Audi Q7 Manuale utente

Audi Q7

Quick reference guide

Fuel and tyre

pressures

(see sticker)

Fuel tank flap

To open:

Press the switch on the

driver’s door.

To close:

Press the tank flap until you hear

it click into place.

Engine oil

The correct oil specifi-

cations and engine oil

capacity are listed in

the Performance,

weights and dimen-

sions section of the

Owner’s Manual.

Warning triangle

The compartment for the

warning triangle is located

behind the cover in the tailgate.

Welcome

Dear Audi Driver,

This quick reference guide gives you

an overview of the main features and

controls of your vehicle. However, it

cannot replace the detailed Owner’s

Manual which contains important

information and safety warnings.

Please refer to your Owner's Manual for

detailed information on your vehicle.

You will find everything you need to

know about the radio, CD, navigation,

TV and telephone functions in the

Infotainment/MMI Operating Manual.

We wish you safe and enjoyable

motoring with your new Audi.

AUDI AG

AUDI Q7

Controls

and displays

Unlock switches for:

Tailgate

Tank flap

Bonnet lock release

Parking brake

To apply: Press pedal firmly

with your foot.

To release: Pull lever .

Parking brake release lever

Adjuster for exterior

mirrors

Turn the adjuster for:

Left exterior mirror

Exterior mirror heating

Right exterior mirror

Exterior mirror

retraction

Press the adjuster to move

the mirror glass in the

desired direction.

Electric windows

To set the desired position:

Press/pull to the first stop

and hold.

”One-touch” function:

Press/pull briefly to the

second stop.

Buttons for seat memory

Light switch

Button for side assist

Door handle and central

locking switch

Lock

Unlock

10 9

12 13

14 14

Overview

Switches and warning

lamps for:

Electronic stabilisation

program

Hazard warning lights

Passenger airbag off

CD player or CD changer

Air conditioner

Selector lever

(for automatic gearbox)

or gear lever

MMI control console

Buttons for:

Starting engine

Switching off engine

ESP

OFF

side assist warning lamp

Headlight range control

Cruise control system or

adaptive cruise control

Controls on multi-function

steering wheel

Turn signal and main beam

lever with button for lane

assist

Instruments and warning/

indicator lamps

Windscreen wipers/washer

and buttons for on-board

computer

Steering wheel position

adjuster

Buttons for:

Activating/deactivating

parking system plus/

advanced

Resetting trip recorder

Check function

Instrument lighting

MMI display

Buttons for:

Switching MMI display

on/off

Opening glove box

CHECK

advanced key

Switching on the ignition/starting the

engine

On vehicles without the advanced key, start

the engine in the normal way using the car

key. On vehicles with the advanced key, you

can start the engine without inserting the

key in the ignition lock.

To switch on the ignition: Press the START

button down to the first stop. The glow

plugs on diesel engines start preheating in

this position.

To start the engine: Press the brake pedal

(on an automatic vehicle move the selector

lever to Por N) and press the START button

down to the second stop.

To switch off the engine: Stop the vehicle

(on an automatic vehicle move the selector

lever to position Por N) and press the

STOP button.

If you press the STOP button again for at

least one second,

this will lock

the steering.

Locking and unlocking the vehicle

The advanced key allows you to lock and

unlock the vehicle without handling the

key itself. You only need to have the

remote control key on your person.

To unlock the vehicle:

Take hold of one of the door handles

or press the release catch on the tailgate.

To lock the vehicle:

Move the selector lever (on an automatic

vehicle) to position P.

Press the exterior locking switch eon one

of the door handles.

To open the tailgate:

The tailgate will spring open slightly when

you unlock it.

To unlock:

Press the button on the remote

control key, or

Press the button on the driver’s door

or the release catch on the tailgate.

To close the power-operated tailgate:

Press the button inside the open tailgate.

123

Manual seat adjustment

To adjust lumbar support:

Press the appropriate part of

the switch.

To move seat backwards or

forwards:

Lift the lever and move the

seat. Then release the lever

and move the seat further

until the catch engages.

To adjust seat height:

Pull up or press down the

lever.

To adjust backrest:

Take your weight off the

backrest and turn the knob.

Adjusting head restraint

To lower, press button pon the

side of the head restraint. The

top of the head restraint should

be at eye level or higher.

Seat adjustment

Electric seat adjustment

To adjust seat height and move seat

backwards or forwards:

Front of seat cushion up/down

Rear of seat cushion up/down

Seat up/down

Seat forwards/backwards

To adjust backrest:

Backrest further upright/

further reclined

To adjust lumbar support:

Press the appropriate

part of the switch.

Sitting position

Sit in a normal upright position and

do not sit too close to the steering

wheel. If necessary, also adjust the

position of the steering wheel.

min.

25 cm

First steps

Panorama roof

The two roof segments are opened/closed

separately when the ignition is on.

To open/close the front segment:

Comfort position: Turn control to

position e.

To open: Turn control towards runtil the

roof reaches the desired position.

To close: Turn control to position .

To tilt open/close the front segment:

Briefly press/pull control in position .

Press/pull the control and hold it to tilt the

roof to any desired position.

To tilt open/close the rear segment:

Briefly press the appropriate symbol on

the rocker switch or on the switch in the

rear headliner. Press and hold the rocker

switch to tilt the roof to any desired

position.

Switches for deluxe automatic

air conditioner

Left switches – left side of vehicle

Right switches – right side of vehicle

Temperature selection

Blower speed

Automatic mode

Set the desired temperature and

press the button.

SETUP

For calling up additional settings on

the MMI display

Air recirculation

Circulates and filters the air in the

interior of the vehicle

ECON mode

Activates/deactivates air cooling

ECON

SETUP

AUTO

Air conditioner

Speed and distance control

The adaptive cruise control is a cruise

control with integrated distance control.

To switch on/off: Pull/press lever u.

To set speed: Press button t.

To adjust stored speed: Press lever uup

(faster) or down (slower).

The adaptive cruise control will automati-

cally apply the brakes as you approach

a vehicle in front.

To increase/reduce the distance: Press

switch rto the right/left.

Technology

lane assist

Audi lane assist

The lane assist detects lane markings (e.g. on

a motorway). If the vehicle approaches one of

the lane markings, the steering wheel vibrates to

warn you. The warning does not occur if you

operate the turn signals before changing lane.

To activate/deactivate the system, press

button eon the turn signal lever.

adaptive cruise control

Multi Media Interface

MMI controls and displays

Driver information system

Multi-function steering wheel

Scroll the left thumbwheel to select a menu item in the

driver information system. Press the thumbwheel to

confirm the selection.

Press the MODE button to switch between the active audio

source and the navigation and telephone functions.

Briefly press the button (talk button) to switch on the

speech dialogue system.

Speak after the <beep>, e.g. say <Help Radio> to call up the

possible commands for operating the radio.

Press and hold the talk button to switch off the speech

dialogue system.

Scroll the right thumbwheel to adjust the volume. If you

press the right thumbwheel, the last navigation cue will be

repeated.
