Convenient, remote access to your computers via the LAN

The LongView IP digital extension solution provides remote access to your computer over a

local area network (LAN). With LongView IP digital extension, you have remote access to

all of your computer’s peripherals from anywhere on the corporate TCP/IP LAN or point-

to-point over a single UTP cable. LongView IP digital extension lets you easily move your

desktop devices, including your keyboard, video and mouse, speakers and microphone

away from your computer. Convenient IP connectivity gives you access to high quality

DVI video and audio from anywhere in your building. The LongView IP digital extender

technology also improves data security, and environmental and limited workspace problems.

Deploying a LongView solution could not be easier. Simply connect the LongView

transmitter to the computer, and the receiver at the user location (desk) and connect both

units to a LAN.

Key Features and Beneﬁts

Full Hardware Solution.All

connections to the user desktop

peripherals are provided without the

need for software, OS, disk or fan

DVI Video.Connects to single

or dual DVI monitors on the user

desktop

CD Audio.Connects to the analog

speakers on the user desktop

Quad USB Ports.Provides

connection for up to four USB

devices including keyboard, mouse,

and mass storage devices

Dual PS/2.Provides connection for

legacy PS/2 keyboard and mouse

Ethernet Port.Allows the computer

and user to be located anywhere

on the 100 or 1000Mbps network

with full routing of data across

routers, switches and subnets

Encryption of Network Data.128bit

AES encryption of all data passing

between the computer and the

network

Upgradeable.Based on an

embedded Linux OS, the device is

fully upgradeable to allow for future

feature enhancements

Flexible Mounting.Small form factor

can be used on a desk, mounted

directly to the back of a monitor or

inside the display device.

Gigabit

Ethernet Switch

LongView IP

Receiver

LongView IP

Transmitter

LongView IP

Transmitter

LongView IP

Transmitter

LongView IP

Receiver

LongView IP

Receiver

Workstation

LongView IP

Receiver

Workstation

Speakers

UTP

LongView IP

Transmitter

LongView IP

Receiver

Speakers Workstation

UTP

LongView IP

Transmitter

Desktop extension over UTP

Dual monitor extension over UTP

Workstation extension over a LAN

LongView®IP Desktop Extension over IP Solutions

Transmitter Receiver

Connections

PS/2 No 2 (Keyboard & Mouse)

USB 2 x USB 4 x USB

VGA 1280x1024 @ 60Hz 1280x1024 @ 60Hz

DVI 1280x1024 @ 60Hz 1280x1024 @ 60Hz

3.5mm Stereo Speaker

Jack

Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz

Mono microphone jack Yes Yes

Network Port 1 - RJ45 1 - RJ45

Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps

Encryption SSL/AES 128 bit SSL/AES 128 bit

USB Support USB keyboard & mouse, and mass storage devices USB keyboard & mouse, and mass storage devices

Mechanical

Format self-enclosed module Desktop mounting metal case with external power supply

Height 0.83 in. (21 mm) 1.04 in. (26.5 mm)

Depth 6.02 in. (153 mm) 5.12 in. (130 mm)

Width 2.68 in. (68 mm) 8.27 in. (210 mm)

Weight .66 lbs. (0.3 Kg) 1.54 lbs. (0.7 Kg)

Environmental / Power

Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)

Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)

Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)

Power In 5VDC / 1.1A 100-250VAC / 50-60 Hz, 1A

Power Consumption 6W 20W

Standards

Approved Agency cUL, UL, CE, FCC15 Class A

LongView IP Speciﬁcations

Transmitter Receiver

Connections

PS/2 No 2 (Keyboard & Mouse)

USB 1 x USB 4 x USB

VGA No 2 x 1600x1200 @ 60Hz (with Adaptor)

DVI 2 x DVI-D (supports digital video only) 2 x DVI-I (supports digital and/or analog video)

1900 x 1200 @ 60Hz

3.5mm Stereo Speaker

Jack

Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz

Mono microphone jack No No

Network Port 1 - RJ45 1 - RJ45

Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps

Encryption SSL/AES 128 bit SSL/AES 128 bit

USB Support USB keyboard & mouse, and mass storage devices USB keyboard & mouse, and mass storage devices

Mechanical

Format External metal case module Desktop mounting metal case with external power supply

Height 1.10 in (28 mm) 1.10 in (28 mm)

Depth 7.87 in (200 mm) 6.06 in (154 cm)

Width 5 in (127 mm) 8.19 in (208 mm)

Weight 1.65 lbs (.75 Kg) 2.09 lbs (.95Kg)

Environmental / Power

Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)

Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)

Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)

Power In 5VDC 100 – 250VA[email protected]

Power Consumption 6W 1W

Standards

Approved Agency cUL, UL, CE, FCC15 Class A

LongView IP DH Speciﬁcations

Avocent, the Avocent logo, and LongView are registered trademarks of Avocent

Corporation or its afﬁliates in the U.S. and other countries. All other marks are the

0508-LVIP-DS-EN

www.avocent.com/contacts

Transmitter Receiver

Connections

PS/2 2 (Keyboard & Mouse)

USB 2 x USB 2 x USB

VGA 1280x1024 @ 60Hz 1280x1024 @ 60Hz

DVI No No

3.5mm Stereo Speaker

Jack

Yes, Stereo speakers 24 bit 44kHz Yes, Stereo speakers 24 bit 44kHz

Mono microphone jack Yes Yes

Network Port 1 - RJ45 1 - RJ45

Network Speed 100Mbps or 1Gbps 100Mbps or 1Gbps

Encryption SSL/AES 128 bit SSL/AES 128 bit

USB Support USB keyboard & mouse PS/2 / USB keyboard & mouse

Mechanical

Format Self-enclosed module Desktop mounting metal case with external power supply

Height 0.83 in. (21 mm) 1.04 in. (26.5 mm)

Depth 6.02 in. (153 mm) 5.12 in. (130 mm)

Width 2.68 in. (68 mm) 8.27 in. (210 mm)

Weight .66 lbs. (0.3 Kg) 1.54 lbs. (0.7 Kg)

Environmental / Power

Operating Temperature 32° F to 95° F (0° C to 35° C) 32° F to 95° F (0° C to 35° C)

Storage Temperature -4° F to 140° F (-20° C to 60° C) -4° F to 140° F (-20° C to 60° C)

Humidity 10% to 90% (non-condensing) 10% to 90% (non-condensing)

Power In 5VDC / 1.1A 100-250VAC / 50-60 Hz

Power Consumption 6W 20W

Standards

Approved Agency cUL, UL, CE, FCC15 Class A cUL, UL, CE, FCC15 Class A

LongView IP VG Speciﬁcations
