OmniSwitch 6250 Series

Getting Started Guide

060302-10, Rev. A

November 2009

Warning. Only personnel knowledgeable in basic electrical and mechanical procedures should install or maintain this

equipment.

The features and specifications described in this guide are subject to change without notice.

the express written permission of Alcatel-Lucent.

Alcatel-Lucent®and the Alcatel-Lucent logo are registered trademarks of Alcatel-Lucent. Xylan®, OmniSwitch®,

OmniStack®, and Alcatel-Lucent OmniVista®are registered trademarks of Alcatel-Lucent.

OmniAccess™, Omni Switch/Router™, PolicyView™, RouterView™, SwitchManager™, VoiceView™, WebView™,

X-Cell™, X-Vision™, and the Xylan logo are trademarks of Alcatel-Lucent.

This OmniSwitch product contains components which may be covered by one or more of the following U.S. Patents:

• U.S. Patent No. 6,339,830

• U.S. Patent No. 6,070,243

• U.S. Patent No. 6,061,368

• U.S. Patent No. 5,394,402

• U.S. Patent No. 6,047,024

• U.S. Patent No. 6,314,106

• U.S. Patent No. 6,542,507

• U.S. Patent No. 6,874,090

Alcatel-Lucent

26801 West Agoura Road

Calabasas, CA 91301

US Customer Support: (800) 995-2696

Internet: service.esd.alcatel-lucent.com

November 2009 iii

OmniSwitch 6250 Series. . . . . . . . . . . . . . . 1

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Unpacking Instructions . . . . . . . . . . . . . . . . . 3

Items Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Unpacking the Chassis . . . . . . . . . . . . . . . . . . . . . . . 3

Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connections and Cabling . . . . . . . . . . . . . . 5

Connecting the Serial Cable . . . . . . . . . . . . . . . . . . . 5

Serial Connection Default Settings . . . . . . . . . . . . . 5

Booting OmniSwitch 6250 Series

Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Booting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Your First Login Session. . . . . . . . . . . . . . . . 7

Logging in to the Switch . . . . . . . . . . . . . . . . . . . . . 7

Assigning an IP Address to the Switch . . . . . . . . . . 8

Unlocking Session Types . . . . . . . . . . . . . . . . . . . . . 9

Changing the Login Password . . . . . . . . . . . . . . . . 10

Setting the System Time Zone . . . . . . . . . . . . . . . . 11

Setting the Date and Time . . . . . . . . . . . . . . . . . . . 11

Setting Optional System

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Viewing and Saving Changes . . . . . . . . . . . . . . . . . 12

Using WebView. . . . . . . . . . . . . . . . . . . . . . . . . . 13

Browser Compatibility . . . . . . . . . . . . . . . . . . . . . . 13

Logging In to WebView . . . . . . . . . . . . . . . . . . . . . 13

Navigating WebView . . . . . . . . . . . . . . . . . . . . . . . 14

Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Additional Information . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting WebView . . . . . . . . . . . . . . . . . . . 17

Table of Contents

iv November 2009

November 2009 OmniSwitch 6250 Series 1

OmniSwitch 6250 Series

The Alcatel-Lucent OmniSwitch 6250 Series is a family of

fixed configuration, Gigabit Ethernet, stackable LAN switches

with advanced Layer 2 and basic routing capabilities designed

for both the Enterprise and Metro markets.

Refer to the Product Documentation Card for instructions on

downloading additional hardware and software OmniSwitch

documentation.

2 OmniSwitch 6250 Series November 2009

Related Documentation

The following are the titles and descriptions of all the

OmniSwitch 6250 Series user documentation available for

download. Refer to the included Product Documentation Card

for instructions:

•OmniSwitch 6250 Series Getting Started Guide

Describes the hardware and software procedures for

getting an OmniSwitch 6250 Series switch up and

running.

•OmniSwitch 6250 Series Hardware Users Guide

Complete technical specifications and procedures for

all OmniSwitch 6250 Series hardware, including

chassis, power supplies, fans, combo ports, optional

backup power supplies, etc.

•OmniSwitch CLI Reference Guide

Complete reference to all CLI commands supported on

the OmniSwitch 6250 Series. Includes syntax

definitions, default values, examples, usage

guidelines, and CLI-to-MIB variable mappings.

•OmniSwitch 6250 Switch Management Guide

Includes procedures for readying a switch for

integration into a network. Topics include the software

directory architecture, image rollback protections,

authenticated switch access, managing switch files,

system configuration, using SNMP, and using web

management software (WebView).

•OmniSwitch 6250 Network Configuration Guide

Includes network configuration procedures and

descriptive information on all the major software

features and protocols included in the base software

package. Chapters cover Layer 2 information (Ether-

net and VLAN configuration), Layer 3 information

(static routes), security options (authenticated

VLANs), Quality of Service (QoS), and link

aggregation.

•OmniSwitch Transceivers Guide

Includes information on Small Form Factor Pluggable

(SFPs) and 10 Gbps Small Form Factor Pluggables

(XFPs) transceivers.

November 2009 Unpacking Instructions 3

Items Included

Your OmniSwitch 6250 Series switch order may include the

following items:

•OmniSwitch 6250 Series chassis

•Power supply and power supply tray

•Rack mount flanges with attachment screws (rack

mount flanges may be pre-installed on some orders)

•Power cord (country-specific) and power cord bracket

•Product Documentation Card

•DB9 to RJ-45 serial adapter (Uses RJ-45-to-RJ-45

straight-through cable, not included)

Depending on the items ordered for your specific network

requirements, the following optional items may also be

included:

•SFPs (per order)

•Backup power supply components and cables

(per order)

•Additional mounting or securing hardware

Unpacking the Chassis

To protect your OmniSwitch chassis and hardware compo-

nents from electrostatic discharge (ESD) and physical damage,

read all unpacking recommendations and instructions care-

fully before beginning.

Recommendations

•Unpack your OmniSwitch chassis as close as possible

to the location where it will be installed.

•Depending on your order, Small Form-Factor Plugga-

bles (SFPs) and backup power supply components may

be packaged separately. In order to greatly reduce

exposure to electrostatic discharge (ESD) and physical

damage, do not unpack these items until they are ready

to be installed.

Instructions

1Carefully cut the tape along the seam at the top of the

box containing the chassis.

2Lift the box’s top flaps. Remove any smaller boxes or

pouches that are enclosed and set them aside.

3Lift the chassis out of the packaging.

Unpacking Instructions

4 Unpacking Instructions November 2009

4Carefully remove any foam pads and protective plastic

from the switch chassis as in the example diagram.

5Once all OmniSwitch 6250 Series switches have been

removed from their packaging, continue to “Installation

Options.”

Installation Options

Depending on the model, there are three basic ways in which

the OmniSwitch 6250 Series switches can be installed:

•Rack-mount installation

•Tabletop installation

•Wall-Mount Installation (Model depdenent)

Note: For detailed, step-by-step instructions on install-

ing and mounting OmniSwitch 6250 hardware and

power supplies along with environmental and safety

considerations, please refer to the OmniSwitch 6250

Hardware Users Guide.

November 2009 Connections and Cabling 5

Once your switch is properly set up and all the required hard-

ware components are installed, you should connect all network

and management cables required for your network applica-

tions. Connections may include:

•RJ-45 cable connection to the console port

•Single mode or multimode fiber cables to combo port

SFPs as required by your network

•Ethernet cables to 10/100/1000 Ethernet ports as

required by your network

Connecting the Serial Cable

The console port, located on the chassis front panel, provides a

serial connection to the switch and is required when logging

into the switch for the first time. By default, this RJ-45

connector provides a DTE console connection.

1Locate the console port on the front of

the switch.

2Connect one end of an RJ-45-to-RJ-45

straight-through cable to the console port.

3Connect the other end of an RJ-45-to-RJ-45 straight-

through cable to the supplied DB-9 to RJ-45 adapter.

4Connect the adapter to the PC or terminal with the

default settings below.

Serial Connection Default Settings

The default settings for the serial connection are as follows:

Note. For information on modifying these settings, refer to

the OmniSwitch 6250 Series Hardware Users Guide.

Connections and Cabling

baud rate 9600

parity none

data bits (word size) 8

stop bits 1

6 Booting OmniSwitch 6250 Series Switches November 2009

Booting the Switch

The OmniSwitch 6250 Series switch does not use an on/off

switch. The power cord is the switch’s only connect/discon-

nect device. The power connector socket is located on the

chassis rear panel. For more information, refer to the

OmniSwitch 6250 Series Hardware Users Guide.

To boot the switch, plug the power cord (provided) into the

power connector socket or power brick at the switch’s rear

panel. Next, plug the power cord into an easily-accessible

power source, such as a grounded AC outlet or an Uninterrupt-

ible Power Supply (UPS).

The switch immediately begins the boot process. Allow a few

moments for the switch to boot completely, then verify the

status of all LEDs on the switch’s front panel. A successful

boot displays the following LED states:

If the LED states differ from the states shown in the table,

refer to the OmniSwitch 6250 Series Hardware Users Guide

for more information. Contact Alcatel-Lucent Customer

Support if the unexpected LED state persists.

Booting OmniSwitch 6250

Series Switches

LED States

OK Solid green

PWR Solid green

Altri manuali per OmniSwitch 6250

Indice

Altri manuali Alcatel-Lucent Interruttore

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6400 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6450 Series Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6450-P10S Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6855 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-T Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent 1830 PSS-16 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuale utente

Alcatel-Lucent

Alcatel-Lucent SFP Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent 4306G Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6865-P16X Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch AOS Release 7 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuale utente

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-100 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6900 Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6350 Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-R6 OS Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuale di programmazione

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuale utente
