Washer-Extractors

Cabinet Hardmount Operating Instructions

Part No. F232145R6EN

November 2005

This manual is only a

Supplement. Refer to

Installation Manual and

Operation/Maintenance

Manual for full

instructions.

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

means without the expressed written consent of the publisher.

F232145 (EN) 1

Installation/Operation Supplement

Table of

Contents

Safety Information.............................................................................. 3

Important Safety Instructions ............................................................... 3

Specifications and Dimensions........................................................... 5

Gap Setting for Vibration Switch

(Variable-Speed and Fixed-Speed

Models)............................................................................................... 8

Dimensional Clearances ....................................................................... 16

Dimensions ........................................................................................... 17

18, 20, 25, 27, 30, 35, 40, 50, 60 and 80 Models............................. 17

125 Model ........................................................................................ 19

Electrical Specifications ....................................................................... 20

Operation............................................................................................. 25

Instructions for EDC Control................................................................ 27

Instructions for Mechanical Timer ....................................................... 29

Instructions for S, P and V Series Microcomputers ............................. 31

Instructions for B Series Microcomputer ............................................. 33

Instructions for A Series Microcomputer ............................................. 35

2F232145 (EN)

Installation/Operation Supplement

Notes

F232145 (EN)

Installation/Operation Supplement

Safety Information

Precautionary statements (“DANGER,” “WARNING,”

and “CAUTION”), followed by specific instructions,

are found in this manual and on machine decals. These

precautions are intended for the personal safety of the

operator, user, servicer, and those maintaining the

machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

1. Read all instructions before using the washer.

2. Refer to the Grounding Instructions in the

Installation Manual for the proper grounding of

the washer.

3. Do not wash textiles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline, kerosene, waxes, cooking oils,

dry-cleaning solvents, or other flammable or

explosive substances as they give off vapors that

could ignite or explode.

4. Do not add gasoline, dry-cleaning solvents, or

other flammable or explosive substances to the

wash water. These substances give off vapors that

could ignite or explode.

5. Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been

used for two weeks or more. HYDROGEN GAS

IS EXPLOSIVE. If the hot water system has not

been used for such a period, before using a

washing machine or combination washer-dryer,

turn on all hot water faucets and let the water

flow from each for several minutes. This will

release any accumulated hydrogen gas. The gas is

flammable; do not smoke or use an open flame

during this time.

6. Do not allow children to play on or in the washer.

Close supervision of children is necessary when

the washer is used near children. This is a safety

rule for all appliances.

7. Before the washer is removed from service or

discarded, remove the door to the washing

compartment.

8. Do not reach into the washer if the wash drum is

moving.

DANGER indicates the presence of a

hazard that will cause severe personal

injury, death, or substantial property

damage if the danger is ignored.

DANGER

WARNING indicates the presence of a

hazard that can cause severe personal

injury, death, or substantial property

damage if the warning is ignored.

WARNING

CAUTION indicates the presence of a

hazard that will or can cause minor

personal injury or property damage if the

caution is ignored.

CAUTION

To reduce the risk of fire, electric shock,

serious injury or death to persons when

using your washer, follow these basic

precautions:

W023

WARNING

Installation/Operation Supplement

F232145 (EN)

9. Do not install or store the washer where it will be

exposed to water and/or weather.

10. Do not tamper with the controls.

11. Do not repair or replace any part of the washer,

or attempt any servicing unless specifically

recommended in the user-maintenance instructions

or in published user-repair instructions that the

user understands and has the skills to carry out.

12. To reduce the risk of an electric shock or fire, DO

NOT use an extension cord or an adapter to

connect the washer to the electrical power source.

13. Use washer only for its intended purpose,

washing clothes.

14. ALWAYS disconnect the washer from electrical

supply before attempting any service. Disconnect

the power cord by grasping the plug, not the cord.

15. Install the washer according to the Installation

Instructions. All connections for water, drain,

electrical power and grounding must comply

with local codes and be made by licensed

personnel when required.

16. To reduce the risk of fire, textiles which have

traces of any flammable substances such as

vegetable oil, cooking oil, machine oil,

flammable chemicals, thinner, etc., or anything

containing wax or chemicals such as in mops and

cleaning cloths, must not be put into the washer.

These flammable substances may cause the

fabric to catch on fire by itself.

17. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or product.

18. Keep washer in good condition. Bumping or

dropping the washer can damage safety features.

If this occurs, have washer checked by a qualified

service person.

19. Replace worn power cords and/or loose plugs.

20. Be sure water connections have a shut-off valve

and that fill hose connections are tight. CLOSE

the shut-off valves at the end of each wash day.

21. Loading door MUST BE CLOSED any time the

washer is to fill, tumble or spin. DO NOT

bypass the loading door switch by permitting the

washer to operate with the loading door open.

22. Always read and follow manufacturer’s

instructions on packages of laundry and cleaning

aids. Heed all warnings or precautions. To reduce

the risk of poisoning or chemical burns, keep

them out of the reach of children at all times

(preferably in a locked cabinet).

23. Always follow the fabric care instructions

supplied by the textile manufacturer.

24. Never operate the washer with any guards

and/or panels removed.

25. DO NOT operate the washer with missing or

broken parts.

26. DO NOT bypass any safety devices.

27. Failure to install, maintain, and/or operate this

washer according to the manufacturer’s

instructions may result in conditions which can

produce bodily injury and/or property damage.

NOTE: Underloading can cause out-of-balance

conditions that can shorten life of machine.

NOTE: The WARNING and IMPORTANT

SAFETY INSTRUCTIONS appearing in this

manual are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining or operating the washer.

Any problems or conditions not understood should be

reported to the dealer, distributor, service agent or the

manufacturer.

F232145 (EN)

Installation/Operation Supplement

Specifications and Dimensions

2 Speed Models

Specification 18, 20 25 27, 30 35 40 50

Overall Dimensions

Overall width, in. (mm) 26

(660)

(737)

30-1/8

(765)

30-5/8

(778)

34-1/16

(865)

Overall height, in. (mm) 42-7/8

(1089)

(1143)

45-7/8

(1165)

47-1/4

(1200)

47-7/8

(1216)

50-13/16

(1291)

Overall depth, in. (mm) 29-13/16

(757)

33-7/8

(860)

34-13/16

(884)

38-1/2

(978)

40-3/16

(1021)

41-13/16

(1087)

Weight and Shipping Information

Net weight, lbs. (kg) 390

(177)

435

(198)

498

(226)

650

(295)

706

(321)

820

(373)

Domestic shipping weight, lbs.

(kg)

428

(194)

470

(214)

545

(245)

680

(309)

744

(338)

875

(398)

Domestic shipping volume, ft3

(m3)

(0.8)

(0.9)

(1.0)

(1.09)

42.6

(1.19)

(1.5)

Export shipping weight lbs., (kg) 480

(218)

530

(241)

588

(267)

760

(345)

846

(385)

1020

(464)

Export shipping volume, ft3(m3)30.1

(0.86)

36.7

(1.03)

39.6

(1.11)

47.1

(1.32)

54.1

(1.51)

58.7

(1.67)

Wash Cylinder Information

Cylinder diameter,

in. (mm)

(533)

(610)

26-1/4

(667)

26-1/4

(667)

(762)

Cylinder depth, in. (mm) 13-3/4

(349)

18-3/4

(476)

(406)

18-3/8

(467)

20-1/4

(514)

(508)

Cylinder volume, ft3(l) 2.76

(78.1)

3.76

(106.5)

4.19

(118.6)

5.76

(163.1)

6.34

(180)

8.18

(231.6)

Perforation size, in. (mm) 0.188

(4.76)

0.188

(4.76)

0.188

(4.76)

0.188

(4.76)

0.188

(4.76)

0.188

(4.76)

Perforation open area, % 17 17 23 17 17.5 18

Table 1 (Continued)

Installation/Operation Supplement

F232145 (EN)

Table 1 (Continued)

2 Speed Models (Continued)

Specification 18, 20 25 27, 30 35 40 50

Door Opening Information

Door opening diameter,

in. (mm)

(305)

14-11/32

(364)

14-11/32

(364)

16-1/4

(413)

16-1/4

(413)

Height of door bottom above floor,

in. (mm)

14-3/8

(365)

14-3/8

(365)

(356)

(406)

14-1/2

(368)

13-1/2

(343)

Power Consumption

Average power used per cycle,

kW-hr

0.20 0.25 0.25 0.30 0.34 0.42

Average HVAC load, Btu/hr 425 400 400 510 510 700

Drive Train Information

Number of motors in drive train 1 1 1 1 1 1

Wash/reverse power, HP (kW) 0.18

(0.13)

0.25

(0.19)

0.25

(0.19)

0.40

(0.30)

0.40

(0.30)

0.55

(0.41)

High extract power, HP (kW) 1.0

(0.746)

1.4

(1.04)

1.4

(1.04)

1.8

(1.3)

1.8

(1.3)

2.7

(2.01)

Cylinder Speeds

Wash/reverse speed, RPM 53 55 47 47 47 44

High extract speed, RPM 525 540 480 470 470 450

Centrifugal Force Data

Wash/reverse centrifugal force, Gs 0.85 0.90 0.75 0.82 0.82 0.825

High extract centrifugal force, Gs 82.1 86.8 78.4 82.3 82.3 86.3

Table 1 (Continued)

Installation/Operation Supplement

F232145 (EN)

Table 1 (Continued)

2 Speed Models (Continued)

Specification 18, 20 25 27, 30 35 40 50 60

Balance Detection

Vibration switch installed N/A N/A N/A N/A N/A N/A N/A

Direct Steam Heating (Optional)

Steam inlet connection size,

in. (mm)

1/2

(13)

1/2

(13)

1/2

(13)

1/2

(13)

1/2

(13)

1/2

(13)

1/2

(13)

Numberofsteaminlets 1111111

Steam required to raise

bath water temperature

10°F (6°C)

LOW 1.05 (0.75) 1.4 (1.01) 1.44 (1.03) 2.06 (1.48) 2.09 (1.51) 2.76 (1.99) 2.76 (1.99)

HIGH 1.4 (1.01) 1.59 (1.15) 1.91 (1.37) 2.69 (1.94) 2.84 (2.04) 3.59 (2.59) 3.59 (2.59)

Average steam use per cycle,

bhp (kg)

0.71

(11.1)

0.87

(13.6)

0.97

(15.2)

1.4

(21.6)

1.43

(22.4)

1.84

(28.9)

1.84

(28.9)

Electrical Heating (Optional)

Total electrical heating capacity,

7.8 7.8 7.8 15.6 15.6 23.4 23.4

Electricalheatingelements 3336399

Electrical heat element size, kW 2.6 2.6 2.6 2.6 5.2 2.6 2.6

Installation/Operation Supplement

F232145 (EN)

Gap Setting for Vibration Switch

(Variable-Speed and Fixed-Speed

Models)

After the machine has been properly installed, the

vibration switch gap must be measured before

conducting the Control Function Test. Locate the gap

found between the vibration switch and the machine

structure. Refer to Figures 1, 2, 3, 4and 5. To check

the gap setting of the switch, proceed as follows:

1. Remove the front panel on 18-50 models.

Remove the rear panel on 60-80 models. Remove

the top cover on the 125 model. The switch can

be seen inside the bottom right corner of the A-

frame, mounted on a bracket. Refer to Figures 1,

2, 3, 4and 5.

2. Measure the gap distance when the switch is in

both the open and closed positions. The

specifications should be at the minimum switch

gap setting when the switch is open and at the

maximum switch gap setting when the switch is

closed. If these distances are not correct, adjust

the balance switch to these specifications.

NOTE: The standard position of the switch is open,

or non-tripped.

3. Tighten nuts on switch extension after adjusting

the gap. Measure the gap distance to verify

accurate setting.

18, 20 27, 30 35 40 50 60 80 125

Switch gap

setting*

0.015-

0.025 in.

(0.38-

0.64 mm)

0.025-

0.035 in.

(0.64-

0.89 mm)

0.030-

0.040 in.

(0.76-

1.02 mm)

0.020-

0.030 in.

(0.51-

0.64 mm)

0.025-

0.035 in.

(0.64-

0.89 mm)

0.013-

0.015 in.

(0.20-

0.25 mm)

0.009-

0.011 in.

(0.23-

0.28 mm)

0.006-

0.008 in.

(0.15-

0.20 mm)

* Gap setting should be made with “GO-NO-GO” type feeler gauge. Lower value must not trip switch. Upper value must trip switch.

Tabl e 2

Indice

Altri manuali Alliance Laundry Systems Rondella

Alliance Laundry Systems

Alliance Laundry Systems LTS90A*N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 802715 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems LTS95A*N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems CS018 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems EE1010 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems FLW1526C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems H264I Guida

Alliance Laundry Systems

Alliance Laundry Systems TLW12C_SVG Guida

Alliance Laundry Systems

Alliance Laundry Systems HCD020GD2 Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems 201470R7 Manuale d'uso e manutenzione

Alliance Laundry Systems

Alliance Laundry Systems FLW1548C SVG Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 9002062R3 Guida all'installazione

Alliance Laundry Systems

Alliance Laundry Systems H370I Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 802733R4 Guida

Alliance Laundry Systems

Alliance Laundry Systems EA2011 Series Istruzioni per il montaggio

Alliance Laundry Systems

Alliance Laundry Systems AFBE9BSP303NN29 Istruzioni operative

Alliance Laundry Systems

Alliance Laundry Systems LWS16M series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems AWS48NW Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen FV6000WN Manuale di servizio

Alliance Laundry Systems

Alliance Laundry Systems LTS80A Series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems LWS45M series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems FLW1511C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HC125BYV Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems CHM1766C Manuale del proprietario

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
