Aplex ADP-1224A Manuale utente
ADP-1224A User Manual
2
Warning!___________________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions manual, it may cause interference to radio communications.
It has been tested and found to comply with the limits for a ClassA computing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Disclaimer
This information in this document is subject to change without notice. In no event shall Aplex Technology
Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or
misuse of information in this document or in any related materials.
Electric Shock Hazard –Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.
ADP-1224A User Manual
3
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Chapter 1 Getting Started
1.1 Specifications…………………………………………....……………...….5
1.2 Dimensions…………………………………...………………………….…6
1.3 Brief Description...................................................................................7
1.4 Display Mode……………………………………………………………….8
Chapter 2 OSD
2.1 Front Panel Controls………………………………………………...……9
2.2 OSD Controls…………………..…………………………………………..10
2.3 Main Menu…..………..……………………………………………………..11
2.4 AD Board (VA-3600) OSD Functions…….………………………………13
Chapter 3 Control Board
3.1 Introduction to PenMount Control Board………………………………..14
3.2 Features…………………………………………………………………….15
3.3 Electrical Specifications…………………………………………………...15
3.4 Installation of Control Board……………………………………………...16
Chapter 4 Installation
4.1 Windows 2000/XP Driver Installation…………………………………….17
4.2 Configuring PenMount Windows 2000/XP Driver………………………21
4.3 Uninstall PenMount Windows 2000/XP Driver………………………….31
Chapter 5 Software
5.1 Software Functions………………………………………………………..32
5.2 Software Function Descriptions……………………………………….…33
ADP-1224A User Manual
4
Appendix A: Board Description & Specifications………………….40
Appendix B: Controller IC Specifications………………………………41
Figures
Figure 1.1: Dimensions of ADP-1224A….……………………………………..6
Figure 1.2: Front View of ADP-1224A………………………………………….7
Figure 1.3: Rear View of ADP-1224A………………………………………….7
Figure 3.1: Bird Eye’s View of Control Board………………………………14
Figure 3.2: Mechanical Drawing of Control Board…………………………14
ADP-1224A User Manual
5
Chapter 1_____________________________
1.1 Specifications
Model No.
Specs
ADP-1224A
LCD
Display Type
21.5” TFT- LCD
Max. Resolution
1920x1080
Max. Color
16.7M
Luminance (cd/m2)
400
ViewAngle
H:170°/ V:160°
Backlight Lifetime
40,000 hrs
System
On Screen Display Control
On the front side
External I/O Port
Default:
VGA Input
AC 100-240V input
Optional:
DVI
Video
S-Video
Touch I/O
3 Pin terminal block DC11~32V input
Touch Screen
Type
Optional Resistive Type
Light Transmission
80%
Power Supply
Power Input
AC 100-240V input, Optional for DC 11~32V
Mechanical
Construction
Steel Housing
IP Rating
Front Panel IP65
Mounting
VESA 100x100 Mount
Dimensions (WxHxD)
557(W)x362(H)x68(D) mm
Environmental
Operating Temperature
0~50 °C
Storage Temperature
-20~60 °C
Storage Humidity
10~90% @40 ﾟC non-condensing
Certificate
Meet CE/FCC Class A
ADP-1224A User Manual
6
1.2 Dimensions
Figure 1.1: Dimensions of the ADP-1224A
ADP-1224A User Manual
7
1.3 Brief Description of the ADP-1224A
The ADP-1224A is a 21.5" TFT LCD Display that comes with viewing angle of 170 (H)
degrees and 160 (V) degrees, and more outstanding features, thus giving you the best
in monitoring and control applications.
The front panel of the display is sealed IP65 rating when it is VESA-mounted in a NEMA
rated cabinet or enclosure. It is optional to be equipped with a resistive touch screen.
Figure 1.2: Front View of the ADP-1224A
Figure 1.3: Rear View of the ADP-1224A
ADP-1224A User Manual
8
1.4 Display Mode
Display Mode
Hori. Sync (KHz)
Vert. Sync. (Hz)
31
60
VGA 640 x 480
38
72
38
75
35
56
SVGA 800 x 600
38
60
48
72
47
75
48
60
XGA 1024 x 768
56
70
60
75
SXGA
1152 x 864
68
75
1280 x 1024
64
60
80
75
Full HD 1920 x 1080
75
60
ADP-1224A User Manual
9
Chapter 2_____________________________
2.1 Front Panel OSD Functions
Auto Adjust Up/Left Down/Right Power
Menu/Entry Power Indicator
Power switch: To turn ON or OFF the power
Shift the icon to the right side or shift it up
Shift the icon to the left side or shift it down
Menu: To enter OSD menu for related icon and item.
Auto Button: One-touch auto adjustment
1.) Getting into Burn-in Mode
Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don’t let them go)
the buttons until the AC power cord is connected and the “RGB” appears on the top left corner
of your screen. Now it can be put into the burn-in mode for changing colors.
2.) Getting Out of Burn-in Mode
Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the
button (If not workable, press the button and don’t let them go) until the AC power cord is
connected. Please don’t let your fingers go until the AC power cord is connected again and the
wording of “RGB”appears on the top left corner of your screen, and wait for 3 seconds. Under the
non-signal entry situation, if is seen, exit is thus successfully made.
Cable Not Connected
ADP-1224A User Manual
10
2.2 OSD Controls
To make any adjustment, select the following:
1. Press (Menu) to show the OSD menu or disable the OSD menu.
2. Select the icon that you wish to adjust with the ( / or +/-) key in the menu.
3. Press (Menu) and then choose the item with the ( / or +/-) key.
4. Press (Menu) and then adjust the quality with the ( / or +/-) key.
1.) If the “RGB”is still on the top left corner of the screen, press to enter “Miscellaneous”and
choose “Reset”, and then Yes, and press . When the screen goes black, disconnect power
and repeat the above steps.
2.) If the “RGB”is not found, disconnect the AC power cord first. Then press the buttons
(don’t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When
“RGB”appears, repeat the above steps.
3.) Functions of OSD Keys
