AOC 02 Manuale utente

User manual

SPEAKER O2

EN 1

Contents

1Important safety instructions 2

Safety

Compliance

Care of the environment

FCC and IC statement

Trademark notice

2Your wireless speaker 5

What's in the box 5

Overview of the speaker 5

Play from Bluetooth devices

Multi-point connection

Control playback

Pairing for stereo mode

PartyLink mode 8

4 Product information 9

5 Troubleshooting 10

General 10

Bluetooth 10

3 Get started 6

Charge the built-in battery 6

Turn On / Oﬀ

USB Playback

EN2

1Important

Safety

Important safety instructions

• Make sure that the power supply

voltage corresponds to the voltage

on the back or the underside of

the unit.

• The speaker shall not be exposed

to dripping or splashing.

• Do not place any source of danger

on the speaker (e.g. liquid ﬁlled

objects, lit candles).

• Make sure that there is enough free

space around the speaker for

ventilation.

• Please use the speaker safely in an

environment with temperature

between 0°C and 45°C.

• Only use attachments and accessories

speciﬁed by the manufacturer.

Battery safety precautions

• Danger of explosion or ﬁre if a battery

is incorrectly replaced. Replace only

with the same or equivalent type.

• A battery (battery pack or battery

installed) shall not be exposed to

excessive heat such as sunshine,

ﬁre or the like.

• A battery in extreme high or low

temperatures during use, storage or

transportation, and low air pressure at

high altitude can pose safety hazards.

• Do not replace a battery with an

incorrect type that can defeat a

safeguard (for example, some lithium

battery types).

• Disposing a battery into ﬁre or a

hot oven, mechanically crushing

or cutting a battery can result in

an explosion.

• Leaving a battery in an extremely

high temperature surrounding, or

an extremely low air pressure

environment may result in an

explosion or leakage of ﬂammable

liquid or gas.

Warning

• Never remove the casing of this speaker.

• Never lubricate any part of this speaker.

• Place this speaker on a ﬂat, hard and

stable surface.

• Never place this speaker on other

electrical equipment.

• Only use this speaker indoors. Keep this

speaker away from water, moisture and

liquid-ﬁlled objects.

• Keep this speaker away from direct

sunlight, naked ﬂames or heat.

• Risk of explosion or ﬁre if a battery is

replaced by an incorrect type.

• Please note that your device contains

built-in lithium batteries. The charging

capacity of lithium batteries will decrease

over time due to their self-discharge

characteristics. To ensure the longevity of

your device's battery, we recommend

charging the built-in lithium battery to

around 50% every 6 months when the

device is not in use.

safety instructions

EN 3

Inform yourself about the local separate

collection system for electrical and

electronic products and batteries. Follow

local rules and never dispose of the

product and batteries with normal

household waste. Correct disposal of

old products and batteries helps prevent

negative consequences for the

environment and human health.

Environmental information

All unnecessary packaging has been

omitted. We have tried to make the

packaging easy to separate into three

materials: cardboard (box), pulp tray

and accessories box or paper card.

Your system consists of materials which

can be recycled and reused if

disassembled by a specialized company.

Please observe the local regulations

regarding the disposal of packaging

materials, exhausted batteries and old

equipment.

AOC O2 Product

explosion diagram

For illustration purposes only

Disposal of a battery into ﬁre or a hot

oven, or mechanically crushing or

cutting of a battery, can result in

an explosion.

Compliance

Hereby, TP Vision Europe B.V. declares

that this product is in compliance with

the essential requirements and other

relevant provisions of Directive 2014/

53/EU. You can ﬁnd the Declaration of

Conformity on

https://aoc.com

Care of the environment

Disposal of your old product and battery

Your product is designed and

manufactured with high quality

materials and components, which

can be recycled and reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains batteries covered by European

Directive 2013/56/EU which cannot be

disposed of with normal household

waste.

Any changes or modiﬁcations made

to this device that are not expressly

approved by MMD Hong Kong Holding

Limited may void the user's authority to

operate the equipment.

EN4

FCC and IC statement

Warning: Changes or modiﬁcations

not expressly approved by the party

responsible for compliance could void

the user’s authority to operate the

equipment.

Note: This equipment has been tested

and found to comply with the limits for

a Class B digital device, pursuant to

Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does

cause harmful interference to radio or

television reception, which can be

determined by turning the equipment

oﬀ and on, the user is encouraged to try

to correct the interference by one or

more of the following measures:

(1) Reorient or relocate the receiving

antenna. (2) Increase the separation

between the equipment and receiver.

(3) Connect the equipment into an

outlet on a circuit diﬀerent from that to

which the receiver is connected.

FCC information

The device complies with the FCC rules,

Part 15. Operation is subject to the

following two conditions:

This device may not cause harmful

interference, and.

This device must accept any

interference received, including

interference that may cause

undesired operation.

(4) Consult the dealer or an experienced

radio/TV technician for help.

RF Warning Statement

The device has been evaluated to meet

general RF exposure requirements. The

device can be used in portable

exposure conditions without restriction.

Trademark notice

The Bluetooth® word mark and logos

are registered trademarks owned by the

Bluetooth SIG, Inc. and any use of such

marks by MMD Hong Kong Holding

Limited is under license.

Other trademarks and trade names are

those of their respective owners.

IC-Canada: CAN ICES-003(B)/NMB-003(B)

This device contains licence-exempt

transmitter(s)/receiver(s) that comply

withInnovation, Science and Economic

DevelopmentCanada’s licence-exempt

RSS(s). Operation is subject to the

following two conditions:

1. This device may not cause interference.

2. This device must accept any

interference, including interference

that may cause undesired operation

of the device.

Avis d’Industrie Canada: CAN ICES-003(B)

/NMB-003(B)L’émetteur/récepteur exempt

de licencecontenu dans le présent appareil

estconforme aux CNR d’Innovation,

Sciences etDéveloppement économique

Canada applicables aux appareils radio

exempts delicence. L’exploitation est

autorisée aux deuxconditions suivantes :

1. L’appareil ne doit pas produire

debrouillage;

2. L’appareil doit accepter tout brouillage

radioélectrique subi, même si lebrouillage

est susceptible d’encompromettre le

fonctionnement.

EN 5

What's in the box

Check and identify the contents of your

package:

• Speaker

• USB cable

• Quick start guide

• Safety sheet

• Worldwide warranty

• Strap

Overview of the speaker

3 2456 17

10 89

2 Your wireless

speaker

• Enter/exit Bluetooth pairing mode.

• Clear Bluetooth pairing

information.

•

Turn the speaker on or oﬀ.

• Decrease volume.

• Charge the built-in battery.

DC IN

• Increase volume.

6PartyLink

Power/Bluetooth LED indicator

• Power/Bluetooth light.

•

• Show the battery level: To check

battery status, press any other

keys but not , as will trigger

the power oﬀ.

• It works only when you have two

identical speakers.

LED indicators

Battery level indicators.

• Short press to play/pause/resume

the playback or pick an incoming call.

Long press to reject an incoming call

or trigger voice assistant of the

connected mobile device.

•

• Press to enter PartyLink pairing

mode.

• Press to enter Stereo pairing

mode.

EN6

3Get started

Always follow the instructions in this

chapter in sequence.

Charge the built-in

battery

The speaker is powered by a built-in

rechargeable battery.

Note

• Fully charge the built-in battery before

using.

• When the speaker is turned on and the

battery is low, the Power/Bluetooth

LED indicator blinks red.

Connect the USB-C socket on the

speaker to an outlet (5V

USB cable.

3A)

(9V 3A）(15V 2A）

by using the provided

INPUT: 9V 3A

INPUT: 15V 2A

INPUT: 5V 3A

OUTPUT: 5V 2A

LED4LED2LED1 LED3 Power/

Bluetooth LED

Power on

When the speaker is being charged,

Power/Bluetooth LED blinks red and

blue and white.

When the speaker is fully charged,

Power/Bluetooth LED blinks white

blue.

The speaker can charge an external device

via USB cable.

Power oﬀ

When the speaker is being charged,

Power/Bluetooth LED is solid red.

When the speaker is fully charged,

Power/Bluetooth LED is oﬀ.

Battery power

Full Solid red

Solid red OFF

OFF

Blinking

Red

Solid red

Solid

red

OFF

LED1 LED2 LED3 LED4 Power/

Bluetooth LED

80%

50% - ＞80%

＞20% - ＞50%

Low battery 20%

≤

≥

EN 7

1Press to turn the speaker on. It

will enter Bluetooth pairing mode

automatically. You can also press

and hold for 3 seconds to enter

Bluetooth pairing mode.

2Enable Bluetooth and select

"AOC O2" in the Bluetooth

list on your device for pairing.

If a message prompts for

permission for Bluetooth

connection, conﬁrm it.

Power/Bluetooth

LED indicator Description

Blinking white

&blue Ready for pairing

Blinking blue Reconnecting the last

connected device

Solid blue Connected

Turn on/oﬀ

Caution

• Risk of speaker damage! Make sure the

power supply voltage corresponds to the

voltage printed on the back or the

underside of the speaker.

• Risk of electric shock! When unplug the

USB cable, always pull the plug from the

socket. Never pull the cable.

• Use only a USB cable speciﬁed by the

manufacturer or sold with this speaker.

Note

The speaker will turn oﬀ automatically

if there is no audio signal from

Bluetooth for 15 minutes.

•

Press to turn the speaker on.

You will hear the prompt sound.

To turn the speaker oﬀ, press

You will hear the prompt sound.

again.

Play from Bluetooth

devices

USB Audio playback

With this speaker, you can enjoy audio

from your Bluetooth device.

Note

• Make sure that the Bluetooth function

is enabled on your device.

• The maximum distance for pairing the

speaker and your Bluetooth device is

9 meters.

• Keep away from any other electronic

device that may cause interference.

Note

Press button. Select sound output

device (AOC O2 USB) on your laptop.

•

Play audio on your Bluetooth

device to start music streaming.

Control playback

During music playback

Press to pause or resume play

Press twice to play the next track

Adjust the volume

EN8

Note

• To disconnect a device, press and hold

for 3 seconds until the Power/

Bluetooth LED indicator blinks white

and blue.

• To clear the pairing information, press

and hold for 8 seconds until the

Power/Bluetooth LED indicator blinks

white quickly for 3 times.

Multi-point control

The product supports multi-point feature,

and can connect two Bluetooth devices

at the same time.

Incoming call has priority over music

playback regardless from the ﬁrst or

second device.

•

Under Stereo or PartyLink mode, multi

-point control is not supported.

•There is a voice prompt when the

second Bluetooth device connects the

speaker.

Once it is connected wtih two Bluetooth

devices, you can select audio source

from either device.

•

Note

PartyLink mode

Partylink is a multi-device connection

solution that connects multiple speakers

wirelessly to provide a rich audio

experience. The speaker can connect up

to 100 AOC speakers together (across

AOC O1, O2 and O3) and play audio at

the same time.

Enter PartyLink mode：

1 Select one speaker as the master

speaker to connect with the Bluetooth

device. Power indicator turns solid blue

once Bluetooth is connected. Then,

press PartyLink button for 3 seconds to

enter PartyLink pairing mode, you will

hear a voice prompt and the Power/

Bluetooth LED indicator of the master

speaker blinks white and blue

alternatively.

2 Press and hold PartyLink button on all

other speakers for 3 seconds to enter

PartyLink pairing mode. When PartyLink

is connected, you will hear a voice

prompt on the slave speakers and

their power indicators turn solid white.

Volume level on slave speakers will

sync from the master speaker after

PartyLink connected.

3 Press and hold PartyLink button on

the master speaker. All speakers will

exit PartyLink mode.

During PartyLink pairing mode, slave

speaker will return to previous state

automatically after 1 minute without

user operations or PartyLink pairing is

not successful.

There is no timeout on master speaker.

EN 9

4Product

speciﬁcations

Note

• Product information is subject to change

without prior notice.

General information

USB port 5V 3A 9V 3A

15V 2A

Built-in lithium battery 7.4V, 10400 mAh

Dimensions (W x H x D)

291.5×130.7×132.8mm

Operation ambient

IP protection class

0 ℃~45 ℃

IP67*

Weight (main unit) 2305g

Ampliﬁer

Output power (RMS) 65 W

Frequency response 20 Hz - 20 KHz

Signal to noise ratio 90 dB

Speaker

Impedance 4 Ω

Maximum input power 40 W

Drivers

Bluetooth

Bluetooth version 5.3

Frequency range 2.402-2.480 GHz

Maximum

transmition power

< 10 dBm

Compatible

Bluetooth proﬁles

HFP V1.8

Bluetooth range up to 9 m

2 x 83 mm drivers

1 x 31 mm tweeter

Pairing for stereo mode

Two identical wireless speakers can pair

with each other for stereo sound.

*The IP67 rating means the speaker driver is

dust tight and can be submerged for up to

30 minutes at a depth of up to 1 m.

Note

• Any speaker can be used as the primary

speaker.

• The speaker connected to a Bluetooth

device can only be used as the primary

speaker.

• Before stereo pairing, make sure that the

secondary speaker is in Bluetooth

pairing mode.

• Keep a maximum distance of 9 meters

between the speaker and your

Bluetooth device.

• In stereo mode, the button operation on

the secondary speaker is as same as that

of the primary speaker.

1 Press to power on both speakers,

and they will enter Bluetooth pairing

mode automatically. The speaker

connected to your Bluetooth device

will be used as the primary speaker.

3 Press on either speaker. The

music will be played through both

speakers.

To exit the stereo mode, press and hold

on either speaker.

Passive radiators 2

≥

2 On both speakers, press and hold

to enter stereo pairing mode until

the LED blinks white and blue

alternatively. You will hear a prompt

sound when successfully connected,

Power/Bluetooth LED of the primary

speaker is solid blue and that of the

secondary speaker is solid white.

Indice

Altri manuali AOC Altoparlanti

AOC

AOC SPEAKER O3 Manuale utente

Manuali Altoparlanti popolari di altre marche

argon audio

argon audio IE20 Manuale utente

Denon

Denon SC-N7 Manuale utente

Gemline

Gemline Ace 3952 Manuale utente

Focal

Focal ON WALL 300 Manuale di istruzioni

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuale utente

SoundLogic

SoundLogic BCCS-6/6395 Manuale utente

Peavey

Peavey DTH 218 Manuale utente

Avantree

Avantree Pluto Air Manuale utente

Morel

Morel Integra Series INTEGRA OVATION 4 Manuale utente

Oppo

Oppo SONICA Manuale utente

Bose

Bose SoundLink Wireless Music System Manuale utente

Rocksteady

Rocksteady Stadium Manuale utente

Bowers & Wilkins

Bowers & Wilkins 4 Manuale utente

Sonance

Sonance SONOS OUTDOOR Series Manuale utente

Electro-Voice

Electro-Voice EVID FM4.2 Manuale utente

Pioneer

Pioneer XW-HTD630 Manuale utente

Onn

Onn BWA16AA002 Manuale utente

HP GL313AA - USB Speakers PC Multimedia Manuale utente
