Baby Jogger Stroller Manuale utente
Read these
instructions carefully
before use and
keep them for
future reference.
Your child’s safety may be
affected if you do not follow
these instructions.
Assembly
Instructions
City Mini Single
Amazing 360° Turns
Make For Extreme Maneuverability
This product complies with BS EN 1888:2003 inc. A1,2,3: 2005
This product complies with ASTM F833-07a
2
• WARNING: DO NOT exceed 3mph. – this stroller is not suitable for running, jogging,
skating or roller blading.
• WARNING: Prevent serious injury to your child by always using the safety harness.
• WARNING: Parcels or accessory items, or both, placed on the unit may cause the unit
to become unstable.
• WARNING: Never leave your child unattended.
• WARNING: Recommended weight for seat pocket is 2 pounds and basket is
10 pounds. Excessive weight may cause a hazardous unstable condition to exist.
• WARNING: Stroller is not meant to be used for transporting children up or down
stairs. Damage resulting to stroller, will not be covered under warranty.
• WARNING: Child may slip into leg openings and strangle. Never use in reclined
carriage position unless safety harness is properly fastened.
• Accessories which are not approved by the manufacturer or distributor
shall not be used.
• The passenger shall remain seated (no standing in the stroller).
• Watch out for cars – never assume that a driver can see you and your child.
• Total weight load recommended for this stroller is 50 lbs.
(combined passenger and baggage weight.)
• This stroller seats one passenger.
• It may be unsafe to use replacement parts other than those supplied or approved
by the manufacturer.
For the sake of your precious cargo, please read
these warnings before using your stroller.
1
1. Unpack stroller from box
and set wheels aside.
3. The stroller will click into place.
2. Begin to unfold stroller by pushing the bottom
frame up and away from the handle.
4. Turn stroller over to upright position.
Snap safety strap to frame before use.
WARNING: Ensure all
locking devices are
engaged before use.
To fold: Unsnap safety strap from frame and pull up on fold strap.
Frame
3
1 Align wheel with axle.
2 To insert, press the wheel
button while gently sliding
the axle into the wheel's
axle end. You will feel the
wheel click into place.
To remove the rear wheels,
press the wheel button
while gently sliding the
wheel away from the axle.
Rear Wheels
2
1 To install front wheel, lay
stroller back so the handle
is resting on floor.
2 Insert the front wheel by
sliding the axle into the
wheel end. Make sure
the front wheel is locked
into place.
Front Wheel
Swivel/Straight Feature
• Raise the lever up to allow the front wheel
assembly to swivel.
• Press the lever down to lock the front wheel
assembly in the straight position.
NOTES: When loading and unloading child,
always press the lever down to lock the front
wheel straight.
5
WARNING: Engage parking device before loading and
unloading passenger.
Brake
• Simply push
brake pedal down
to engage rear
parking brake and
lift up to release.
4
WARNING: Always use the crotch strap in combination with the
shoulder straps and waist belt.
1 Unclip top of
shoulder strap
from the seat
and re-clip
on the pair
of seat loops
closest to
child’s shoulder
height.
2 To adjust the
shoulder and
crotch strap
length: Remove
the shoulder
pads and move
the plastic guide
up or down
to lengthen or
shorten.
3 To buckle: Fasten both
shoulder strap buckles into
the crotch strap buckle. The
buckles should always be
clicked into place before use.
To unbuckle: Press both sides
of the shoulder buckles to
release them from the crotch
buckle, one at a time.
Safety Harness
6
2 To remove the canopy, stand facing the
stroller and press the bracket buttons
with index finger while removing the
canopy from the bracket.
1 To attach canopy to frame, simply
slide canopy axle into the top hole of
the bracket on the frame, until you
hear it click into place. The bottom
hole can be used for accessories,
and they should be inserted into the
bracket the same way as the canopy.
Canopy
7
Seat
1 Snap seat to frame,
starting with the top snap
closest to the handle, and
working your way down
to the frame behind the
front wheel.
To fold stroller: Remove child
from seat. Unsnap safety straps
from frame and pull upwards on
the fold strap with a gentle tug.
4 Secure safety
straps to both
sides of the
frame before use. 5 Be sure that fold strap rings are secured
to the frame before use.
3 Secure seat straps around the
bottom of the frame, behind
the front wheel. Thread one
seat strap through the D ring of
the other strap, and fasten both
Velcro sides firmly together.
WARNING: Always
be sure the safety
strap Is securely
snapped onto the
frame before using
stroller!
2 Secure top of seat around
frame with Velcro tab, after
snapping the webbing to the
frame underneath.
9
Basket
1 Wrap webbing around stroller frame tube.
NOTE: The rear of basket has the mesh material and the front does not.
2 Snap basket webbing together. On the back
side of the stroller, the basket should rest
between upright frame and crossbar.
1 To recline: Pinch the clamp behind the seat, and slide it down to desired recline.
Pull seat down on both sides to match recline position of clamp.
Reverse steps to return to the upright position.
Reclining Seat
8
• Weather Cover: If desired, pull weather cover down and
over the seat back mesh. Secure firmly over both sides of
seat. When not in use, roll weather cover up and fasten
with elastic loop and barrel provided under top of the
seat fabric.
1110
Steering
• Steering your stroller is simple: It is balanced to turn with just a light touch on the handlebar
without having to lift the front wheel.
In the Dark
• Since we are concerned about the safety of you and your child, we recommend that you not use
your stroller at night. However, if you choose to, please attach reflective strips to the wheels and
the seat. Bicycle lights can also be mounted on the handle crossbar. These accessories can be
found at most bike stores.
Maintenance
• To preserve the longevity of your stroller, it is important to perform simple, regular maintenance.
From time to time, make sure that the joints and folding areas are still in good condition. If you
hear any squeaking or feel tension, you can take your stroller to a local bike shop for added
lubrication. All repairs should only be carried out by an authorized dealer.
In Motion
Quick Fold
Technology
To fold stroller:
1 Remove child from seat. Remove safety
straps from frame. Pull upwards on the
fold strap with a gentle tug.
Simple Lift & Fold
(Patented)
WARNING: Always
be sure the safety
strap Is securely
snapped onto the
frame before using
stroller!
12
13
Baby Jogger's Limited Lifetime Warranty:
Baby Jogger warrants that the frame is free of manufacturer defects for the lifetime of the product. Manufacturer’s defects include
but are not limited to the breaking of welds and frame tube damage. Textile or soft side materials and all other components
shall be warranted for one year from the date of purchase (except for tubes and tires). Proof of purchase is required to make a
warranty claim and the warranty is only extended to the original purchaser.
THIS WARRANTY DOES NOT COVER:
fitness for a particular purpose is according to the specific warranty period for this model unit at time of purchase. Some states do not allow the
consult your local or state consumer affairs office or your state’s Attorney General.
E-MAIL:
CALL:
1-804-262-6277
MAIL: BABY JOGGER COMPANY
8575 Magellan Parkway
Suite 1000
Washing
• You can machine wash your stroller’s seat in cold water with a mild detergent.
To minimize shrinkage, simply reattach the seat to the frame to dry.
(Please do not put the seat in the dryer!)
• Be sure to remove the frame from the back of the
seat before washing.
Wheel Care
• The wheels can be cleaned using a damp cloth. They
will need to be dried completely with a soft towel or cloth.
Storing
• Sunshine can fade seat fabric and dry out tires, so storing your stroller indoors
will prolong its good looks. However, if you do store it outside, using a tarp will
help protect against weather wear.
Stroller Care WARRANTY REGISTRATION ON-LINE AT
www.babyjogger.com/register
We wish you many happy journeys with your new
stroller! Your stroller is a great product, and we
are proud to manufacture it. If you have any
questions or comments, please give us a call at:
1.800.241.1848
Baby Jogger is a Division of Dynamic Brands
8575 Magellan Parkway, Suite 1000 • Richmond, VA 23227
T: 800.241.1848 • F: 804.262.6277 • www.babyjogger.com
Thank You!
