Audiovox LCM-5600NP Manuale utente
LCM-5600NP
5.6"ActiveMatrixLCDMonitor
Owner’s Manual
EXPLANATION OF GRAPHIC SYMBOLS
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
WARNING: TO PREVENTFIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
Thelightningflashwiththearrowheadwithin
a triangle is intended to alert tell the user
that parts inside the product are capable of
producing an electric shock .
The exclamation point within a triangle
is intended to alert the user that important
operating and servicing instructions are
being provided.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2
1. Type: Color Liquid Crystal Display (LCD)
Monitor
2. Display Screen Size: 5.6inches
(114.2 x 83mm) ( W x H )
Element : TFT LCD
Format : 480 (W) x 234 (H) dot
Total 112,320 dot
3. Back Light: Cold Cathode Fluorescent Lamp
4. Power Source: +12 VDC
5. PowerConsumption: 11W
6. ConnectionTerminals: Video/Audio Input Jacks (RCA)
External Power Jack (DC IN 12V)
IR Jack
7. Operating Temperature: 32°F - 104°F
(0°C - 40°C)
8. Storage Temperature: -4°F - 176°F
(-20°C - +80°C)
9. Cabinet Dimensions: 6.29 in x 4.52 in X 1.14 in (WxHxD)
(160 x 115 x 29 mm)
10. Weight: 1.33 lbs (500g)
11. Video Format: PAL, NTSC
SPECIFICATIONS
3
CONTROLS AND INDICATORS
FRONT PANEL
1. Power On LED Indicator
2. Power On/Off Switch
3. Remote Control Sensor
4. Picture Select
5. On Screen Adjustment Up Button
6. On Screen Adjustment Down Button
4
1
2
3
4
5
6
REAR PANEL
7. Power Input Connector: Red = +12 VDC
Black = ground
8. VideoSignal InputConnector
9. IRRepeater Connector
10. IRRepeaterTransmitter
11. AudioRight ChannelInput Connector
12. AudioLeft ChannelInputConnector
5
10
9
7
8
12
11
To IR Tansmi tter
(Optional)
To Optional
IR Transmitter
Part Number IRT456
NOTE(B)
NOTE(A)
NoteA : This cable (10) is utilized to connect to Video Cas-
sette Playersthatdo not acceptthe IR Repeater1/8"
(3.5mm)style plug(9). TheIRRepeaterTransmitteris
provided with an adhesive that allows it to adhere to
Video Cassette Player remote sensor. Remove the
backing covering the adhesive and place the IR Re-
peater Transmitter directly over the Video Cassette
Playerremote sensor.
Connector(11)and(12)areAudioinputJacksreserved
for optional IR Wireless Transmitter use (IRT456).
IR Wireless Transmitter is a device for transmitting
(audiosoundwithout usingwires)to IR Headphones.
Please contact Audiovox dealers for this optional ac-
cessory.
NoteB :
OPERATION
1. Connect the monitor power input plug (7) to a DC power
source (Red plug +12 VDC, Black plug (-) to ground).
2. Connectthe external videosource output signal(fromVCP/
DVD, TV Etc.) to the VIDEO IN jack (8).
3. Presspower On/Off button(2) toturnthe monitoron andoff.
TheLEDpower indicatorwill light red.
4. Press the Picture Select button (4) to adjust the picture dis-
play characteristics. The adjustments will be shown on the
On Screen Display in the following sequence: Contrast,
Brightness, Color, and TINT.
5. While in the picture select mode (video adjustment), press
theup button(5) to increase the selected adjustment level
or press the down button (6) to decrease the level.
6
GENERAL INSTALLATION INFORMATION
1. Installationwill vary fromvehicle to vehicle,as headrestsin
vehiclesare notstandard.
2. Thisunit isintendedforinstallationby professionalinstallers.
3. The kit consists of the screen assembly, a mounting hous-
ing, key to remove screen from housing, wiring harness,
remotecontrolunit and remote control unitbatteries.
4. To release screen from housing, slide the key on either the
rightorleftsideofthescreenbetweenthehousingandscreen
assembly to release the two clips which hold the screen
assembly in the housing.
5. Toinstallthescreen assemblyinto thehousing simplyinsert
the screen assembly until you hear the clips click into the
locking position.
6. Headrests will have to be cut to install the screen assembly
housing.
Caution -Donot over-cut theheadrestbeyond the heightand
widthof thehousing.
7. To fasten the housing to the headrest, use either screws or
tie wraps. Find a suitable mounting surface in the headrest
tosecurethe housing.
Caution - Use the proper length screws, which will vary with
eachheadrest.Ifasuitablemountingsurfacecannotbefound,
use tie wraps to secure the housing.
8.Attachthe wiringtothe screen,throughthe housingintoand
down the headrest and seat before permanently mounting
the housing and screen assembly.
9. Follow the wiring diagram in the owner’s manual for proper
wiring connections. 7
8
© 2001 Audiovox Electronics Corp., Hauppauge, NY 128-5973A
NOTE: A Remote Control Unit is included which will perform
the Functions and adjustments of Operation items 3,
4, and 5 as well as additional features as noted below.
REMOTE CONTROL FUNCTIONS:
LCD/VCP:........Power button for LCD/VCP
REPLAY:..........Press to rewind tape and automatically go to
play mode.
PICTURE SEL: .OnScreenDisplay(OSD)forcolor,tint,brightness,
contrast. Use ± to adjust
REW: ...............Rewinds tape
FWD: ...............Fast Forward tape
PLAY:...............Playstape
STOP:..............Stops tape
1. Do not operate the monitor at temperatures below 32°F
(0°C) or above 104°F (40°C).
2. Keep the monitor clean and dry.
3. Alwaysseek qualifiedpersonneltoperformrepairs. Never
attempt your own repairs.
4. Do not drop the monitor or expose to strong impacts.
5. Do not expose to direct sunlight for extended periods of
time.
CAUTION
