Allied Telesis LANEDGE AT-LE700 Manuale utente

Allied Telesis www.alliedtelesis.com

Datasheet | Switches

LANEDGE AT-LE700 Series

Unmanaged 5 & 8 Port Desktop Switches

T-LE700/5xx

5port 10/100TX Unmanaged Switch

AT-LE700/8xx

8port10/100TX Unmanaged Switch

High Performance

Apowerful 10/100 switch solution for desktop,

small networkor conference room environ-

ments, the Allied Telesis LE700 series of

unmanaged switches feature full auto-negotiating

10/100 ports that detect the speed and duplex

modes of attached devices, enabling them to

automatically configure for the best possible

performance.

Quality & Reliability

Allied Telesis is a worldwide leader in unman-

aged Ethernet switches. Shipping more than

250,000 every year,Allied Telesis offers proven

reliability and industry recognized quality.

Applications

Connected to managed switches such as the

AT-8524M or unmanaged switches such as

the AT-GS900 series or AT-FS700 series, the

AT-LE700 provides a quality, affordable solution

for small businesses or Home offices looking

to upgrade their networks.

Simplified Installation

Available in 5 & 8 port models, the

AT-LE700 Series provides wall- & desk-mounting

options, as well as mounting magnets to give

users their choice of deployment locations.

These fully auto-configuring AT-LE700 Series

switches require minimal set-up by the user.

Auto-sensing ports enable seamless and simple

connectivity between existing 10Mbps Ethernet

and 100Mbps Fast Ethernet UTP devices—

and all units can be installed in minutes. Every

AT-LE700 Series model is equipped with auto

MDI/MDIX across all ports for simple connection

to other hubs and switches. Finally, easy to read

top panel LEDs show ongoing switch status

and simplify troubleshooting.

Key Features

•5or 8 10/100TX ports

•Non-blocking architecture

•Auto-negotiation ports

•Auto MDI/MDIX on all ports

•Plug-and-play installation

•Palm sizedesign, suitable for all small business

and home office networking

©2006 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the proper ty of their respective owners. 617-000082 Rev. D

LANEDGE AT-LE700 Series |Unmanaged 5 & 8 Port Desktop Switches

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

Technical Specifications

Performance

Ethernet

10Mbps (Half Duplex)

20Mbps (Full Duplex)

Fast Ethernet

100Mbps (Half Duplex)

200Mbps (Full Duplex)

MAC Addresses: 1K

Packet Buffer: 768K

Half/Full Duplex

Auto Negotiation

Auto MDI/MDIX on all ports

Interface Connections

10/100TX Rj-45

Power Characteristics

Frequency: 50 to 60Hz

AT-LE700/5

Power Requirements: 7.5vDC +/- 5%

Power Consumption: 2.8W (Max.)

Current Consumption 800mA

AT-LE700/8

Power Requirements: 7.5vDC +/- 5%

Power Consumption: 2.5W (Max.)

Current Consumption: 800mA

Environmental Specifications

Operating Temp: 0-40 C (32-104F)

Non-Operating Temp: -10-70C (-13 to 158F)

Operating Humidity: 10-90% Non-Condensing

Non-operating Humidity: 5-90% Non-Condensing

Physical Specifications

Dimensions: 3.0 x 12.3 x 7.6 cm (W x D x H)

(1.18 x 4.8 x 3.0 in)

Weight: 0.12kgs (0.26 lbs)

Standards & Compliance

IEEE802.3 10T Ethernet

IEEE802.3u 100TX Fast Ethernet

IEEE802.3x Flow Control

Certification

FCC/EN55022 Class A

VCCI Class A

C-TICK

Ordering Information

AT-LE700/5-xx

5port 10/100TX unmanaged switch

AT-LE700/8-xx

8port 10/100TX unmanaged switch

Where xx = 10 for U.S. power adapter

=20 for no power adapter

=30 for U.K. power adapter

=40 for Australia power adapter

=50 for Europe power adapter
