Asus AX5400 Manuale utente
Quick Start Guide
TUF-AX5400
TUF-AX5400
TUF Gaming AX5400 Dual Band Wi-Fi 6 Router
TUF Gaming AX5400 Dual Band Wi-Fi 6 Router
¨
A18187-1 / First Edition / April 2021
A18187-1_TUF-AX5400_booklet_QSG.indb 1A18187-1_TUF-AX5400_booklet_QSG.indb 1 2021/4/15 18:03:582021/4/15 18:03:58
Table of contents
Table of contents
English.........................................................................................................................................................................3
繁體中文 ....................................................................................................................................................................9
Bahasa Indonesia.....................................................................................................................................................15
Bahasa Melayu..........................................................................................................................................................21
ไทย...............................................................................................................................................................................27
Tiếng Việt....................................................................................................................................................................33
A18187-1_TUF-AX5400_booklet_QSG.indb 2A18187-1_TUF-AX5400_booklet_QSG.indb 2 2021/4/15 18:03:582021/4/15 18:03:58
3
English
A quick look at TUF-AX5400
A quick look at TUF-AX5400
WAN (Internet) LED Power button
LAN 1 ~ 4 LEDs USB 3.2 Gen 1 port
5GHz LED LAN 1 ~ 4 ports
2.4GHz LED WAN (Internet) port
Power LED WPS button
Power (DC-IN) port Reset button
Package contents
Package contents
TUF-AX5400 Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
A18187-1_TUF-AX5400_booklet_QSG.indb 3A18187-1_TUF-AX5400_booklet_QSG.indb 3 2021/4/15 18:03:592021/4/15 18:03:59
4
English
Position your wireless router
Position your wireless router
For optimal wireless transmission between the wireless router and connected
wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum wireless coverage
for the network devices.
• Keep the wireless router away from metal obstructions and away from direct
sunlight.
• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,
2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,
heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other
industrial equipment to prevent signal interference or loss.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
• To ensure the best wireless signal, orient the six non-detachable antennas as
shown in the drawing below.
NOTES:
• Use only the adapter that came with your package. Using other
adapters may damage the device.
• Specications:
DC Power adapter DC Output: +12V with 2.5A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
A18187-1_TUF-AX5400_booklet_QSG.indb 4A18187-1_TUF-AX5400_booklet_QSG.indb 4 2021/4/15 18:03:592021/4/15 18:03:59
5
English
Preparing your modem
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a
battery backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your
Internet Service Provider (ISP) to properly
congure the router.
2. Connect your modem to the router with
the bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure
the connection is active.
Unplug
A18187-1_TUF-AX5400_booklet_QSG.indb 5A18187-1_TUF-AX5400_booklet_QSG.indb 5 2021/4/15 18:04:002021/4/15 18:04:00
6
English
Setting up your TUF-AX5400
Setting up your TUF-AX5400
You can set up your router via wired or
wireless connection.
A. Wired connection
1. Plug your router into a power outlet
and power it on. Connect the network
cable from your computer to a LAN
port on your router.
2. The web GUI launches automatically when you open a web browser. If it does
not auto-launch, enter http://router.asus.com.
3. Set up a password for your router to prevent unauthorized access.
B. Wireless connection
1. Plug your router into a power
outlet and power it on.
Laptop
Tablet
Smart phone
Wall Power Outlet
TUF-AX5400
Modem
LINE LAN RESET PWR
Power
WAN
a
c
b
Wall Power Outlet
TUF-AX5400
Modem
LINE LAN RESET PWR
Laptop
Power
WAN
LAN
a
d
c
b
A18187-1_TUF-AX5400_booklet_QSG.indb 6A18187-1_TUF-AX5400_booklet_QSG.indb 6 2021/4/15 18:04:002021/4/15 18:04:00
7
English
2. Connect to the network with SSID shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign
a password.
ASUS router
ASUS_XX
Wi-Fi Name (SSID): ASUS_XX
* XX refers to the last two digits of 2.4GHz
MAC address. You can nd it on the label
on the back of your router.
3. You can choose either the web GUI or ASUS Router app to set up your router.
a. Web GUI Setup
•
Once connected, the web GUI launches automatically when you open a
web browser. If it does not auto-launch, enter http://router.asus.com.
•
Set up a password for your router to prevent unauthorized access.
A18187-1_TUF-AX5400_booklet_QSG.indb 7A18187-1_TUF-AX5400_booklet_QSG.indb 7 2021/4/15 18:04:002021/4/15 18:04:00
8
English
b. App Setup
Download ASUS Router App to set up your
router via your mobile devices.
•
Turn on Wi-Fi on your mobile devices
and connect to your router’s network.
•
Follow ASUS Router App setup
instructions to complete the setup.
ASUS Router
ASUS
Router
Remembering your wireless router settings
• Remember your wireless settings as you complete the router setup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQ
FAQ
1. Where can I nd more information about the wireless router?
• Technical support site: https://www.asus.com/support
• Customer hotline: refer to the Support Hotline section in this Quick Start
Guide.
A18187-1_TUF-AX5400_booklet_QSG.indb 8A18187-1_TUF-AX5400_booklet_QSG.indb 8 2021/4/15 18:04:002021/4/15 18:04:00
9
繁體中文
認識您的無線路由器
認識您的無線路由器
WAN（網際網路）指示燈 電源開關
LAN 1 ~ 4 LED 指示燈 USB 3.2 Gen 1 連接埠
5GHz 指示燈 LAN 1 ~ 4 網路連接埠
2.4GHz 指示燈 WAN （網際網路）連接埠
電源指示燈 WPS 按鈕
電源（DC-IN）連接埠 重置按鈕
產品包裝內容
產品包裝內容
TUF-AX5400 無線路由器 電源變壓器
RJ-45 網路線 快速使用指南
A18187-1_TUF-AX5400_booklet_QSG.indb 9A18187-1_TUF-AX5400_booklet_QSG.indb 9 2021/4/15 18:04:012021/4/15 18:04:01
10
繁體中文
放置您的路由器
放置您的路由器
為獲得無線路由器與所連線的網路裝置之間傳送最佳無線訊號，請確認以下幾點：
• 建議將路由器放置在中心區域，以獲得最佳無線訊號覆蓋範圍。
• 請勿將裝置放在靠近金屬物品與陽光直射的地方。
• 請遠離其它 802.11g 或20MHz Wi-Fi 裝置、2.4GHz 電腦周邊裝置、 藍牙裝置、無線室內
電話、傳送器、重型發動機、日光燈、微波爐、電冰箱與其他工業裝置，以防止訊號干
擾或減損。
• 請經常更新至最新版本韌體。您可以登入華碩官網 https://www.asus.com/tw/ 獲得最新
韌體。
• 請依據下圖所示擺放路由器上的六根非可拆式天線以獲得最佳無線訊號覆蓋範圍。
注意：
• 請僅使用包裝中的電源變壓器。使用其他類型的電源變壓器可能會造成裝置損毀。
• 規格：
直流電源變壓器 DC 輸出： +12V 電壓，支援最大 2.5A 電流
運作溫度 0~40°C儲存溫度 0~70°C
運作濕度 50~90% 儲存濕度 20~90%
A18187-1_TUF-AX5400_booklet_QSG.indb 10A18187-1_TUF-AX5400_booklet_QSG.indb 10 2021/4/15 18:04:012021/4/15 18:04:01
