OmniAccess 4504, 4604,
and 4704 WLAN Switch
Installation Guide
www.alcatel-lucent.com
26801 West Agoura Road
Calabasas, CA 91301
OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide 0510353-01 | December 2007
Copyright
© 2007 Alcatel-Lucent. All rights reserved.
Specifications in this manual are subject to change without notice.
Originated in the USA.
Trademarks
AOS-W, Alcatel 4308, Alcatel 4324, Alcatel 6000, Alcatel 41, Alcatel 60/61/65, Alcatel 70, and Alcatel 80 are trademarks of Alcatel-
Lucent in the United States and certain other countries.
Any other trademarks appearing in this manual are the property of their respective companies.
Legal Notice
The use of Alcatel-Lucent switching platforms and software, by all individuals or corporations, to terminate Cisco or Nortel VPN client
devices constitutes complete acceptance of liability by that individual or corporation for this action and indemnifies, in full, Alcatel-
Lucent from any and all legal actions that might be taken against it with respect to infringement of copyright on behalf of Cisco Systems
or Nortel Networks."
OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide Contents | 3
Contents
Preface Guide Overview 5
Related Documents 5
Contacting Alcatel-Lucent 5
Chapter 1 Hardware Overview 7
About the OmniAccess 4504, 4604, and 4704 7
Minimum Software Requirements 8
Package Checklist 8
Hardware Model Overview 8
Front View 9
1000Base-X (SFP) Ports 9
10/100/1000Base-T Gigabit Ethernet Ports 9
Serial Console Port 10
Rear View 11
AC Power Socket 11
LED Status Indicators 11
Chapter 2 Installation 13
Installation 13
Pre-Installation Requirements 13
Physical Installation 13
Rack Mounting 13
Tabletop Deployment 15
Initial Setup and Network Connectivity 15
Removal 15
Appendix A Specifications, Safety & Compliance 17
Physical Specifications 17
Power Management Specifications 17
Power Consumption 17
Power Specifications (AC Input Requirements) 17
Operating Specifications 17
Storage Specifications 18
Safety and Regulatory Compliance 18
FCC Class A Device 18
Proper Disposal of Alcatel-Lucent Equipment 18
Waste of Electrical and Electronic Equipment 18
European Union RoHS 19
China RoHS 19
4|Contents OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide
OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide Preface | 5
Preface
This preface includes the following information:
zAn overview of the contents of this manual
zA list of related documentation for further reading
zAlcatel-Lucent support and service information
Guide Overview
zChapter 1, “Hardware Overview” on page 7 provides a detailed hardware overview of the three
OmniAccess WLAN Switches covered in this guide: the OAW-4504, the OAW-4604, and the OAW-
4704.
zChapter 2, “Installation” on page 13 provides rack mounting and installation instructions.
zAppendix A, “Specifications, Safety & Compliance” on page 17 includes product technical
specifications and safety and regulatory compliance information.
Related Documents
The following documents are referred to in this guide and are considered components of the complete
documentation set needed for successful installation and management of an OmniAccess WLAN
Switch:
z
AOS-W Quick Start Guide
z
AOS-W User Guide
z
OmniVista Mobility Manager User Guide
Contacting Alcatel-Lucent
Web Site Support
Main Site http://www.alcatel-lucent.com/wps/portal/enterprise
Support Site https://service.esd.alcatel-lucent.com
Support Email support@ind.alcatel.com
Telephone Support
North America 1-800-995-2696
Latin America 1-877-919-9526
Europe +33 (0) 38 855 6929
Asia Pacific +65 6240 8484
Worldwide 1-818-878-4507
6| Preface OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide
OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide Hardware Overview | 7
Chapter 1
Hardware Overview
About the OmniAccess 4504, 4604, and 4704
The OmniAccess 4504, 4604, and 4704 are enterprise-class, wireless LAN switches. These switches
connect, control, and intelligently integrate wireless Access Points (APs) and Air Monitors (AMs) into a
wired LAN system.
Available base models:
zOmniAccess 4504 (OAW-4504)
The OAW-4504 is capable of supporting up to 32 campus connected APs. The following base models
are available and can be upgraded by purchasing optional software licenses:
OAW-4504-0: no built-in AP support; optional Alcatel-Lucent AP upgrade licenses available.
OAW-4504-8: includes built-in campus connected AP support of up to 8 APs; additional Alcatel-
Lucent AP upgrade licenses available.
zOmniAccess 4604 (OAW-4604)
The OAW-4604 is capable of supporting up to 64 campus connected APs. The following base models
are available and can be upgraded by purchasing optional software licenses:
OAW-4604-0: no built-in AP support; optional Alcatel-Lucent AP upgrade licenses available.
OAW-4604-32: includes built-in campus connected AP support of up to 32 APs; additional Alcatel-
Lucent AP upgrade licenses available.
zOmniAccess 4704 (OAW-4704)
The OAW-4704 is capable of supporting up to 128 campus connected APs. The following base
models are available and can be upgraded by purchasing optional software licenses:
OAW-4704-0: no built-in AP support; optional Alcatel-Lucent AP upgrade licenses available.
OAW-4704-64: includes built-in campus connected AP support of up to 64 APs; additional Alcatel-
Lucent AP upgrade licenses available.
NOTE
Feature related AP licenses are counted independently and in addition to the Alcatel-Lucent AP
upgrade licenses. Contact your Alcatel-Lucent sales representative for complete details regarding
software licensing options and support capacity.
8| Hardware Overview OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide
Minimum Software Requirements
The OmniAccess 4504, 4604, and 4704 require AOS-W 3.2.0 or later.
AOS-W software builds prior to version 3.2.0 do not support the OmniAccess 4504, 4604, and 4704. If
your network currently runs on a software build prior to 3.2.0, you must upgrade the software on your
master and local switches to 3.2.0 or later prior to installing an OmniAccess 4504, 4604, or 4704 WLAN
Switch in your existing network.
Package Checklist
zOmniAccess 4504, 4604, or 4704 WLAN Switch
zAC Power Cord (country-specific)
zRack Mount Brackets with Hardware (for rack mounting)
zFlat Serial Cable (RJ-45)
zRubber Feet (for table top deployments)
zSerial Console Port Adaptor (RJ-45 to DB9)
zAOS-W Software Documentation CD
z
AOS-W Quick Start Guide
zEnd User License Agreement (EULA)
Hardware Model Overview
NOTE
The master switch, its redundant master switch, and all of its local switches must run on the same
code of AOS-W. Once you upgrade your network and install an OmniAccess 4504, 4604, or 4704
WLAN Switch into your network, verify that the software version on your switch matches the rest of
the network. If the code shipped on the switch is prior to the version that you upgraded your
network to, you must upgrade the code on the switch to match the rest of the network.
NOTE
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the
carton, including the original packing materials. Use these materials to repack and return the unit to
the supplier if needed.
NOTE
Optional accessories, such as SFP modules, are available for use with an OmniAccess 4504, 4604,
or 4704 and are sold separately. Contact your Alcatel-Lucent sales representative for details and
assistance.
NOTE
The physical hardware overview covers all three switches: the OmniAccess 4504, 4604, and 4704 .
The difference between the three switch models is dependent on the licensing level purchased,
which is covered in About the OmniAccess 4504, 4604, and 4704 on page 7. The switch model
depicted in the illustrations throughout this section is the OAW-4504.
OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide Hardware Overview | 9
Front View
Figure 1 OmniAccess 4504, 4604, and 4704 Front View
1000Base-X (SFP) Ports
There are four 1000Base-X combination ports for fiber connectivity only and are intended for use with
Alcatel-Lucent SFPs (mini-GBICs).
To purchase compatible SFP modules, contact your Alcatel-Lucent sales representative for details and
assistance.
10/100/1000Base-T Gigabit Ethernet Ports
There are four 10/100/1000Base-T Gigabit Ethernet (RJ-45) ports. Gigabit Ethernet uses all eight wires
and each pair is used in a bi-directional fashion, meaning the same pairs are used for both data
transmission and reception. Figure 2 illustrates the CAT-5 pin-out found on an RJ-45 connector. The
CAT-5 pin-out pairs the following pins on a 10/100/1000Base-T Gigabit Ethernet port: 1/2, 3/6, 4/5, and 7/
8.
Serial Console Port
10/100/1000-Base-T
Gigabit Ethernet Port
1000Base-X (SFP)
Ports
Dual-media ports (4x); 1000Base-X
or 10/100/1000Base-T
NOTE
Ports zero through three are dual-media ports and can utilize either the 1000Base-X or 10/100/
1000Base-T connections provided. However, the 1000Base-X fiber connection has priority over the
10/100/1000Base-T copper connection. If a link is detected for the 1000Base-X interface, the 10/
100/1000Base-T connection will be disabled.
NOTE
Alcatel-Lucent tests and supports Alcatel-Lucent optics within their switch systems. Third party
optics are not tested or supported; therefore, Alcatel-Lucent does not guarantee proper functionality
of third party optics when used in an Alcatel-Lucent system.
10 | Hardware Overview OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide
Figure 2 Gigabit Ethernet Port Pin-Out
Serial Console Port
A serial console port is provided for connection to a terminal, allowing for direct local management.
The port’s RJ-45 female connector accepts an RS-232 serial cable with a male connector.
Figure 3 Serial Console Port Pin-Out
Communication settings for the serial console port are indicated in Table 1.
Serial Console Port Adaptor
A modular adaptor can be used to convert the RJ-45 (female) connector to a DB9 (male) connector.
Refer to Figure 4 for complete details.
Figure 4 RJ-45 (female) to DB9 (male) Modular Adaptor Conversion
Table 1 Console Terminal Settings
Baud Rate Data Bits Parity Stop Bits Flow Control
9600 8 None 1 None
1000Base-T Gigabit
Ethernet Port
RJ-45 Female
Pin-Out
Signal Name
1
2
3
4
5
6
7
8
BI_DC+
BI_DC-
BI_DD+
BI_DD-
BI_DA+
BI_DA-
BI_DB+
BI_DB-
Function
Bi-directional pair +C
Bi-directional pair -C
Bi-directional pair +D
Bi-directional pair -D
Bi-directional pair +A
Bi-directional pair -A
Bi-directional pair +B
Bi-directional pair -B
Serial
Console Port
1
2
3
4
5
6
7
8
TxD
GND
RxD
RJ-45 Female
Pin-Out
Direction
Input
Output
GND
!
CAUTION
Do not connect an Access Point (AP) to the serial console port. The serial console port is compatible
with only RS-232 devices. Non-RS-232 devices, such as APs, are not supported.
3
4
5
2
5
63
RJ-45 DB-9
Internal
Connections
TxD
GND
RxD
1
2
3
4
5
6
7
8
TxD
GND
RxD
RJ-45 Female
Pin-Out
Direction
Input
Output
DB-9 Male
Pin-Out
TxD
RxD
Ground
5
4
3
2
1
9
8
7
6
Direction
Input
Output
Altri manuali per OmniAccess 4504
1
Questo manuale è adatto per i seguenti modelli
2
Indice
Altri manuali Alcatel-Lucent Interruttore
Alcatel-Lucent
Alcatel-Lucent 1850 TSS-100 Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6900 Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6800 Series Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 9000 Series Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6450-P10S Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent 1671 Service Connect Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6400 Series Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent OmniSwitch AOS Release 7 Manuale utente
Alcatel-Lucent
Alcatel-Lucent 7450 ESS-7 Manuale utente
Alcatel-Lucent
Alcatel-Lucent 1850 TSS-60 Guida utente
Alcatel-Lucent
Alcatel-Lucent 7210 Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6250 Manuale utente
Alcatel-Lucent
Alcatel-Lucent 7210 SAS-T Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6400 Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch AOS Release 6 Manuale utente
Alcatel-Lucent
Alcatel-Lucent OmniSwitch OS6450-10 Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 6250 Manuale di installazione
Alcatel-Lucent
Alcatel-Lucent OmniSwitch 2220 Istruzioni per l'installazione
Alcatel-Lucent
Alcatel-Lucent 7210 SAS E OS Manuale utente
Alcatel-Lucent
Alcatel-Lucent 7210 SAS-D Foglio di istruzioni
