The Power of Being There®

Multiple problems faced by your IT organization can be managed by the physical

separation of your users from their computer/target device. Problems include physical

and data security, workplace environments, asset management, licensing and auditing,

remote access, reduced downtime, and more.

The LV1000 supports physical separation requirement up to 1000 feet with any UTP

cable without compromising your experience. The simple transmitter and receiver

pair design allows for ease of installation and simple deployment.

Target devices are typically multiplatform computers, or a KVM switching

infrastructure. The user station may be a desktop environment, KVM switching

infrastructure console or a video/audio display unit.

LongView® LV1000

Extend your control up to 1000 feet from

computers with a single UTP cable

FEATURES AND BENEFITS

•Multiplatform. Easily connect to PS/2,

USB and SUN machines.

•User Peripherals. Extends keyboard,

video, mouse, speakers, microphone and

serial devices up to 1000 feet with any UTP

cable type. Connect PS/2 and USB keyboard

and mouse at the user station, regardless of

the target device platform.

•Auto Tuning. This unique feature will

automatically compensate for video skew and

signal loss, delivering clear crisp video

images up to 1000 feet at a resolution of

1280 x 1024.

•Dual Mode. The dual mode transmitter

supports a second user connection locally at

the target device or remotely up to 1000 feet

away with an additional LV1000R receiver

unit

•Small Form Factor. The small form

factor user station (receiver unit) supports

desk and flat panel monitor mounting with

optional hardware.

•OSD. Configuration and system information

is easily accessed and updated via the on-

screen display.

•Ease of Installation. The single cable

to desk design simplifies installation while

making it easier for you to move, add or

change configurations. LongView® LV1000 is part of the Avocent extension solutions family that includes analog and

digital products supporting extension over copper, fiber and wireless media. For additional

information please contact an Avocent sales representative.

KVM, Audio & Serial Device Extension

MECHANICAL

•Height – 1.06” (27mm)

•Depth – 7.40” (188mm)

•Width – 8.27” (210mm)

•Unit Weight – 2.2lbs (1Kg)

•Shipping Weight – 4.4lbs (2Kg)

ENVIRONMENTAL / POWER / HARDWARE

•Operating Temperature 0oC (32oF) to 40oC

(104oF)

•Storage Temperature -20oC (-4oF) to 50oC (122oF)

•Power In 100-250VAC @ 0.7-0.3A

•Power Consumption 25W

•Computer PS/2 and USB machines.

•KVM Switch PS/2 and USB local ports

•Video Resolution 1280 x 1024 @ 1000’

•Peripherals PS/2 and USB keyboard / Mouse,

Audio in/out, serial devices and VGA video.

STANDARDS

•Approvals – cUL, UL, CE, FCC15 Class A,

VCCI-A.

ORDERING DETAILS

•LV1000P Receiver with PS/2 Transmitter

•LV1000U Receiver with USB Transmitter

•LV1000R Receiver only

•AMIQDM-VSN SUN transmitter only

•DMK-02 Desk Mounting option

•MMK-01 FP Monitor and Wall mounting option

•RMK-45 Rack Mounting Kit option

WARRANTY

•Standard warranty 2 Year

•Extended warranty Contact Avocent

The LV1000 extender is a point-to-point KVM, audio and serial device

extender up to 1000 feet. The system is a transmitter/receiver design

with an interconnecting UTP cable. The skew compensation feature

supports any combination of UTP cable in the extension path as well as

patch panel interfaces. If the connection path is altered in any way

during operation, the LV1000 will automatically adjust without any

manual adjustment or user intervention.

LONGVIEW® LV1000 Extender Specifications

4991 Corporate Drive, Huntsville, AL 35805

KVM Switch Extension Configuration

PC Extension Configuration

vocent, the Avocent logo, The Power ofBeing There andLongView are

trademarks or registered trademarks of Avocent Corporation or its affiliates.

Avocent Corporation 0805-LV1000-TP

TEL 866 286-2368 FAX 256 430-4030

www.avocent.com
