ARGON18 E-117 TRI Disc 317A Manuale utente

E-117 TRI Disc 317A / 317B : ASSEMBLY GUIDE

Valid for MY2020 E-117 Tri Disc 317A / 317B

Revision 2.0 - 02.10.2019

For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High end components,

particularly carbon parts, need extra care when assembled. These components must be installed using a calibrated torque

wrench to make sure every bolt is at the right torque setting to prevent damage.

Table of Contents

My E-117 Tri Disc

Date of purchase:

Retailler:

Size:

Serial Number:

1. Tools Needed & First Aid Kit .......................................... 3

2. E-117 TRI Disc 317A Frameset Parts .................................. 4

3. E-117 TRI Disc 317A Parts’ SKUs and Descriptions*.................... 5

4. Seat Post Clamp Installation .......................................... 6

5. Seat Post Installation................................................. 7

6. Seat Post Installation................................................. 8

7. Frame Inspection .................................................... 9

8. Rear Derailleur Hanger Adjustment ..................................10

9. Front Derailleur Hanger Adjustment .................................11

10. Headset Installation ...............................................12

11. Cable Housing Installation for mechanical drive train................15

12. Cable Housing Installation for electrical drive train..................16

13. Cable Housing Installation .........................................17

14. Rear derailleur grommet ...........................................19

15. Electronic Drive-train Installation...................................20

16. Saddle Adjustment ................................................21

17. Troubleshooting / Tips .............................................22

18. Min/Max Seat Post Insertion .......................................23

Tools needed for assembly

1: Bearing Cup Press (Park Tool HHP-2)

2: Allen Key Set

3: Grease

4: Utility Pick Set (Park Tool Item # UP-SET)

5: Clean Rags

6: Derailleur Hanger Alignment Gauge (Park Tool Item # DAG-2,2)

7: Cables and Housing Cutter

8: Carbon Paste

9: Loctite #242 or #243

10: Torque Wrench

First Aid Kit: Essential parts to always have on hand

IN CASE OF EMERGENCY…THIS MIGHT SAVE YOUR RIDE!

1: Spare rear dropout (SKU: 80832 for Direct Mount and 80802 for regular)

2: Spare brake pads corresponding to your caliper and disc model

3: Seat clamp (SKU: 80423, 80422)

IMPORTANT: the E-117 Tri Disc’s seat clamp (1.5-1.6) is not the same as the Nitrogen

1. Tools Needed & First Aid Kit

SKU: 80422

SKU: 80423

SKU: 80802SKU: 80832

2. E-117 TRI Disc 317A Frameset Parts

Images are for reference only.

Argon 18 reserves the right to modify/change parts of the frameset at any moment without prior notice.

31.5

1.18

1.19

1.111.91.101.19

1.7

1.8.2

1.13

1.3.2

1.3.1

1.4

1.12

1.21

1.2

1.8.1

1.17

1.14

1.16

1.15

1.3.3

1.6

3.2

Complete headset

Not shown on the image:

- Di2 battery holder

- Foam liner for hydraulic hoses

3. E-117 TRI Disc 317A Parts’ SKUs and Descriptions*

*Except for the frame itself, which is not sold as a spare part, all parts can be ordered by referring to their respective SKU number.

No. Name A18 SKU# Qty

1 E-117 TRI DISC FRAME N/A 1

1,2 FRONT DERAILLEUR HANGER (W. SCREWS) 38882 1

1,3,1 REAR DERAILLEUR HANGER STANDARD

80802

1,3,2 REAR DROPOUT DS 1

1,3,3 REAR DERAILLEUR HANGER SCREW M4x12 FLAT HEAD 1

1,4 REAR DERAILLEUR HANGER DIRECT MOUNT 80832 1

1,5 SEAT POST COLLAR BASE W. SCREW M8X12 80423 1

1,6 SEAT POST COLLAR WEDGE W. SCREW M3X8 80422 1

1,7 BB CABLE GUIDE 80492 1

1,8,1 BB CABLE COVER 80159 1

1,8,2 BB CABLE COVER SCREW M4x6 2

1,9 TT GROMMET MECH 36656 1

1,10 TT GROMMET Di2 36670 1

1,11 TT GROMMET WIRELESS 81094 1

1,12 FD CABLE ENTRY GROMMET 80164 1

1,13 FD CABLE ENTRY PLUG 80826 1

1,14 ROUND GROMMET MECH 80985 1

1,15 ROUND PLUG 80804 1

1,16 ROUND GROMMET DI2 80805 1

1,17 OBLONG HOSE GUIDE 80551 1

1,18 SCREW FOR BOTTLE CAGE AND FRONT DERAILLEUR

M5x16 ROUND HEAD

81003 5

1,19 PLASTIC PLUG M5 80264 3

2 E-117 TRI DISC FORK FK.E117T_D.317A 1

3 E-117 TRI ASP-7050 SEAT POST (INCL. SHAFT + HEAD) SP.E117T.285A 1

3,2 RITCHEY SEAT POST HEAD N/A in spare part; Available at ritcheylogic.com 1

3,3 DI2 BATTERY HOLDER 80167 1 kit

4 HEAD SET NO.37-E 80096 1

5 A18 REAR THRU AXLE M12x161 81053 1

6 A18 FRONT THRU AXLE M12x119 81052 1

7 A18 THRU AXLE LEVER 81054 1

8 FOAM LINER FOR HYDRAULIC HOSE 80811 1

4. Seat Post Clamp Installation

1. Apply a drop of blue Threadlocker

(n. 242) on the bolt’s thread

2. Apply grease on the seat post clamp

and on the screws as shown

3. Assemble the seat post clamp with

the small screw, allowing the parts to

move freely

4. Place the seat post clamp inside the

frame, holding it to prevent it falling

inside the frame

5. Insert the seatpost (3), on which

some carbon ber assembly paste has

been applied

6. Position the seatpost to the desired

height

7. Tighten the set screw at max. 5.5Nm

IMPORTANT: The E-117 Tri Disc’s seat

clamp is not the same as the Nitrogen

GREASE

THREADLOCKER

BLUE (n. 242)

GREASE

CARBON FIBER

ASSEMBLY PASTE

5.5 Nm

Thighten lightly, then unscrew a

1/4 turn to keep the wedge free to

slide

1,5

1,6 THREADLOCKER

BLUE (n. 242)

5. Seat Post Installation

1. Unscrew main bolt (A) as far as

possible without fully removing it from

the lock nut.

2. Install the saddle rails into the

seatpost clamp (B).

3. Slide saddle clamp (B) onto rocker (C).

4. Tighten the bolt up at 12Nm.

See p.23 for saddle adjustment.

IMPORTANT:

The E-117 Tri Disc’s saddle rail clamp is

made for metal and round-shaped saddle

rails (For part numbers contact Ritchey).

For other types of saddle rails, please

refer to the Tips and Troubleshooting

section of this Assembly Guide (p.22).

12Nm

CARBON

FIBER

ASSEMBLY

PASTE

5Nm

6. Seat Post Installation

The Di2 battery is hidden in the

seatpost; use the Di2 battery holder

(3.3) to  x the battery correctly. Apply a

slight amount of grease on both parts.

GREASE

3.3

CARBON

FIBER

ASSEMBLY

PASTE

7. Frame Inspection

Parts installed on the frame Description Screw Torque Detail

type Nm

Front derailleur hanger Screw (2) 5mm 4Nm Threadlocker

Rear derailleur hanger Screw (1) 4mm 2Nm Threadlocker

Bottle cage Screw (4) 5mm 3Nm Grease

Bottom bracket cover Screw (2) 4mm 2.5Nm Grease

IMPORTANT:

The following parts are assembled on the frame. When assembling the bike, you will need to adjust these parts according to their

torque specications.

BEFORE ASSEMBLING YOUR NEW E-117 TRI DISC, MAKE SURE THAT YOU HAVE ALL THE FOLLOWING:

1. Brakes hoses, gears cables and housing set

2: Frameset parts checklist (see p.5)

3: All the necessary bolts (refer to Frameset Parts, p.5)

WHEN ASSEMBLING YOUR NEW E-117 TRI DISC, MAKE SURE YOU FOLLOW THIS PROCEDURE:

4: Inspect the frame for cosmetic aspect (scratches, bumps, cracks, paint defect, etc.)

5: For reference, check serial number and write it on p.2

6: For optimal shifting performance, use a dropout alignment gauge to make sure that the drive-side dropout is straight.

8. Rear Derailleur Hanger Adjustment

1. Select the correct rear derailleur hanger depending on the type of derailleur

that you have.

- Direct mount (1.4)

- Regular mount (1.3.1)

2. Make sure to align the rear derailleur hanger using a Derailleur Hanger

Alignment Gauge like Park Tool Item #DAG-2,2.

For any assistance, visit Park Tool’s website:

www.parktool.com/product/derailleur-hanger-alignment-gauge-dag-2-2

1.4

1.3.1

1.3.2

1.3.3

1.3.2

1.3.3
