ARGON18 RADON Manuale utente

RADON : ASSEMBLY GUIDE

Révision 3.0 - 06-02-2016

Assembly overview. . . . . . . . . . . . . . . . . . . . . . . ..................2

1. Frame inspection . . . . . . . . . . . . . . . . . . . . . ...................3

2. Cable housing installation . . . . . . . . . . . . . . . . . . . . . . . . ......4-6

3. Saddle adjustment . . . . . . . . . . . . . . . . . . . . . . . .............7-8

4. Parts listing. . . . . . . . . . . . . . . . . . . . . . . . ...................9-10

For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High-end components,

particularly carbon parts, need extra care when assembled. Those components must be installed using a calibrated torque

wrench to make sure every bolt is at the right torque setting to prevent damage.

RADON : Table of contents

2. Cable housing installation

IMPORTANT NOTICE: It is easier to install the

cables and cable housings before the bearings.

4. Parts listing

2

RADON : Assembly overview

1. Frame inspection 3. Seatpost adjustment

3

RADON : 1. Frame inspection

Parts installed on the frame Description Screw Tork Detail

type Nm

1 Seatpost, Ø 31.6mm Seatpost Carbon paste

2 Rear derailleur hanger Screw (2) 3mm 4Nm Loctite

3 Bottle cage Screw (4) 4mm 3Nm Grease

4 Seatpost collar Clamp 4mm 6Nm Grease

5 Bottom bracket cable guide Screw 5mm 3Nm Grease

When assembling a new frame, be sure to check if the following parts are assembled correctly.

4

RADON : 2. Cable housing installation

A : metal cap

B : plastic cap

A

A

A

B

B

B

B

1. Install the front and rear derailleur

cable starting at the top of the down

tube.

2. Install the rear brake cable starting at

the head tube.

For the derailleur and brake housing,

measure a sucient length of housing

to be able to turn the handlebar both

ways correctly.

5

RADON : 2. Cable housing installation (continued)

Rear brake cable housing

Font section: Measure the necessary cable housing

to ensure proper rotation of the handlebar. Insert

the cable through the shifter, then insert the cable

housing into the top tube cable stopper.

Rear section: Pass the cable through the rear

cable stopper. Mesure the rear housing correctly

to avoid interference with the rider’s left leg. Fix

the cable to the brake according to the brake

manufacturer assembly guide.

6

RADON : 2. Cable housing installation (continued)

Front & rear derailleur: Pass the cables under the downtube

then into the cable guide (5).

5

8

RADON : 3. Saddle adjustment

7

9.1 Install the saddle on the rocker (3f)

and tighten the rail clamp (3g) using

the screw (3d)

9.2 Adjust the angle, the oset of the

saddle and tighten the bolt (3b).

9.3 The rocker and the rail clamp (3f-

3g) can be ipped to change the saddle

oset.

GREASE

3a

3f

3d

3b

3e

GREASE

GREASE

3g

6Nm

3c

RADON : 3. Saddle adjustment

8

Seat clamp oset (5mm) by ipping

the rail clamp (3g) and rocker (3f).

3f3f

3g 3g

RADON : 4. Parts

Images are for reference only. Proportions are not accurate.

3a

3e

3d

3b

3f

3c

2

4a

5

6

8

4b

3 7

9
