Audi RS 4 CABRIOLET Manuale utente

Audi RS 4 Cabriolet

Quick reference guide

Fuel

(see sticker)

Tyre pressures

(see sticker on door

pillar on driver side)

Fuel tank flap

To open:

Press the right side of the flap.

To close:

Press the tank flap until you hear

it click into place.

Engine oil

The correct oil specifi-

cations and engine oil

capacity are listed in

the Performance,

weights and dimen-

sions section of the

Owner’s Manual.

Warning triangle

The compartment for the warning

triangle is located inside the boot lid.

Welcome

Dear Audi Driver,

This quick reference guide gives you

an overview of the main features and

controls of your vehicle. However, it

cannot replace the detailed Owner’s

Manual which contains important

information and safety warnings.

Please refer to your Owner's Manual

for detailed information on your vehicle.

You will find everything you need to

know about the radio, CD, navigation, TV

and telephone functions in the Operating

Manual for your sound system or

navigation system.

We wish you safe and enjoyable

motoring with your new Audi.

AUDI AG

Controls and

displays

Buttons for seat memory

Electric windows

To set the desired position:

Press/pull to the first stop

and hold.

„One-touch“ function:

Press/pull briefly to the

second stop.

Bonnet lock release

Steering wheel position

adjuster

Door handle and

central locking switch

Unlock

Lock

Adjuster for exterior

mirrors

Turn the adjuster for:

Left exterior mirror

Exterior mirror heating

Right exterior mirror

Exterior mirror

retraction

Press the adjuster to move

the mirror glass in the

desired direction.

8 8

Overview

Driver’s seat heating

Front passenger’s seat

heating

Gear lever

Handbrake

START button

Power-operated soft top

Cigarette lighter/

electrical socket

Switches and warning

lamps for:

Electronic stabilisation

program

Sport mode

Passenger airbag off

Hazard warning lights

Storage tray

Sound system or

navigation system

Air conditioner

ESP

Cruise control system

Controls on steering wheel

Light switch

Turn signal and main beam

lever

Instruments and warning/

indicator lamps

Windscreen wipers/washer

and buttons for on-board

computer

Ignition lock

14 15

Sitting position

Sit in a normal upright position and

do not sit too close to the steering

wheel. If necessary, also adjust the

position of the steering wheel.

123

Seat adjustment

Electric seat adjustment

To adjust seat height and move seat backwards

or forwards:

Front of seat cushion up/down

Rear of seat cushion up/down

Seat up/down

Seat forwards/backwards

To adjust backrest:

Backrest further upright/

further reclined

Head restraint

up/down

To adjust lumbar

support:

Press the appropriate

part of the switch.

min.

25 cm

Seat adjustment for RS bucket seat (sports seat)

To move seat backwards or forwards:

Lift the lever and move the seat. Then release the

lever and move the seat further until the catch

engages.

To inflate and deflate side padding on seat:

Press the control upwards or downwards to

inflate or deflate the side padding on the seat as

desired.

To inflate and deflate backrest side padding on

seat:

Press the control upwards or downwards to

inflate or deflate the backrest side padding on

the seat as desired.

To adjust seat height:

Lift or press the lever repeatedly until the seat

reaches the desired height.

To adjust lumbar support:

Press the appropriate part of the switch.

To adjust backrest:

Take your weight off the backrest and turn the knob.

Easy entry function:

Lift the lever and fold the backrest down/return

it to its upright position.

First steps

Starting the engine

To switch on the ignition:

Turn the key to position .

To start the engine:

Press the clutch and press and hold the

START button until the engine starts.

To switch off the engine:

Turn the key to position .

Air conditioner

Switches for air conditioner

Buttons on left: Temperature selection for left side

Buttons on right: Temperature selection for right side

Buttons in centre: Blower speed

Automatic mode

Set the desired temperature and press the button

Air recirculation

Circulates and filters the air in the interior of the vehicle

ECON mode

Activates/deactivates air cooling

To deactivate the air conditioner

Air to the windows

Air from the dashboard outlets

Air to the footwells

ECON

AUTO

Windbreak

Setting up:

pTake the windbreak out of the storage

bag (luggage compartment).

pFold the two side sections outwards.

pPull out the retainer pegs (left/right)

and hold the windbreak in a horizontal

position against the backrest upholstery.

pSlide the retainer pegs (left/right) all

the way into the mountings.

pPress the release catches (left/right)

and slide the locking pins into the

mounting holes at the sides.

pFold the vertical section of the windbreak

into the fully upright position.

Removing:

Follow the instructions in reverse order.

Power-operated

soft top

To open the soft top:

Switch on the ignition.

Pull and hold the switch until the

soft top is fully open.

To close the soft top:

Switch on the ignition.

Press and hold the switch until the

soft top is fully closed.

Technology

Cruise control

system

When the system is switched on, the

indicator lamp appears in the instrument

cluster.

To switch on/off: Pull/press lever .

To set speed: Press button .

To adjust stored speed: Press lever up (faster)

or down (slower).

The storage box can be raised in order to

extend the luggage compartment.

The soft top must be closed!

To raise: Slide the lever to position .

To lower: Slide the lever to position .

Variable

soft top storage box

Audi Navigation System plus

Components

Driver information system

Controls on steering wheel

button: Press briefly to switch the sport mode on or

off.

button: Briefly press repeatedly to switch between the

active audio source and the navigation, telephone and

on-board computer functions.

and buttons: Briefly press repeatedly to scroll

through the on-board computer displays.

button: Press briefly to activate the selected menu.

SET
