Arecont Vision MegaBall 2 Manuale utente

1080p 1080p WDR 3Megapixel 3Megapixel WDR 5Megapixel

AV2245PM-D AV2246PM-D AV3245PM-D AV3246PM-D AV5245PM-D

AV2245PM-D-LG AV2246PM-D-LG AV3245PM-D-LG AV3246PM-D-LG AV5245PM-D-LG

AV2245PM-W AV2246PM-W AV3245PM-W AV3246PM-W AV5245PM-W

+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | avsales@arecontvision.com

Made in the USA

1080p–5 Megapixels

MegaBall®2

1.3–5MP H.264 All-in-One Manual Lens or Motorized P-Iris Lens Day/Night Indoor IP Cameras

(WDR option in 1080p and 3MP)

Stylish MegaBall®2 multi-megapixel cameras provide ample

resolution to zoom-in for details in live or recorded video. These

indoor all-in-one solutions integrate a 1080p, 3 or 5-megapixel

camera with fast frame rates and an IR corrected motorized

vari-focal P-iris lens with an adjustable wall mount or ﬂush and

surface mount dome housing. H.264 compression reduces network

bandwidth and storage requirements while delivering full frame

rates and full resolution without sacriﬁcing image quality. Day/Night

functionality allows for 24-hour surveillance. Wide Dynamic Range

(WDR) up to 100dB at full resolution balances light and dark areas in

the same scene (AV2246 and AV3246). Binning mode for increased

low-light sensitivity is available for 3MP and 5MP cameras.

MegaBall®Cameras

Wall/Ceiling Mount

(-W)

Flush Mount

(-D)

Surface Mount

LG Version (-LG – Light Gray)

• Remote Focus/Zoom P-Iris Lens (-PM Models)

• P-Iris Control to Get Best Depth of Field and Image Clarity

(-PM Models)

• Optional True WDR up to 100dB at Full Resolution Available

on Some 1080p and 3MP Models: See Clearly in Shaded

and Bright Light Conditions Simultaneously

• Light Gray and Black Dome Options

• Casino Mode™ Guarantees Continuous 30fps Frame Rate

Required by Gaming Industry Regulations (AV2145 & 2245

Models)

• Binning Mode for Strong Low-Light Performance on 3MP

and 5MP Resolutions

• True Day/Night Functionality with Mechanical IR Cut Filter (DN Models)

• Tamper-Resistant Housing

• Installer Friendly Cable Management, 3-Axis Adjustment, In-Ceiling

and Surface Mount Dome

• PoE and Auxiliary Power: 12–48V DC/24V AC

• Dual Encoder H.264/MJPEG

• Privacy Mask, 1024 Zone, Motion Detection, Flexible Cropping,

Bit Rate Control, Multi-Streaming and Forensic Zooming

• Fast Frame Rates

• PSIA Conformant

• New User-Friendly Webpage

• Reduced Overall System Cost

• Made in the USA

Features:

All-in-One Ball

Solution

Pixel Binning Mode

on 3 and 5MP Models

Dual Encoder

H.264/MJPEG

Wide Dynamic Range

Available on AV2246 and

AV3246 Models

Casino Mode™

Maintains at Least 30fps

on AV2245 Models

True Day/Night

with IR Cut Filter

Integrated Motorized Lens

with Remote Focus

and Zoom

P-Iris Control for

Best Depth of Field

and Image Clarity

+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | [email protected]

Made in the USA

MegaBall®2 Speciﬁcations

Camera Imaging Speciﬁcations

Model AV2245 AV2246 AV3245 AV3246 AV5245

Image Sensor (CMOS) 1080p 1080p* 3MP* 3MP 5MP

Optical Format 1/2.7" 1/3.2" 1/2.5" 1/3.2" 1/2.5"

Pixel Pitch 3μm 2.2μm 2.2μm 2.2μm 2.2μm

Minimum

Illumination

Color (day mode) 0.1 Lux 0.3 Lux 0.3 Lux 0.3 Lux 0.3 Lux

Color Binning (day mode) - - 0.15 Lux 0.15 Lux 0.15 Lu x

B/W (night mode) 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive

Full FOV Resolution 1920 H x 1080 V 1920 H x 1080 V 2048 H x 1536 V 2048 H x 1536 V 2592 H x 1944 V

1/4 Resolution 960 H x 540 V 960 H x 540 V 1024 H x 768 V 1024 H x 768 V 1296 H x 972 V

Dynamic Range 69dB WDR up to 100dB 70.1d B WDR up to 100dB 70.1dB

Maximum SNR 45dB 49dB 45dB 49dB 45dB

Frame Rates

At Max Resolution 31fps (1920 x 1080) 30fps (1920 x 1080) 21fps (2048 x 1536) 21fps (2048 x 1536) 14fps (2592 x 1944)

Cropped

42fps (1280 x 1024) 41fps (1280 x 1024) 29fps (1920 x 1080)

41fps (1280 x 1024)

30fps (1920 x 1080)

41fps (1280 x 1024)

21fps (2048 x 1536)

29fps (1920 x 1080)

41fps (1280 x 1024)

Binning Mode

- - 46fps (1024 x 768)

64fps (960 x 540)

21fps (1024 x 768)

27fps (800 x 600)

31fps (960 x 540)

32fps (640 x 512)

34fps (1296 x 972)

46fps (1024 x 768)

64fps (960 x 540)

Lens Motorized Lens

3-10mm, 1/2.7", F1.3

RZ, RF, P-iris

H-FOV = 117°–36°

3-10mm, 1/2.7", F1.3

RZ, RF, P-iris

H-FOV = 81°–26°

3-10mm, 1/2.7", F1.3

RZ, RF, P-iris

H-FOV = 86°–28°

3-10mm, 1/2.7", F1.3

RZ, RF, P-iris

H-FOV = 86°–28°

3.4-10mm, 1/2.5", F1.4

RZ, RF, P-iris

H-FOV = 102°–35°

Model Speciﬁc Features

Model Resolution Frame Rate Features

AV2245 1080p 31fps - Casino Mode™-

AV2246 1080p 30fps WDR - -

AV3245 3MP 21fps - - Binning

AV3246 3MP 21fps WDR - Binning

AV5245 5MP 14fps - - Binning

Build-to-Order Options

-W Wall Mount Model

-D Dome or Recessed Dome Model

-LG Light Gray Dome

Create Your Model (Example: AV3246-PM-D-LG)

AV 42

Megapixel

Resolution Generation Body Type Compression Lens Mount Light Gray Body

* WDR for AV2246 and AV3246 only.

** “4” Represents MegaBall product line—which are then deﬁned by “W” or “D”

*** LG only available on Dome version

WDR*

Standard

Motorized Lens

P-iris Day/Night

Wall Mount

Dome

Light Gray Dome***

WDR WDR

*effective

Compliance Industry Standard PSIA Conformant

Listings UL (CB)

FCC Compliance 47 CFR 15 Class A

Environmental RoHS, REACH, WEEE

Markings (CE) EN55022 Class A, EN55024,

EN61000-3-2, EN61000-3-3, EN60950

Programmability Remote focus, remote zoom and P-iris control

Motion Detection and privacy mask with 1024 detection zones

Auto adjustment between WDR and LDR modes (WDR models only)

Programmable shutter speed to help control motion blur

Pixel Binning Mode (3MP and 5MP)

Casino Mode™maintains 30fps (AV2245 model)

Flexible Cropping (resolution windowing down to 1x1 pixel for JPEG and

2x2 pixels for H.264)

Low light noise filter control

Bit rate and bandwidth limitation control

Backlight compensation and multi-matrix white balance

50/60Hz selectable flicker control

Electronic pan, tilt, zoom (PTZ) and image flip 180°

Programmable resolution, brightness, saturation, gamma, sharpness, tint

+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | [email protected]

Made in the USA

Data Transmission Compression Type H.264 (MPEG-4, Part 10)/Motion JPEG

21 levels of quality

Transmission Protocols RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP

100Base-T Ethernet Network Interface

Multi-Streaming 8 non-identical streams

Environmental Operating temperature -5°C (-23°F) to +50°C (122°F)

Humidity 0% to 90% (non-condensing)

Stable image temperature 0°C (32°F) to +50°C (122°F)

Storage temperature -20°C (-4°F) to +60°C (140°F)

General Electrical Alarm Input/Output General purpose opto-coupled

Power Over Ethernet PoE 802.3af, Class 2

Auxiliary Power 12–48V DC, 24V AC

Max Power Consumption AV2245 5.9 Watts DC Power

AV3245 / AV5245 6.3 Watts DC Power

AV2246 / AV3246 6.8 Watts DC Power

Mechanical Casing -W Die-cast aluminum 3" metal ball and mount

-D Plastic surface/in-ceiling dome w/ Acrylic bubble

Gimbal Easy 3-axis camera adjustment w/360° pan, 90° tilt and

360° z-axis

Dimensions -W Ø 3" (76.2mm) x 6.15" H (156.2mm)

-D (in-ceiling) Ø 5.1" (130mm) x 1.74" H (44mm)

-D (surface

mount w/ bubble) Ø 5.1" (130mm) x 3.85" H (98mm)

Camera Unit Packaged

Weight -W 1.2lbs (0.54kg) 2.0lbs (0.9kg)

-D 1.2lbs (0.54kg) 1.9lbs (0.86kg)

Dome Color -LG Light Gray Dome

Accessories D4S-WMT-B Black wall mount with 3/4"NPT standard

D4S-CMT-B Black ceiling mount with 3/4"NPT standard

D4S-WMT Light Gray Wall mount with 3/4"NPT standard

D4S-CMT Light Gray Ceiling mount with 3/4"NPT standard

SV-EBA Light Gray Electrical box adapter

SV-JBA Light Gray Junction box adapter

MegaBall®2 Speciﬁcations

-W

-D

(in-ceiling)

-D

(w/Bubble)

-W

-D

(in-ceiling)

-D

6.15"

(156.2mm)

Ø 3"

(76.2mm)

Ø 5.1"

(130mm)

Ø 5.1"

(130mm)

Ø 5.1"

(130mm)

Ø 5.1"

(130mm)

1.74"

(44mm)

3.85"

(98mm)
