Asus ZenFone 3 Max Manuale utente

User Guide

E12086

15060-xxxxxxxx

RevisedEditionV3/September2016

Model: ASUS_X008D/ASUS_X008DA/ASUS_X008DB/

ASUS_X008DC

Beforeyou start,ensurethatyou have readallthe

safetyinformation and operating instructions in this

UserGuidetopreventinjuryordamagetoyour

device.

NOTE:

Forthelatestupdatesandmoredetailed

information, please visit

www.asus.com

Front features

Proximity sensor

Receiver

Front

camera

LED indicator

Touch screen

display

Side features

Audio jack

NanoSIM /

microSIM

card slot

Eject

hole

Volume

key

Power

key

Microphone

Micro USB port

Rear features

Flash

Rear camera

Fingerprint

sensor

NOTES:

•

TheNano SIM/microSIMcard slotssupport

GSM,WCDMA,FDD-LTE,andTDD-LTE

network bands.

•

ThemicroSDcardslotsupportsmicroSDand

microSDXC card formats.

Charging your ASUS Phone

TochargeyourASUSPhone:

ConnecttheUSBconnectorintothepower

adapter’s USBport.

ConnecttheotherendoftheUSB cabletoyour

ASUS Phone.

Plug thepoweradapterintoawallsocket.

IMPORTANT!

•

WhenusingyourASUSPhonewhileitispluggedto

apoweroutlet,thegroundedpoweroutletmustbe

neartotheunitandeasily accessible.

•

WhenchargingyourASUSPhonethroughyour

computer,ensurethatyouplugtheUSBcableto

your computer’s USBport.

•

Avoid chargingyourASUSPhoneinan

environment with ambient temperature of above

35oC (95oF).

NOTES:

•

Useonlythepoweradapterthatcamewithyour

device.Usingadifferentpoweradaptermay

damage yourdevice.

•

UsingthebundledpoweradapterandASUSPhone

signalcabletoconnectyourASUSPhonetoa

poweroutletisthebestwaytochargeyourASUS

Phone.

•

UsetheASUS18W/10WpoweradapterandASUS

USBcable togetthebest chargeexperience when

yourASUSPhoneisinsleepmode.

•

Theinputvoltagerangebetweenthewalloutletand

thisadapterisAC100V-240V.Theoutputvoltage

oftheUSBcableis+9V 2A,18W /+5V 2A,10W.

InstallingaNanoSIM/microSIM/

microSD card

ToinstallaNanoSIM/microSIM/microSDcard:

1. Push thebundled

ejectpinintothehole

onthecardslot to

ejectthetrayout.

2. InserttheNanoSIM,microSIM,ormicroSD

card into the appropriateslot.

Micro-SIM1

Micro

3. Push the trayto

closeit.

IMPORTANT!

Both SIMcard slotssupport4G/3G/2G

networkband.Butonlyone SIMcard can connectto4G

serviceatatime.

CAUTION!

•

Donotusesharptoolsorsolventonyourdeviceto

avoidscratchesonit.

•

UseonlyastandardMicroSIMorNanoSIMcard

onyourASUSPhone.

• For more regulatory information and E-labels,

checkonyourdevice fromSettings>About>

RegulatoryInformation.

Federal Communications

Commission Statement

Thisdevice complieswithpart15oftheFCCRules.

Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,

and(2)thisdevicemustacceptanyinterference

received,includinginterferencethatmaycause

undesiredoperation.

Changes or modifications not expressly approved by

thepartyresponsibleforcompliancecouldvoidthe

user‘s authority to operate theequipment.

Thisequipmenthasbeentestedandfoundto

complywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules. Theselimits

aredesignedtoprovidereasonableprotection

against harmful interference in aresidential

installation. This equipment generates, uses and can

radiateradiofrequencyenergyand,ifnotinstalled

andusedinaccordancewiththeinstructions, may

cause harmful interference to radiocommunications.

However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthis

equipmentdoes cause harmfulinterference to radio

or television reception, which can bedetermined

byturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyone

ormoreofthefollowingmeasures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

Connecttheequipmentintoanoutletona

circuitdifferentfromthattowhichthereceiver

is connected.

Consultthedealeroranexperiencedradio/TV

technician for help.

Theantenna(s)usedforthistransmittermustnotbe

co-locatedoroperatedinconjunctionwithanyother

antenna or transmitter.

Thecountrycodeselectionisfornon-USmodels

onlyandisnot availabletoallUSmodels.PerFCC

regulation,allWiFiproductsthataremarketedinUS

mustbefixedtoUS-operatedchannelsonly.

RF Exposure Information (SAR)

This device has been tested and meets applicable

limits for Radio Frequency (RF) exposure.

Specific Absorption Rate (SAR) refers to the rate at

which the body absorbs RF energy. SAR limits are

1.6 Watts per kilogram (over a volume containing a

mass of 1 gram of tissue) in countries that follow the

United States FCC limit and 2.0 W/kg (averaged

over 10 grams of tissue) in countries that follow the

Council of the European Union limit. Testsfor SAR

are conducted using standard operating positions

with the device transmitting at its highest certified

power level in all tested frequency bands.

To reduce exposure to RF energy, use a hands-free

accessory or other similar option to keep this device

away from your head and body. Carry this device at

least 10 mm away from your body to ensure

exposure levels remain at or below the as-tested

levels. Choose the belt clips, holsters, or other

similar body-worn accessories which do not contain

metallic components to support operation in this

manner. Cases with metal parts may change the RF

performance of the device, including its compliance

with RF exposure guidelines, in a manner that has

not been tested or certified, and use such

accessories should be avoided.

Canada, Industry Canada (IC)

Notices

ThisdevicecomplieswithIndustryCanada’s

licence-exempt RSS standard(s). Operationis

subjecttothefollowingtwoconditions:

(1)

Thisdevicemaynotcauseinterference;and

(2)

Thisdevicemustacceptanyinterference,

includinginterferencethatmaycause

undesiredoperationofthedevice.

LeprésentappareilestconformeauxCNR

d’IndustrieCanadaapplicablesauxappareilsradio

exemptsde licence.L’exploitation est autorisée aux

deux conditions suivantes:

(1)

l’appareilnedoitpasproduiredebrouillage,et

(2)

l’utilisateurdel’appareildoitacceptertout

brouillageradioélectriquesubi,mêmesile

brouillage est susceptible d’en compromettrele

fonctionnement.

Radio Frequency (RF) Exposure Information

TheradiatedoutputpoweroftheWirelessDeviceis

belowtheIndustryCanada(IC)radiofrequency
