Bacharach MZF Manuale utente

Mechanical Burner Combustion Testing Kits

Combustion &

Environmental Analyzers

Headquarters: 621 Hunt Valley Circle, New Kensington, PA 15068 U.S.A.

Phone: 1-800-736-4666 Canada: 1-800-328-5217 E-Mail: [email protected] Website: www.bacharach-inc.com

Oil Burner Combustion Testing Kits

Components

1. Fyrite®CO2 Indicator – The Fyrite Carbon Dioxide Indicator

measures the percent CO2in a flue gas sample.

2. True Spot®Smoke Tester and Oil Burner Smoke Scale – With

the True Spot Smoke Tester and Smoke Scale, you can get an

accurate indication of smoke content in flue gas.

3. Fire Efficiency Finder/Stack Loss Slide Rule – The Fire

Efficiency Slide Rule is a quick and easy way of determining

combustion efficiency and stack loss from the results of the CO2

and stack temperature tests.

4. Tempoint®Dial Thermometer – High stack temperatures are

cause for special concern and may indicate a serious condition.

5. Model MZF Draft Gauge – The intensity of draft determines the

rate at which combustion gases pass through the boiler or

furnace. With the MZF Draft Gauge, you can determine if draft

is excessive or insufficient.

4. Draftrite®Draft Gauge – The hand-held Draftrite pinpoints draft

problems and determines chimney defects.

5. Tempoint®Dial Thermometer – With the Tempoint Dial

Thermometer, you can obtain an accurate stack temperature of

gas designed equipment.

6. Gas Service Calculator – The Gas Service Calculator determines

the orifice size needed for fuel gas of any specific gravity and

BTU value.

7. Gas Pressure Manometer – The Gas Pressure Manometer

determines if gas input and gas pressure adjustments are within

recommended limits.

8. Monoxor®Carbon Monoxide Detector – In some Testing Kits,

the Monoxor Carbon Monoxide Detector replaces the Monoxor

CO Indicator.

9. Carrying Case – Testing kit comes in a rugged, plastic

carrying case.

Bacharach®Combustion Testing Kits continue to offer you the most economical means of testing for oil burner

efficiency during installation or servicing. Each kit is designed with the service technician in mind and contains the

instruments listed in the ordering chart.

Components

1. Fyrite® Indicators; CO2and O2– The Fyrite Indicators are

utilized in conjunction with the Tempoint Dial thermometer

to determine efficiency calculation with the Fire Efficiency

Slide Rule.

2. Monoxor® CO Indicator – The Monoxor Indicator quickly and

easily tests CO concentrations in flue gas samples.

3. Fire Efficiency Finder/Stack Loss Slide Rule – The Fire

Efficiency Slide Rule provides a rapid and uncomplicated means

of determining combustion efficiency and stack loss from the

resultsof the CO2 and stack temperature tests.

6. Draftrite®Draft Gauge – In some Oil Burner Combustion Testing

Kits, the hand-held Draftrite replaces the Model MZF Draft Gauge

for measuring overfire and draft.

7. Carrying Case – Instruments for Bacharach Oil Burner

combustion Testing Kits come in a rugged, plastic carrying case.

Gas Burner Combustion Testing Kits

Headquarters: 621 Hunt Valley Circle, New Kensington, PA 15068 U.S.A.

Phone: 1-800-736-4666 Canada: 1-800-328-5217 E-Mail: [email protected] Website: www.bacharach-inc.com

Fyrite, True Spot, Tempoint, Monoxor, Draftrite and Bacharach are registered trademarks of Bacharach, Inc.

Product Bulletin-4171 08/03 10M DXC HPC

Printed in U.S.A.

* Export Kits are similar to standard kits except Fyrite Indicators are shipped without fluid installed. Draftrite, MZF Draft Gauge,

Manometer and Tempoint are supplied metric in most instances. Fluid for export kits must be purchased separately in three bottle cartons.

Distributed By:

OIL BURNER COMBUSTION TESTING KIT ORDERING INFORMATION

ITEM KIT STANDARD KIT EXPORT KIT*

NO. CONTENTS 10-5014 10-5002 10-5022 10-5036 10-5050 10-5150 10-5023 10-5037 10-5051

10-5064 Fire Efficiency Finder ■■■■■■

10-0100 Carrying Case (large) ■ ■■■■■■■

11-0121 Moisture Absorb. Material ■■■■■■■■■

11-7029 Sampling Hose Assembly ■■■■■■■■■

11-7032 Fyrite CO2 20%-Filled ■■■■■

12-7014 Tempoint Therm. 1000°(6” Stem) ■■■■ ■

13-7019 MZF Draft, +.05 to -.25”W ■■ ■

10-0099 Carrying Case (small) ■

13-3000 Draftrite, +.10 to -.14”W ■■

21-7006 True Spot Smoke Tester ■■■■■■■

12-7018 Tempoint Therm. 1000°(12” Stem) ■

13-7021 MZF Draft, +.05 to -1.0”W ■

10-5175 Stack Loss Calculator ■■■

11-7031 Fyrite CO2 20%-Unfilled ■■■■

12-7015 Tempoint Therm. 540°C (6” Stem) ■■

13-7020 MZF Draft, +1.0 to -2.5mmW ■■

13-7018 MZF Draft, +1.0 to -5mmW ■

12-7017 Tempoint Therm. 540°C (12” Stem) ■

GAS BURNER COMBUSTION TESTING KIT ORDERING INFORMATION

ITEM KIT STANDARD KIT EXPORT KIT*

NO. CONTENTS 10-5030 10-5035 10-5217 10-8008 10-5047 10-5224

10-0070 GAS SERVICE CALCULATOR ■■■ ■

10-5064 FIRE EFFICIENCY FINDER ■■■ ■

10-5067 HIGH EFFICIENCY FINDER ■■■

10-0100 CARRYING CASE ■■■■■■

11-0121 MOISTURE ABSORB. MATERIAL ■■■■■■

11-7029 SAMPLING HOSE ASSEMBLY ■■ ■■

11-7045 EXTENDED SAMPLING HOSE ASSEMBLY (10’) ■

11-7032 FYRITE CO2, 20% FILLED ■■■

11-7036 FYRITE O2, 21% FILLED ■■

12-7014 TEMPOINT THERMOMETER 1000°F (6”STEM) ■■■ ■

13-3000 DRAFTRITE +.10 TO .14”W ■■■ ■

17-7002 MANOMETER 15”W 8.5OZ/IN 2 ■■■ ■

19-0003 SAMPLING TUBE ATTACHMENT ■■■

19-7021 CO DETECTOR KIT ■■

11-7045 SAMPLING TUBE ASSEMBLY ■■ ■

19-0001 SPARE TUBE TIPS (6) ■■■■

19-0243 MONOXOR INDICATOR .2% ■■ ■

19-5015 CARTON OF 12 CO TUBES ■■ ■

10-5175 STACK LOSS CALCULATOR ■■

11-7031 FYRITE O2, 20% UNFILLED ■■■

11-7035 FYRITE O2, 21% UNFILLED ■■■

19-0242 MONOXOR INDICATOR .2%

19-5010 CARTON OF 12 CO TUBES

12-7015 TEMPOINT THERMOMETER 540°C (6”STEM) ■■

13-3002 DRAFTRITE +2.5 TO -3.5MM W ■

17-7000 MANOMETER 15”W, 38CMW ■■

13-3003 DRAFTRITE -6.5MM TO 1.5MM ■

19-7019 MONOXOR PUMP ■

19-5002 MONOXOR CO TUBES ■
