ADP-1174 User Manual 1

ADP-1174 Display Monitor

User Manual

ReleaseDate Revision

Oct. 2007 V0.1

Aplex Technology, Inc.

9F-5, No. 2, Jian Pa Road, Chung Ho City, Taipei County, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplex.com.tw

ADP-1174 User Manual 2

Warning!___________________________________

This equipment generates, uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio communications.

It has been tested and found to comply with the limits for a Class A computing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event shall Aplex Technology

Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or

misuse of information in this document or in any related materials.

Electric Shock Hazard – Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

ADP-1174 User Manual 3

Table of Contents______________________

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Chapter1 GettingStarted

1.1 Features………………………………………………..………….………….5

1.2 Specifications…………………………………………....……………...….5

1.3 Dimensions…………………………………...………………………….…6

1.4 Brief Description...................................................................................7

1.5 Display Mode……………………………………………………………….8

Chapter2 OSD

2.1 Front Panel Controls……………………………………………….…..…….9

2.2 OSD Controls…………………..……………………………………………..9

2.3 Main Menu…..………..……………………………………………………..10

2.4 AD Board (TB-6020) OSD Functions…….………………………………13

Chapter3 ControlBoard

3.1 Introduction to PenMount Control Board………………………………..14

3.2 Features…………………………………………………………………….15

3.3 Electrical Specifications…………………………………………………...15

3.4 Installation of Control Board……………………………………………...16

Chapter4 Installation

4.1 Windows 2000/XP Driver Installation…………………………………….17

4.2 Configuring PenMount Windows 2000/XP Driver………………………21

4.3 Uninstall PenMount Windows 2000/XP Driver………………………….31

Chapter5 Software

5.1 Software Functions………………………………………………………..32

5.2 Software Function Descriptions……………………………………….…33

ADP-1174 User Manual 4

Appendix A: Board Description & Specifications………………….40

Appendix B: Controller IC Specifications………………………………42

Figures

Figure 1.1: Dimensions of ADP-1174….……………………………………..6

Figure 1.2: Front View of ADP-1174………………………………………….7

Figure 3.1: Bird Eye’s View of Control Board………………………………14

Figure 3.2: Mechanical Drawing of Control Board…………………………14

Figure A: Panelmounting……………………………………………………43

Figure B: VESA 100 mounting………………………………………….….44

Appendix

Panelmounting…..…………………………………………………………….43

VESA 100 mounting…………………………………………………………..44

ADP-1174 User Manual 5

Chapter 1_____________________________

1.1 Features

● 17” SXGA color TFT LCD monitor

●Heavy-duty steel chassis

●NEMA 4/IP65-compliant aluminum front panel

●OSD on the front panel

●Long backlight lifetime of 50,000 hours

● Panel or VESA 100 mount

● DVI, composite video and S-video input (optional)

● Power Input: 100~240V AC

● Resistive touch screen (optional)

1.2 Specifications

Display

● Display: 17” SXGA color TFT LCD monitor

● Maximum resolution: 1600 x 1200 with auto phase and auto position

● Maximum colors: 256K

● Dot size (mm): 0.264 x 0.264

● Luminance: 250 cd/m²

● Viewing angle: 150 degrees(H), 140 degrees(V)

● Backlight life: 50,000 hours

● Control: OSD on the front panel

● Touch screen: resistive (optional)

● Power Supply: Internal Universal AC/DC adapter

Mechanical

● Construction: heavy-duty steel chassis

● NEMA 4/IP65-certified front panel

● Mounting type: panel or VESA 100 mount

● Auto recognition of input signal

● Dimensions(WxHxD): 439 x 64.7 x 348mm

ADP-1174 User Manual 6

Environmental

● Operating temperature: 0 to 45℃ (32 to 113℉)

● Storage temperature: -20 to 60℃(-4 to 140℉)

●Relative humidity: 10 to 95% @40℃, non-condensing

●Vibration: 1G peak, 10~150Hz

●Shock: 10G peak acceleration (11 msec.duration)

●Certification: Meet CE, FCC Class A

Ordering Information

ADP-1174 17” SXGA industrial display monitor

ADP-1174T 17” SXGA industrial display monitor with Resistive touch screen (Optional)

1.3 Dimensions

Figure 1.1: Dimensions of the ADP-1174

ADP-1174 User Manual 7

1.4 Brief Description of the ADP-1174

The ADP-1174 is a 17" SXGA color TFT LCD monitor that comes with a dot size of 0.264 x 0.264mm,

viewing angle of 150 (H) degrees and 140 (V) degrees, and more outstanding features, thus giving

you the best in monitoring and control applications.

The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is

panel-mounted in a NEMA rated cabinet or enclosure. It can also be VESA 100-mounted. It is optional

to be equipped with a resistive touch screen.

Figure 1.2: Front View of the ADP-1174

ADP-1174 User Manual 8

1.5 Display Mode

Display Mode Hori. Sync (KHz) Vert. Sync. (Hz)

31 60

VGA 640 x 480 38 72

38 75

35 56

SVGA 800 x 600 38 60

48 72

47 75

48 60

XGA 1024 x 768 56 70

60 75

1152 x 864 68 75

64 60

SXGA

1280 x 1024 80 75

ADP-1174 User Manual 9

Chapter 2_____________________________

2.1 Front Panel OSD Functions

Auto Adjust Up/Left Down/Right Power

Menu/Entry Power Indicator

Power switch: To turn ON or OFF the power

Shift the icon to the right side or shift it up

Shift the icon to the left side or shift it down

Menu: To enter OSD menu for related icon and item.

Auto Button: One-touch auto adjustment

1.) Getting into Burn-in Mode

Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don’t let them go)

the buttons until the AC power cord is connected and the “RGB” appears on the top left corner

of your screen. Now it can be put into the burn-in mode for changing colors.

2.) Getting Out of Burn-in Mode

Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the

button (If not workable, press the button and don’t let them go) until the AC power cord is

connected. Please don’t let your fingers go until the AC power cord is connected again and the

wording of “RGB” appears on the top left corner of your screen, and wait for 3 seconds. Under the

non-signal entry situation, if is seen, exit is thus successfully made.

Cable Not Connected

ADP-1174 User Manual 10

2.2 OSD Controls

To make any adjustment, select the following:

1. Press (Menu) to show the OSD menu or disable the OSD menu.

2. Select the icon that you wish to adjust with the ( / or +/-) key in the menu.

3. Press (Menu) and then choose the item with the ( / or +/-) key.

4. Press (Menu) and then adjust the quality with the ( / or +/-) key.

1.) If the “RGB” is still on the top left corner of the screen, press to enter “Miscellaneous” and

choose “Reset”, and then Yes, and press . When the screen goes black, disconnect power

and repeat the above steps.

2.) If the “RGB” is not found, disconnect the AC power cord first. Then press the buttons

(don’t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When

“RGB” appears, repeat the above steps.

3.) Functions of OSD Keys
