Babybee ROVER Bassinet Manuale utente
ROVER
www.babybeeprams.com.au
Please keep this manual for future reference
babybee prams
bassinet
2
Hello!
Thanks for choosing the babybee ROVER bassinet. Before you get
started, please note the safety warnings below:
Safety First
The safety of your family
is our number one priority.
Please take the time to
carefully read this manual
and safety warnings on
page 8 before setting up
and using your ROVER
bassinet.
The ROVER bassinet is
tested to comply with the
Australian Safety Standard:
AS/NZS 20088:2013 Pram
and Stroller – Safety
Requirements.
Contents
Step One: Setup the base 03
Step Two: Attach the canopy 04
Step Three: Attach the footcover and belly bar 05
Using your ROVER bassinet 06-07
Cleaning instructions 07
Safety Warnings 08
Warranty Information
09
With the exception of
the outer cardboard
packaging, to prevent
injury from choking,
carefully remove and
immediately move out
of reach all protective
packaging. Never leave
your child unattended
with the pram or
packaging.
WARNING
3
Setup the base
To set up your bassinet, pull
the black metal rods into
place as shown. This will give
your bassinet its structure.
Step One
1
Zip the cream bassinet
fabric onto the frame
as shown, and insert the
bassinet mattress.
2
4
Attach the
canopy
Step Two
Starting from the right side
of the bassinet, zip the
canopy onto the frame.
Tip: The canopy end, is the
end with the zip that stops
10cm short of the middle of
the frame. The other end is
for the foot cover.
1Next, attach the plastic
canopy clips to their
respective sides, ensuring
that they sit over the small
plastic guides located on
each side of the bassinet
frame.
2
5
Attach the foot
cover and belly
bar
Step Three
Starting from the right, zip
the foot cover onto the
bassinet
(at the opposite end to the
canopy).
To attach the belly bar,
simply click it in to the slots
ensuring that the release
buttons are on the outside
and you hear a ‘click’.
Give the belly bar a tug to
ensure it’s securely in place.
To remove it, simply press
the release buttons on
either or both sides and lift
up.
2
3
4
1
Bassinet not designed to
be carried by the belly
bar when containing
your child. Remove your
child from the bassinet
before lifting.
WARNING
6
Attaching the bassinet
Attach the bassinet to the
central connectors on the
pram frame. To release, lift
the bassintet release buttons
upwards and simply lift off.
The bassinet can face either
direction with parent facing
preferable.
Adjusting the canopy
Adjust the canopy as needed
to protect your child from the
sun and elements. For maximum
airow, fold up the back panel
and expose the mesh beneath.
Using your ROVER
bassinet
Never leave your child
directly exposed to the sun,
always ensure the canopy is
adjusted correctly to allow
maximum airow and seek
shade in the hottest parts of
the day.
WARNING
7
Cleaning instructions
All plastic, fabric and
metal parts of the
bassinet may be
sponged clean with
warm water and mild
detergent.
Always wipe dry and
allow all parts to dry
thoroughly before using.
The mattress cover can
be hand washed in your
sink with delicate
detergent. It can not be
tumble dried.
Rust may occur due to
environmental factors.
Wiping down your frame
after trips to the beach,
snow or in the rain, may
help reduce the issue.
At rst sight of rust simply
remove with steel wool.
Note: Spare parts can
be purchased
separately from our
website, if needed.
Rain cover
Pull the rain cover over the top
of the canopy and down over
the sides of the bassinet. Ensure
the air ventilation holes are not
obstructed and that air can
circulate through.
8
To avoid injury or
death: always apply
the brakes whenever
the stroller is stationary.
Do not leave children
unattended.
Do not carry extra
children or bags on
the stroller.
Make sure children
are clear of any
moving parts if you
adjust the stroller.
Do not use the ROVER
bassinet with any
other models of
stroller.
Approved for use
with the babybee
ROVER range only.
Safety Warnings
Maximum weight that
can be carried in the
bassinet is 9kg.
Do not use the bassinet
once the child can sit
up unaided.
Not to be used for
overnight or
unsupervised sleeping.
Only use the bassinet
in a at position. Do
not recline.
Bassinet not designed
to be carried by the
belly bar when
containing your child.
Remove your child from
the bassinet before
lifting.
WARNING
The babybee ROVER bassinet is designed and tested to
comply with AS/ NZS2088:2013.
9
Our bassinets come with a 12 month warranty to cover against
faults in materials and workmanship when your products are used
under normal conditions, according to our user manuals and
technical specications. The 12 month period starts from the date
your bassinet is dispatched from our warehouse. Please visit our
website for full details and to make a claim.
Warranty information
General safety
Do not use or leave
the bassinet near
open re or exposed
ame.
Never leave rain
covers, hoods or
blankets on or over
the bassinet indoors, in
a hot atmosphere or
near a heat source.
Always supervise
whilst the stroller is
covered
Do not use the bassinet
in a manner for which it
is not designed.
Do not use
replacement parts or
accessories that are
not approved for use
with the babybee
ROVER range.
Contact
babybee prams
@babybeeprams
Version: September 2017
Information subject to change. Please see website for current version.
www.babybeeprams.com.au
