Altec Lansing A7 Manuale utente

Legacy product line

Specifications:

Model 510 S Loudspeaker

3 Way Tower

Acoustic Suspension

Single/Bi/Tri-wiring

Model 508 S Loudspeaker

3 Way Tower

Acoustic Suspension

Single wiring

Model 305 S Loudspeaker

3 Way bass reflex system

Single AMP wiring

Woofer:

2x10" woven carbon fiber

Midrange:

2" Polyamide Titanium

Tweeter:

1" Polyamide Titanium

Woofer:

2x8" woven carbon fiber

Midrange:

2" Polyamide Titanium

Tweeter:

1" Polyamide Titanium

Woofer:

1x10" woven carbon fiber

Midrange:

2" Polyamide Titanium

Tweeter:

1" Polyamide Titanium

Usable (-10 dB):

20 Hz - 22 kHz

±3dB: 28Hz - 18 kHz

Usable (-10 dB):

26 Hz - 22 kHz

±3dB: 38Hz - 19 kHz

Usable (-10 dB):

29 Hz - 22 kHz

±3dB: 35Hz - 18 kHz

300 W nominal 200 W nominal 200 W nominal

84 dB 83 dB 86 dB

6 ohms 6 ohms 8 ohms

Hand-finished walnut veneer

and cherry veneer

Hand-finished walnut veneer

and cherry veneer

Hand-finished walnut veneer

and cherry veneer

49" x 12" x 14"

2 way

Horn Loaded

LF:

1x15" (515-8G)

1x2" compression driver

(902-8T) on 511B horn

Usable (-10 dB):

35 Hz - 22 kHz

±3dB: 54Hz - 16 kHz

200 W nominal

97 dB

8 ohms

Black splatter

54" x 30" x 24" 41" x 11" x 11" 27" x 15" x 12"

Drivers

Frequency Response

Power Handling

Sensitivity

Nominal Impedance

Cabinet Finish

Cabinet Size

In a class by itself during Hollywood’s golden era, the A7 was the only commercially

available theater speaker approved by the Research Council of the Academy of Motion

Picture Arts and Sciences. Originally introduced in the 1950s, the A7 became a mainstay

in recording studios and audiophiles’ homes as well as in theaters.

The new Legacy A7 is a meticulous re-issue of this classic Altec speaker. Manufactured in

the USA, it is true to the original in every engineering detail with one exception: more

refined cabinetry.

Technologies mature. Tastes change. Audio evolves. However,

qualitatively speaking, some of the best speakers to ever hit the

market did so years ago. That’s why Altec Lansing is re-issuing

some real classics: the 305 S, 508 S, and 510 S – speakers famous

for their sensitivity and power.

What’s more, we’ve tweaked these systems ever so slightly,

enhancing their best qualities and furthering the “art of

balance.” The result? An audio experience that offers all the best

qualities of yesterday and today.

305 S

508 S

510 S
