Datasheet | integrated Multiservice Access Platform

GE8

AT-TN117-A 8 Port GbE Service and Aggregation Module

Allied T

elesis’ iMAP familyof integrated

Multiservice Access Platforms

Aggregation of GbE Network Traffic

The GE8 module available for use with the

iMAP 9000 series is a new advancement in line

card flexibility. As network bandwidth continues

to grow, Service Providers find increasing

bandwidth requirements farther in the local

loop. The ability to maintain a single IP

infrastructure to address Network Transport

bandwidth as well as last mile access bandwidth

is pivotal for any network operator.

The GE8 module is primarilyintended to be

used as an aggregation element with the

introduction of Allied Telesis’ 10G iMAP

common control upgrade (CFC56 and XE1).

Combined, these modules provide 10G

transport bandwidth as well as aggregation of

up to 8 GbE feeds per GE8 module. When

used in the iMAP Resource Module slots, a pair

of GE8 modules can be used to subtend up to

8EPSRTMrings providing an extremely flexible,

reliable and dense aggregation point from any

network location.

If point-to-point aggregation links are required,

the GE8 provides cost effective and feature rich

aggregation to any GbE network element. As

network designs continue to blend the line

between Access and Transport, the GE8 will

become a key component of any IP Triple Play

network design.

MetroEthernet Connectivity

With the GE8 module, the Allied Telesis iMAP

is ideally suited for delivering GbE services to

any Enterprise or business location relying on

last mile fiber access. With advanced features

including per VLAN rate limiting, the GE8

module can be used as either a network

interface for subtended remote locations or

for point-to-point connectivity to a strategic

business.

The GE8 module supports up to 4095 VLANs

and can be used to provide business Ethernet

services. Whether serving customers from

traditional COs, CEVs, RTs or an Enterprise, the

iMAP and GE8 module offers wirespeed and

non-blocking bandwidth for any IP/Ethernet

application.

Part of Allied Telesis’ IP Broadband

Access Family

Whether it is broadband ADSL2+, FTTH or

POTS, the iMAP familyis the ideal platform

for last mile service delivery.The GE8 line card

can be used with any of the iMAP family of

carrier grade, IP Multiservice Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU,7service slots)

•MiniMAP 9100 (1RU,3service slots)

Provisioning, management, and diagnostics of

subscriber ports can be accomplished from

either the iMAP command line interface or the

NMS.

The AT-TN117 has been designed to survive

the most rugged environmental conditions. It

can be confidently deployed in either a central

office or in outdoor enclosures withstanding

extremes of heat, cold, and light exposure.

Key Features

•8GbE Wirespeed ports

•SFP Optics

•Up to 10 Gbps non-blocking backplane link

•Supportfor EPSRTM 50ms Resiliency

•Per VLAN Rate Limiting

•Hardened for OSP designs

QoS

•Eight Queues

•Strict Priority scheduling

•VLAN Stacking

Security

•Upstream Forwarding Only

•ExtensiveACL Support

Services Supported

•High Speed Internet

•VoIP

•IPTV

•Business VPN

•NetworkElement Subtending

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000118 Rev. B

GE8 |AT-TN117-A 8 Port GbE Service and Aggregation Module

GE8

Model Description Part #

GE8 8ports, GE8 Service and Aggregation Module AT-TN-117-A

Ordering Information

Interface Specifications

Number of GbE ports: 8

Backplane capacity: 10Gbps

Physical design: Front Access

8x SFP

Port Specifications

Number of VLANs per port: 4095

Priority queues: 8

Dropped packet counter

Full traffic classifier support

Full traffic classifier action support

ARP Filtering

Egress Metering: 1Mbps increment

Ingress Max Burst Size: 64kbps

gress Max Burst Size: 64kbps

Protocols and Specifications

IEEE 802.1Q VLAN Bridging

IEEE 802.1p Prioritization

IETF RFC 1112 IP Multicasting/IGMP Snooping v1

IETF RFC 2236 IP Multicasting/IGMP Snooping v2

DHCP Relay Agent option 82 (RFC 3046)

Power Requirements

Maximum Power: 53W

Environmental Specifications

Operating Temp: -40C to 65C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

FCC Part15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDA RUS

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF

iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G

iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF

iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G

MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80

MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*

iMAP Common Control

Model Description Part #

CFC24 24GbE switch controller card AT-TN-401-B

GE3 3x GbE WAN interface card AT-TN-301-A

CFC56 56 GbE switch controller card AT-TN-407-A

XE1 10 GbE WAN interface card AT-TN-308-A

CFC12 12GbE switch controller card AT-TN-408-A

*Where XX =10 for U.S. power cord

=20 for no power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord

Related iMAP Line Cards and Accessories

Model Description Part #

FE10 10-port, 100Mbps Fast Ethernet Service Module AT-TN-102-A

FX10BX 10-port, 100Mbps SM, single fiber Service Module AT-TN-109-A
