and T20

Gas line ID labels

Agilent Intuvo 9000 Gas Chromatograph Safety Information manual

MSD Cover insert assembly

Intuvo inlet chip, G4581-60031

Bus front door assembly, G4581-60207

Compression bolts (2), G4581-60260

Intuvo gaskets, polyimide, 2/pk

Indice

Altri manuali Agilent Technologies Attrezzature da laboratorio

Agilent Technologies

Agilent Technologies 850-DS Manuale utente

Agilent Technologies

Agilent Technologies 5975 MSD Manuale utente

Agilent Technologies

Agilent Technologies Graphite Tube Atomizer GTA 120 Manuale utente

Agilent Technologies

Agilent Technologies 990 Micro GC Guida utente

Agilent Technologies

Agilent Technologies Cary 630 FTIR Manuale utente

Agilent Technologies

Agilent Technologies Medalist i1000 Manuale utente

Agilent Technologies

Agilent Technologies E7473A Manuale utente

Agilent Technologies

Agilent Technologies 7010 Series Manuale utente

Agilent Technologies

Agilent Technologies InfinityLab LC Companion Manuale di istruzioni

Agilent Technologies

Agilent Technologies 5975T LTM GC Manuale utente

Agilent Technologies

Agilent Technologies Bravo Platform Manuale utente

Agilent Technologies

Agilent Technologies SPS 4 Manuale utente

Agilent Technologies

Agilent Technologies 1290 infinity Manuale utente

Agilent Technologies

Agilent Technologies 5DX 5000 Series Manuale utente

Agilent Technologies

Agilent Technologies 4100 Istruzioni operative

Agilent Technologies

Agilent Technologies 7820A GC Istruzioni operative

Agilent Technologies

Agilent Technologies 75000 Series C Manuale utente

Agilent Technologies

Agilent Technologies 8860 Manuale utente

Agilent Technologies

Agilent Technologies InfinityLab LC Series Manuale utente

Agilent Technologies

Agilent Technologies MX3000P Guida di sicurezza

Agilent Technologies

Agilent Technologies VGA 77 Manuale utente

Agilent Technologies

Agilent Technologies OmnoBER 725 Manuale utente

Agilent Technologies

Agilent Technologies Varian 325-MS LC/MS Manuale utente

Agilent Technologies

Agilent Technologies 5975 MSD Manuale utente

Manuali Attrezzature da laboratorio popolari di altre marche

Qiagen

Qiagen DML 3000 Manuale utente

Queensgate

Queensgate NANOSCAN OP400 Manuale di programmazione

Conviron

Conviron GEN1000-GE Manuale utente

Parr Instrument

Parr Instrument 4560 Manuale di istruzioni

IKA

IKA IC control Manuale utente

Integra

Integra DOSE IT Manuale utente

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manuale utente

NI PXI-5422 Manuale

Collomix

Collomix Aqix Manuale utente

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manuale utente

Ocean Insight

Ocean Insight FLAME-NIR+ Manuale utente

Parker

Parker ALIGN-MG-NA Manuale utente

BD 644787 Manuale utente

DENTAURUM

DENTAURUM Compact Megaplus Manuale utente

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manuale utente

VWR

VWR SAS Super IAQ Manuale utente

illumina

illumina MiSeqDx Manuale utente

Yamato

Yamato BM510 Manuale utente
