Avocent LongView Wireless Manuale utente

The following instructions will allow you

to connect your LongView Wireless units.

Should you require assistance, please

consult your installer/user guide. To connect a LongView Wireless

Powering up the transmitter and computer

Connect your transmitter to an AC power source with one

of the included power supplies and power up your computer.

NOTE: Use only an Avocent-supplied power supply. The

transmitter must be powered up before the computer.

Installing the LongView Wireless receiver

Connecting the peripherals

Connect the extended user’s keyboard, monitor and

mouse into the appropriately marked ports on the rear of

the receiver.

Connecting the audio

Connect your PC speakers into the receiver’s audio

output connection.

Installing the LongView Wireless transmitter

Connecting the computer’s peripherals

Power down the computer that will be part of your LongView

Wireless system and unplug its peripherals. Place the

transmitter near the computer and connect the LongView

Wireless transmitter cables into the computer’s PS/2

keyboard, PS/2 mouse and monitor connections.

Connecting the audio

Using the supplied audio cable, connect one end to the

transmitter’s audio input connection and the other end to

the computer’s audio output connection.

Connecting a local user to the transmitter

Connect the local user’s keyboard, monitor and mouse into

the appropriately marked ports on the rear of the transmitter.

Powering up the receiver

Connect the power supply into the LongView Wireless

receiver and into an AC power source.

For additional information

For further instructions on LongView Wireless hardware

connection, please refer to the installer/user guide

included with the unit.

Quick Installation Guide

LongView®

Wireless

Connect the

transmitter cable into

the appropriate ports

on the computer.

Connect the audio.

Connect to an

AC power source.

Connect to an

AC power source.

Connect the local

user’s keyboard,

monitor and mouse.

Connect the local

user’s keyboard,

monitor and mouse.

To Contact Avocent Technical Support CALL (888) 793-8763 EMAIL [email protected] DOWNLOAD Check out the latest software from our web site at www.avocent.com

Avocent, the Avocent logo, The Power of Being There and LongView are trademarks or registered trademarks of Avocent Corporation or its affiliates. All other marks are the property of their respective owners. ©2003 Avocent Corporation. All rights reserved. 590-385-001A

Transmitter Receiver

Connect the

extended speaker.

The following instructions will allow you

to connect your LongView Wireless units.

Should you require assistance, please

consult your installer/user guide.

Quick Installation Guide

LongView®

Wireless

To Contact Avocent Technical Support CALL (888) 793-8763 EMAIL [email protected] DOWNLOAD Check out the latest software from our web site at www.avocent.com

Notifications and Approvals

USA Notification This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not

cause harmful interference and (2) this device must accept any interference received, including received interference that may

cause undesired operation.

Agency Approvals

UL, cUL, FCC
