Avantree BTHS-ANC032 Manuale utente
User Manual
Wireless Active Noise
Cancelling Headphones
BTHS-ANC032
Overview ······················································································································1
Basic Operations········································································································1
Connect to a Bluetooth device·············································································1
Reconnect to Bluetooth device············································································2
Active Noise Cancellation·······················································································2
Using as a wired headphone·················································································2
Status of LED Indicators ··························································································3
Charging·······················································································································3
Troubleshooting ········································································································4
1
Overview
Basic Operations
Function Operation
General
Power ON / OFF Hold for about 3s
Enter Pairing Mode From o status, hold for 5s till the LED indicator
blinks RED and BLUE alternately
Clear Paired history After power on, hold BOTH + & - for 5 seconds till LED
blinks RED & BLUE twice then release the buttons.
Music control
Play / Pause music Press once
Volume up/down Short press + or -
Next/ Previous track Long press + or -
Call control
Answer / end a call Press once
Reject a call Hold for 1s when receiving an incoming call
Voice dial(Phone feature) Hold 1s
Redial the last called phone Press twice
Activate / Deactivate Microphone mute In calling status, press BOTH + or - once to activate /
deactivate microphone mute
Connect to a Bluetooth device
1. Set headset into PAIRING MODE – From o state, hold for 5s till the LED indicator ashes RED & BLUE
alternately.
2. On your device, turn on the Bluetooth feature and select “Avantree ANC032”to connect. If you are using a
Bluetooth transmitter, please set your transmitter to PAIRING MODE (follow its user manual).
2
3. Once connected, the LED will ash BLUE onceevery 10 seconds.
Reconnect to Bluetooth device
Normally,whenpowered on, the headphones try to reconnect with the most recently connected device. For
other devices, please select “Avantree ANC032” to connect manually.
Note:
· The devices must be in range and powered on,
· The reconnection function depends on the dierent make/model of devices. Some TVsDO NOT support
automatic reconnection to headphones.
Active Noise Cancellation
Press button once to activate the ANC function, the LED will remain GREEN.Press again to deactivate
ANC function.
Note: If the headphone battery is depleted, you cannot use the ANC function.
3
Using as a wired headphone
Use the supplied 3.5mm audio cable to connect a non-Bluetooth device, or if the headphones battery is
depleted.
Status of LED Indicators
Indicator Light Headphones Status
Red LED blinking Low battery
Red solid Charging
Green solid ANC Activate
Blue and red alternately Ready to pair
Blue ash one time every 10 seconds Connected
Blue ash two time every 10 seconds NOT connected
Charging
If you hear a beep sound once a minute, you should recharge your headphones. Please plug it into a USB wall
charger (DC 5V / 0.5-2A) or a powered computer USB port via attached micro USB cable.
Normally it will take 2.5 hours to fully charged. The LED will remain red when charging and will turn o when
charging is complete.
4
Troubleshooting
• No sound withPC?
- Set Avantree ANC032 as the default device or output device on the PC.
- When using ANC032 to make VOIP calls through apps, please set ANC032 Hands-Free as Microphone
and Speakers device.
• No sound with Bluetooth transmitter to watching TV?
- Check to ensure audio source is functioning properly
· AUX & RCA output on TV – test with wired headphones
· OPT output on TV – Set audio format to “PCM/LPCM”or turn o Dolby/DTS
- Change your TV audio out setting to External speakers /Headset.
- Ensure Bluetooth transmitter and headphones are connected properly.
• Headphones do not pair with Bluetooth device
- Ensure ANC032 is in Pairing mode – LED will ash BLUE and RED alternately.
- For Bluetooth transmitter, ensure the transmitter is in Pairing mode – refer to its user manual.
- For Smart phone, tablet and PC
· Turn the Bluetooth o and then on again.
· Delete “Avantree ANC032 headphones”from your devices Bluetooth list and then try to pair again
- Clear the headphones pairing history
· After power on, hold BOTH +& - for 5 seconds till LED blinks RED & BLUE twice. Then release the
buttons and the headphones enter into pairing mode automatically.
• Visit YouTube.com/Avantree ANC032 to see how-to videos.
For more detailed information please search ANC032 on support.avantree.com or contact
support@avantree.com directly.
