FEATURES
p2
Hardware
•9 (KM0932) or 5 (KM0532) consoles independently and simultaneously control up to 32
directly connected servers
•Flexible expansion – the installation can grow as your needs grow:
• Up to 7 Matrix Expansion KVM switches can be daisy chained from a master switch
• Switches can be cascaded to three levels to access and manage more than 8,000
computers (supports KH1508 / KH1516 switches for economical expansion)
• Dual root configuration allows up to 18 consoles to access any servers on the installation
•Audio support for multimedia-capable devices
•Redundant power supply for 24 x7 reliability
•Multiplatform support: PC, Mac, Sun, and Serial Console access – any type of console can
control any type of computer; mixed combinations (PS/2 & USB) supported on both the
console and computer sides
•Compact design – rack mounts in only 1U of rack space
Ease-to-Use Interface
•Full screen graphical user interface – saves on training time and costs – increases user
efficiency
•Embedded web interface for easy system configuration and management
•Composite tree view – all connected devices are integrated in a single device tree for
convenient management access and control
•The port list automatically expands when stations are added – port names are automatically
reconfigured when the station sequence changes
•Multilingual user interface support – English, German, Japanese, Korean, Traditional
Chinese, Simplified Chinese, Russian.
Convenient Port Operation
•Computer selection via GUI or intuitive hotkey combinations
•Port level access control – users can only access the ports they have been authorized for –
whether in a single-station or multi-stage installation
•Users can access features on multiple computers simultaneously – a user can be working and
listening to music on computer 1 while utilizing virtual media on computer 2 at the same
time.
•Versatile port operation modes for flexible server management:
• Scan – provides automatic monitoring of user-selected computers
• Exclusive – allows the first user to access a port to gain exclusive viewing rights and
control over it for as long as he accesses it
• Occupy – allows the first user to access a port to control that port while others can only
view it
• Share – allows multiple users to access and control a port at the same time on a
cooperative basis
•Broadcast support enables executing the same command on multiple servers at the same
time
