Asus GigaX1024X Manuale utente

Index

1.English ...........................................1

2.繁體中文 ..........................................9

简体中文

..........................................17

4.日本語 ...........................................25

5. ..........................................33

English

User Guide

GigaX1024X

2 ASUS GigaX1024X

English

Introduction

The GigaX1024X rack mountable switch provides non-blocking, wire-speed

performance to meet your intensive network needs. This switch comes with

24 Fast Ethernet ports with auto-sensing and auto MDI/MDIX capabilities.

With easy connectivity, ﬂow control, and QoS, GigaX1024X is guaranteed to

enhance your network performance and productivity.

Features

• 24 x 10/100 Mbps RJ-45 ports

• Up to 200Mbps transmit speed for all ports in full-duplex mode

• Switch capacity: 4.8Gbps Forwarding rate: 3.6Mpps

• Plug and play – auto MDI/MDIX, and auto-sensing for speed and

duplex mode on all ports

• Flow control schemes (802.3x in full-duplex mode) to support zero loss

under temporary network congestion

• Head of Line (HOL) blocking preventions

• IEEE802.1p/TOS/DS supported to meet QoS requirements

• 8K MAC address learning and aging for concurrent connections to

8K nodes

• Easy-to-read LEDs provide quick indication of link status and speed

• Fan-less design for quiet operation

• Desktop or rack mount placement options

Package contents

Before installing the GigaX1024X switch, check your package for the

following items.

• GigaX1024X switch

• Power cable

• User guide

• Mounting kit (2 brackets and 6 screws)

NOTE. Contact your retailer if any of the items is damaged or missing.

ASUS GigaX1024X3

English

Technical speciﬁcations

Physical Dimensions

444 mm (W) x 180mm (D) x 43.5mm (H)

Environmental Ranges

Operating temperature 0ºC ~ 50ºC (32ºF to 122ºF)

Storage temperature -25ºC ~ 70ºC (-13ºF to 158ºF)

Operating humidity 0 to 90%

Storage humidity 0 to 90%

Operating altitude up to 15,000 ft (4,500m)

Storage altitude up to 40,000 ft (12,000m)

Power

Input 100V ~ 240V AC/50-60Hz

Power Consumption 12 Watts

Certiﬁcation

FCC Class A, CE, CCC

4 ASUS GigaX1024X

English

Rear panel

Front panel

Power connector

LED Color Status Description

SYSTEM Green ON The power is ON

STATUS Green ON A device is connected to the port

Flashing Transmitting data

OFF No device connected

SPEED Green ON 100Mbps

OFF 10Mbps

The front panel of GigaX1024X contains twenty-four 10/100Mbps RJ-45

Ethernet ports and LED indicators that shows the working condition of the

switch.

Table 1 LED indicators

The rear panel of GigaX1024X contains a power connector.

ASUS GigaX1024X5

English

Placement options

Placing the switch on a ﬂat surface

Place the GigaX1024X on a ﬂat and stable surface. Make sure the location

meets the operating environment speciﬁcation. See page 3 for details.

NOTE. The length of the UTP Category 5 cable length should not

exceed 100 meters (328 feet).

Mounting the switch on a rack

You may also mount the GigaX1024X switch on a rack with the supplied

mounting brackets and screws.

To mount the switch on a rack:

1. Locate three screw holes on both sides of the switch.

2. Align the mounting brackets with the switch screw holes.

3. Secure the mounting brackets with three screws supplied in the

mounting kit on both sides of the switch.

4. Place the switch in a 19-inch rack, then secure both sides with four

rack mount screws.

NOTE. The rack mount screws are not supplied.

6 ASUS GigaX1024X

English

Connecting network devices

To connect network devices to the GigaX1024X switch:

1. Connect one end of the Ethernet cable to an Ethernet port on the

switch front panel. Connect the other end to the Ethernet port of the

network device. Repeat this step to connect additional network devices.

2. Plug one end of the power cable to the power connector on the switch

rear panel, then plug the other end to an electrical outlet.

3. The Power LED and LED indicators for active Ethernet ports light up to

indicate that the device is on and in use. Refer to the front panel Label/

LED table in page 4 for LED indications.

NOTES

• We recommend the use of Category 5 Ethernet straight-through

cables to ensure proper connections between the switch and other

network devices.

• You may use the switch Ethernet ports as an uplink to another

switch, hub, bridge or repeater. The switch is capable of detecting

either cross-over or straight-through cables.

POWER

ASUS GigaX1024X7

English

Troubleshooting

This troubleshooting guide provides answers to some common problems

which you may encounter while installing and/or using the ASUS

GigaX1024X switch. These problems requires simple troubleshooting that

you can perform by yourself. Contact the ASUS Technical Support if you

encounter problems not mentioned in this section.

Problem Action

The POWER LED does not

light up.

Check if the power cable is properly

connected to the switch and to

an electrical outlet with a correct

voltage output.

• Check if the Ethernet cable is

properly connected to the switch

and to the network device.

• Make sure that the switch

and your network device are

powered on.

• Check if the Ethernet cable

is sufﬁcient to your network

requirements. Make sure you

use Category 5 cables. 10Mbit/

sec cables may work with lower

quality cables.

The STATUS/SPEED LED

does not light up even

after an Ethernet cable is

connected.

8 ASUS GigaX1024X

English

Glossary

10BASE-T 10 Mbps Ethernet over twisted pair cable (Category 3).

100BASE-T 100 Mbps Ethernet over twisted pair cable (Category 5)

1000BASE-T 1000 Mbps Ethernet over twisted pair cable (Category 5)

Auto MDI/MDIX Allows network connections using either straight or cross

cable.

Ethernet The most commonly installed computer network

technology, usually using twisted pair wiring. Ethernet

data rates are 10 Mbps, 100 Mbps, and 1000 Mbps.

Mbps Abbreviation for Megabits per second, or one million bits

per second. Network data rates are often expressed in

Mbps.

network A group of computers that are connected together,

allowing them to communicate with each other and

share resources, such as software, ﬁles, etc. A network

can be small, such as a LAN, or very large, such as the

Internet.
