ATTO ExpressSAS Host and RAID Adapter

Installation and Operation Manual

ExpressSAS H1208 HBA

ExpressSAS H1280 HBA

ExpressSAS H120F HBA

ExpressSAS H12F0 HBA

ExpressSAS H1244 HBA

ExpressSAS H1248 HBA

ExpressSAS H1288 HBA

ExpressSAS H644 HBA

ExpressSAS H608 HBA

ExpressSAS H680 HBA

ExpressSAS H60F HBA

ExpressSAS R644 RAID Adapter

ExpressSAS R608 RAID Adapter

ExpressSAS R680 RAID Adapter

ExpressSAS R60F RAID Adapter

ATTO Technology, Inc.

155 CrossPoint Parkway

Amherst, New York 14068 USA

www.attotech.com

Tel (716) 691-1999

Fax (716) 691-9353

Sales support: [email protected]

Technical support: Monday -- Friday, 8am-6pm EST

[email protected]

(716) 691-1999 ext. 242

holders. No part of this manual may be reproduced in any form or by any means without the express written

permission of ATTO Technology, Inc.

4/2015

.. ... ..... ....... ........ .... . . ........ ...... ..... .... ..... ... ............ .......... ............ ...,,,,,,,, ,,,,,,,,,,,,,,,,

PRMA-0389-000MD

Contents

1 ATTO Provides Storage Solutions............................................................................. 1

ExpressSAS 12Gb Host HBAs

ExpressSAS 6Gb Host HBAs

ExpressSAS 6Gb RAID Adapters

2 Install Drivers................................................................................................................9

Downloading drivers from the ATTO website

Windows

OS X (ExpressSAS H6xx and R6xx only)

Linux

VMware ESXi 5.x (ExpressSAS H6xx only)

VMware ESX/ESXi 4.1 (ExpressSAS H6xx only)

VMware ESX 3.5 (ExpressSAS H6xx only)

3 New Windows OS Installation...................................................................................12

4 New OS X Installation.................................................................................................13

5 Install Hardware......................................................................................................... 17

Installing the Adapter

Installing CacheAssure (ExpressSAS R6xx only)

Non-Volatile (NV) Memory Card Installation

Power Module Installation

Bracket details

Adapter board details

6 Adaptive Path Optimization (ExpressSAS RAID only).............................................30

7 Data Path and LED Control....................................................................................... 31

LED Control for Internal SAS Connectors

8 Troubleshooting........................................................................................................ 40

Appendix A Glossry........................................................................................................ i

Appendix B VMware Configuration & Management....................................................iii

Driver Configuration

Adapter Management

Appendix C Standards and Compliances....................................................................vi

Appendix D Safety and Warranty.................................................................................vii

Safety

ATTO Technology, Inc. limited warranty

1 ATTO Provides Storage Solutions

ATTO Technology ExpressSAS low-profile HBAs and RAID adapters provide 6Gb and 12Gb SAS/SATA

connectivity for IT and digital video environments.

The ATTO ExpressSAS adapter family provides

enhanced reliability and performance thanks to more

than 25 years of ATTO experience.

Installation procedure

The ExpressSAS RAID adapter has a Getting Started

Guide. If you have not used this guide or you are

installing an ExpressSAS HBA, follow the instructions

in this manual.

You will need:

• ExpressSAS adapter.

• Access to www.attotech.com to obtain

drivers, user manuals and utilities.

• The optional low-profile bracket and its

installation procedure.

• A computer with an available x8 or x16 PCI

Express expansion slot. The ExpressSAS

adapter has been optimized for x8 electrical

slots. Check your computer’s

documentation.

• SAS/SATA storage, cables and connectors.

Download

device drivers

from the ATTO website

for your operating system. Refer to page 9 for

driver installation.

2 Install the configuration software, the ATTO

ConfigTool, found on www.attotech.com. Refer

to the ATTO Utilities Installation and Operation

Manual for details.

Note

Logging features are only available if the

ATTO ConfigTool service is installed. We

recommend installing the service as a

minimum configuration.

3 Install the adapter. Refer to Install Hardware on

page 17.

4 Attach SAS/SATA storage.

5 Configure your storage and adapter, including

RAID, using the ATTO ConfigTool.

Note

Default settings are appropriate for most

systems but you may change settings using

the ATTO ConfigTool.

CAUTIONCAUTION

Back up your system data before changing

or installing any hardware.

ExpressSAS features

• Point-to-point technology delivers full throughput

to each connected storage device

• One-click installation

• User-friendly ATTO ConfigTool provides a

simple host-based utility for effortless

configuration; BIOS and EFI setup utilities

provide flexibility for custom applications

• Fully Thunderbolt aware, including hot plug and

daisy chain support in a PCIe expansion slot

• For RAID adapters, a user-friendly GUI allows

quick and easy RAID setup

• ADS™ technology alleviates data transfer

bottlenecks and moves data more efficiently

while managing latency

• DriveAssure™ is an ATTO exclusive

combination of features for the ATTO RAID

series adapters that performs predictive and

corrective actions to allow the continued

operation of marginal drives, while ensuring

continued and uninterrupted access to data

(6Gb RAID adapter only).

• CacheAssure™ provides confidence that your

cached data will remain intact in the event of an

unexpected power loss, while offering an

environmentally friendly, maintenance-free

solution. (6Gb RAID adapter only)

• Adaptive Path Optimization-has built-in

intelligence to sense when multiples paths to

drives are available and direct I/O

accordingly.(6Gb RAID adapter only)

• Driver support for Windows®, Linux®,

Mac® OS X(6Gb only), and VMware®

ESX/ESXi Server (HBAs only)

• Fully support EFI-HII interface (H12xx HBAs

only)

• RoHS compliant

• 3-year standard warranty

2 ATTO Technology Inc. ATTO ExpressSAS Host & RAID Adapter Installation and Operation Manual

ExpressSAS 12Gb Host HBAs

ExpressSAS 12Gb host bus adapters combine 12Gb/s

SAS speeds and x8 PCI Express 3.0 to deliver low

latency in real-time environments. They support a

dense and efficient connection to storage from servers

and workstations in datacenter, data warehousing,

VOD and other high-availability, high-performance

applications. Providing SAS/SATA connectivity to up

to 2,048 end devices (H1208, H1244 and H1280

support 1,024 end devices), ATTO 12Gb SAS HBAs

are ideal for both IT and digital video environments

that require a high level of performance.

Power Center Pro

Power Center Pro is an integrated software RAID

solution that brings the performance and protection of

RAID to storage devices attached to your ATTO

ExpressSAS 12Gb host adapters with internal ports.

ATTO’s Power Center Pro is a RAID 0, 1, 1e and 10

solution included for use with ExpressSAS 12Gb SAS

HBAs with internal connections, providing a cost-

effective option that adds performance and protection

to your storage architecture.

To learn more about using and configuring Power

Center Pro RAID groups, refer to the ATTO Utilities

software manual (

www.attotech.com

H1208 technical specifications

• 8 internal SFF-8643 SAS ports to PCIe 3.0 host

interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.9A; 3.3V @ 0.1A, 11W

• Airflow: 100 lf/m minimum

H1280 technical specifications

• 8 external SFF-8644 SAS ports to PCIe 3.0 host

interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.9A; 3.3V @ 0.1A, 11W

• Airflow: 100 lf/m minimum

H120F technical specifications

• 16 internal SFF-8643 SAS ports to PCIe 3.0 host

interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.2A; 3.3V @ 0.1A, 15W

• Airflow: 200 lf/m minimum

H12F0 technical specifications

• 16 external SFF-8644 SAS ports to PCIe 3.0

host interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.2A; 3.3V @ 0.1A, 15W

• Airflow: 200 lf/m minimum

H1244 technical specifications

• 4 external SFF-8644, 4 internal SFF-8643 SAS

ports to PCIe 3.0 host interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.2A; 3.3V @ 0.1A, 11W

• Airflow: 100 lf/m minimum

H1248 technical specifications

• 4 external SFF-8644, 4 internal SFF-8643 SAS

ports to PCIe 3.0 host interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.2A; 3.3V @ 0.1A, 15W

• Airflow: 200 lf/m minimum

4 ATTO Technology Inc. ATTO ExpressSAS Host & RAID Adapter Installation and Operation Manual

H1288 technical specifications

• 8 external SFF-8644, 8 internal SFF-8643 SAS

ports to PCIe 3.0 host interface

• Up to 12Gb/s per port performance

• Conforms to PCIe low profile form factor

• Length: 6.600”

• Height: 2.536”

• Operating temperature: 0-55 °C (32 °F-131 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.2A; 3.3V @ 0.1A, 15W

• Airflow: 200 lf/m minimum

ExpressSAS 6Gb Host HBAs

ATTO ExpressSAS Host HBAs are engineered for the

most stringent IT server and digital media workgroup

environments and are compatible with multiple

operating systems, applications, and drives.

Providing SAS/SATA II connectivity to up to 1,024 end

devices, the ATTO SAS Host HBA is ideal for both IT

and digital video environments that require a high level

of performance.

H644 technical specifications

• Four internal SFF-8087, four external SFF-8088

ports

• Up to 6-Gb/sec per port performance

• Form factor conforms to PCI low-profile

specification

• Length: 6.600”

• Height: 2.713”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 5-95% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.6A; 3.3V @ 0.2A, 8W

• Airflow: 100 lf/m minimum

H680 technical specifications

• Eight external SFF-8088 ports

• Up to 6-Gb/sec per port performance

• Length: 6.600”

• Height: 2.846”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 5-95% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.6A; 3.3V @ 0.2A, 8W

• Airflow: 100 lf/m minimum

H608 technical specifications

• Eight internal SFF-8087 ports

• Up to 6-Gb/sec per port performance

• Form factor conforms to PCI low-profile

specification

• Length: 5.600”

• Height: 2.713”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 5-95% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.6A; 3.3V @ 0.2A, 8W

• Airflow: 100 lf/m minimum

6 ATTO Technology Inc. ATTO ExpressSAS Host & RAID Adapter Installation and Operation Manual

H60F technical specifications

• 16 internal SFF-8087 ports

• Up to 6-Gb/sec per port performance

• Form factor conforms to PCI low-profile

specification

• Length: 8.638”

• Height: 2.918”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 5-95% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.6A; 3.3V @ 0.8A, 22W

• Airflow: 100 lf/m minimum

H6F0 technical specifications

• 16 external SFF-8088 ports

• Up to 6-Gb/sec per port performance

• Length: 5.600”

• Height: 4.376”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 5-95% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 1.6A; 3.3V @ 0.6A, 22W

• Airflow: 100 lf/m minimum

ExpressSAS 6Gb RAID Adapters

ATTO ExpressSAS RAID adapters are ideal for both IT

and digital video environments that require a high level

of protection and performance, supporting up to 256

end devices.

RAID improves data accessibility and reliability during

normal operations. A RAID group is a virtual,

independent single drive with data written to physical

drives according to a RAID algorithm.

DriveAssure™ lets you run longer, faster and

smoother without interrupting data flow while avoiding

the unnecessary cost of replacing functional drives.

The ATTO ExpressSAS RAID adapters support

JBOD, DVRAID™, RAID Level 0, 1, 4, 10, 5, 6, 50, 60

and advanced features such as read caching, Hot

Spares, automatic RAID group rebuilding, hot swap

and Simple Network Management Protocol (SNMP).

R644 technical specifications

• Four external SFF-8088 & four internal SFF-

8087 ports

• Up to 6-Gb/sec per port performance

• Form factor conforms to PCI low-profile

specification

• Length: 6.600”

• Height: 2.713”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.8A; 9.6W

• 12V @1.22A; 3.3V @ .06A, 15.05W

(NVCACHE charging), 12V @1.00A;

3.3V @ .06A, 12.34W (NVCACHE

charged)

• Airflow: 150 lf/m minimum

R680 technical specifications

• Eight external SFF-8088 ports

• Up to 6-Gb/sec per port performance

• Form factor conforms to PCI low-profile

specification

• Length: 6.600”

• Height: 2.713”

• Operating temperature: 0-40 °C (32 °F-104 °F)

• Operating humidity: 10-90% non-condensing

• Storage temperature: -40-70 °C (-40 °F-157 °F)

• Storage humidity: 5-95% non-condensing

• Power (typ): 12V @ 0.8A; 9.6W

• 12V @1.22A; 3.3V @ .06A, 15.05W

(NVCACHE charging), 12V @1.00A;

3.3V @ .06A, 12.34W (NVCACHE

charged)

• Airflow: 150 lf/m minimum

Altri manuali per ExpressSAS H1208 HBA

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali ATTO Technology Adattatore host

ATTO Technology

ATTO Technology ExpressPCI UL4S Manuale utente

ATTO Technology

ATTO Technology Low-Profile SAS Host Adapter H308 Manuale utente

ATTO Technology

ATTO Technology R348 v Manuale utente

ATTO Technology

ATTO Technology ATTO ExpressPCI FC 3322 Manuale

ATTO Technology

ATTO Technology Low-Profile SAS Host Adapter H308 Manuale utente

ATTO Technology

ATTO Technology 6-Gb SAS/SATA Host Adapter H60F Manuale utente

ATTO Technology

ATTO Technology ATTO ExpressPCI FC 3321 Manuale utente

ATTO Technology

ATTO Technology ExpressSAS H608 Manuale utente

ATTO Technology

ATTO Technology ExpressPCI UL5D Manuale utente

ATTO Technology

ATTO Technology ATTO ExpressPCI Ultra/WIDE SCSI Host Adapters Express PCI PSC: Single-Channel Single-Ended Ultra/WIDE ExpressPCI DC:... Manuale utente

ATTO Technology

ATTO Technology ExpressSAS H1208 HBA Manuale utente

ATTO Technology

ATTO Technology Celerity FC-41EL Manuale utente

ATTO Technology

ATTO Technology ATTO ExpressPCI FC 3342 Manuale utente

ATTO Technology

ATTO Technology ATTO Celerity FC-44ES Manuale utente

ATTO Technology

ATTO Technology Low-Profile SAS Host Adapter H308 Manuale utente

ATTO Technology

ATTO Technology Low-Profile SAS Host Adapter H308 Manuale utente

ATTO Technology

ATTO Technology Celerity FC-164E Manuale utente

ATTO Technology

ATTO Technology Celerity FC-41ES Manuale

ATTO Technology

ATTO Technology UL3D Manuale utente

ATTO Technology

ATTO Technology H30F Manuale utente

ATTO Technology

ATTO Technology ATTO XstreamCORE FC 7550 Manuale utente

ATTO Technology

ATTO Technology ATTO ExpressPCI FC 3321 Manuale utente

ATTO Technology

ATTO Technology Celerity FC-84EN Manuale utente

ATTO Technology

ATTO Technology Celerity FC-84EN Manuale utente

Manuali Adattatore host popolari di altre marche

Digital Equipment

Digital Equipment StorageWorks EK-KZPCM-UG Manuale utente

Sun Microsystems

Sun Microsystems Sun StorEdge Manuale utente

LSI

LSI LSI21320-R Manuale utente

LSI

LSI Ultra160 Manuale utente

Tekram Technology

Tekram Technology TR-824 Manuale utente

LSI

LSI S14037 Manuale utente

Sonnet

Sonnet Tempo Ultra ATA66 Manuale utente

Adaptec

Adaptec AHA-3940UW/OF Manuale utente

HighPoint

HighPoint RocketRAID 600L Manuale utente

Tekram Technology

Tekram Technology DC-820B Manuale utente

HighPoint

HighPoint RocketRAID 174x Manuale utente

Adaptec

Adaptec AHA-2944UW Manuale utente

IBM

IBM System Storage DS4000 Manuale utente

HP A8002A Istruzioni utente

Yealink

Yealink VC400 Manuale utente

Sans Digital

Sans Digital HA-SAN-4ESPCIE Manuale utente

Adaptec

Adaptec AHA-2740 Manuale utente

Adaptec

Adaptec AHA-1540CP Manuale utente
