Allied Telesis Rapier 48w Manuale

Rapier 48w Switch

Removable Fan Installation Guide

AT-FAN04

Rapier 48w Switch Removable Fan

Rapier 48w Switch Removable Fan Installation Guide

Document Number 613-000775 REV A

reproduced without prior written permission from Allied Telesis, Inc.

Allied Telesis, Inc. reserves the right to change specifications and other

information in this document without prior written notice. The information

provided herein is subject to change without notice. In no event shall Allied

Telesis, Inc. be liable for any incidental, special, indirect, or consequential

damages whatsoever, including but not limited to lost profits, arising out of or

related to this manual or the information contained herein, even if Allied Telesis,

Inc. has been advised of, known, or should have known, the possibility of such

damages.

All company names, logos, and product designs that are trademarks or

registered trademarks are the property of their respective owners.

Installation Guide

Models Covered by this Guide

This document describes how to install the AT-FAN04 fan-only module (FOM)

in a Rapier 48w switch.

Package Contents

The following items are included with each FOM:

■one Installation Guide

■one warranty card

Installing a Fan-Only Module

Before you begin:

■Read the safety information for the switch.

Safety information is available in the Rapier 48w Switch Installation and Safety

Guide bundled with every Rapier 48w switch. You can also download this

document from www.alliedtelesis.com/support/software.

■Gather necessary tools and equipment.

You will need a flat screwdriver to adjust the captive screws on the FOM.

We recommend installing new air filters when you replace a FOM. Air

filters must be purchased separately from your authorised Allied Telesis

distributor or reseller.

■Verify the package contents if you have not already done so.

See “Package Contents” on page 3. Contact your authorised distributor or

reseller if items are damaged or missing.

You do not need to power down the switch to change a FOM, but you should

replace FOMs one at a time.

Rapier 48w Switch Removable Fan

1. Unpack the fan-only module.

Caution Follow correct anti-static procedures when installing a FOM.

Failure to do so could damage the FOM or the switch. If you are unsure

about correct procedures, contact your authorised distributor or reseller.

While observing Electrostatic Discharge (ESD) precautions, remove the

FOM from its packing material in an anti-static environment.

2. Remove the current fan-only module from the switch.

Using a flat screwdriver, loosen the captive screws on the faceplate of the

FOM, and slide the FOM out of its cage. The internal power connection is

quite solid so pull firmly on the captive screws.

Installation Guide

3. Install filters in the replacement fan-only module.

Install an air filter in the replacement FOM. Insert the air filter into the

narrow slot between the faceplate of the FOM and the fan. Position the air

filter with the plastic frame towards the fan, the quadrafoam towards the

faceplate, and the flextab to the top. The air filter should fit snugly.

4. Install the replacement fan-only module.

Caution Keep the FOM in straight alignment and insert it slowly. Forcing a

misaligned FOM is likely to damage both the chassis and FOM.

Slowly and carefully slide the replacement FOM into the cage, making sure

that the air filter and the flextab are clear of any contact points.

Firmly press the FOM until the faceplate engages, or nearly engages, the

chassis.

5. Secure the fan-only module.

Tighten the two captive screws on the faceplate of the FOM.

Rapier 48w Switch Removable Fan

Where to Find More Information

For more information about the Rapier 48w switch, see the following

documents:

■The Rapier 48w Switch Installation and Safety Guide describes how to install

the Rapier 48w switch and includes statutory and safety information

■The Rapier Series Switch Hardware Reference, which contains detailed

information on the hardware features of all Rapier Series switches

■The Rapier Series Switch AlliedWare™ Operating System Software Reference,

which contains detailed information on configuring the switch and its

software

You can download these documents from www.alliedtelesis.com.
