Atlas Copco POWER FOCUS 6000 Manuale utente
MicroTorque
Printed Matter No. 9839 1629 01 Electric screwdriver
Publication Date 2019-03-29
Quick Guide
This quick start guide is applicable for the following products:
■ETD MT
■QMC
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
Quick start guide EN MicroTorque
2© Atlas Copco Industrial Technique AB - 9839 1629 01
Quick start guide
1. Connect the tool to MT Focus 6000 using a MT tool cable.
2. Connect MT Focus 6000 to power supply. Make sure to switch on the power supply to start the con-
troller.
WARNING Risk of Injury
The tool may rotate when the system is switched on and the tool is initializing.
►Keep body parts, hair and clothing away from the tool.
3. Connect MT Focus 6000 to a PC with a USB cable or an ethernet cable.
4. Open ToolsTalk MT on the PC. The following are the commonly used configurations to start up:
■Buttons and lights configurations:
■Tool configurations:
■Controller configurations:
For more information, refer to ToolsTalk MT Configuration Manual (98390526).
5.
Create a Pset in ToolsTalk MT to set up a tightening program.
For more information, refer to ToolsTalk MT Configuration Manual (98390526).
6. Mount the bit and activate Pset. Adjust Pset settings if needed.
Refer to PI for instructions of mounting the bit.
Original instructions
Atlas Copco Industrial
Technique AB
SE-10523 STOCKHOLM
Sweden
Telephone: +46 8 743 95 00
Telefax: +46 8 644 90 45
www.atlascopco.com
© Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any
unauthorized use or copying of the contents or part thereof is prohibited. This
applies in particular to trademarks, model denominations, part numbers and
drawings. Use only authorized parts. Any damage or malfunction caused by the
use of unauthorized parts is not covered by Warranty or Product Liability.
Out of respect to wildlife and nature, our technical literature is printed on
environmentally friendly paper.
