47'' Stone Fireplace
Model# SRFP41301
Instructions Manual
1
Table of Contents
Warnings............................................................................................ 2
Table of Contents................................................................................. 1
Tools Required .................................................................................. 4
Parts List ............................................................................................5
Hardware............................................................................................ 6
Assembly Instructions......................................................................... 7
Care and Maintenance......................................................................14
Warranty Information........................................................................ 15
REMINDER
BEFORE ASSEMBLY
Verify that all parts are included with your fireplace BEFORE you begin assembly by checking the Parts and
Hardware List. For your convenience, some parts may be pre-assembled or attached to fireplace components.
If all parts are not included, do not attempt to assemble fireplace. Call the toll free number on the
cover page for replacement parts.
Leave hardware installed HALF-TIGHTENED on the fireplace during assembly until unit is completely
assembled, then finish tightening all hardware installed.
YOUR OWNER’S MANUAL
Keep and store this Owner’s Manual for future reference – it contains important instructions and procedures
for safety and maintenance.
2
Warnings
WARNING
For Outdoor Use Only
(outside any enclosure)
WARNING
!
!
!
1. Improper Installation, adjustment, alteration, service, or maintenance may result
in property damage, injury or death.
2. Read the Installation, operation, maintenance instructions thoroughly before
installing or servicing this equipment.
3. Failure to follow these instructions could result in a fire or explosion, which
could cause property damage, personal injury or death.
WARNING
FOR YOUR SAFETY
2. This item is for outdoor use only, and shall NOT be used in a building, garage or any other
enclosed area.
3. DO NOT use this fireplace for indoor heating. TOXIC carbon monoxide fumes can accumulate
and cause asphyxiation or death.
4. This fireplace is NOT for commercial use.
5. This fireplace is NOT to be operated by children.
.selcihevlanoitaercerrostaobnoronidesuebotTONsifireplacesihT.6
7. Always use in accordance with all applicable local, state and national codes. Contact your
local fire department for details on outdoor burning.
8. When using this fireplace, exercise the same precautions you would with any open fire.
9. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s
ability to properly assemble or safely operate this fireplace.
10. This fireplace is for use with dry, seasoned hardwood. It will burn hotter, more completely
and create less smoke.
11. DO NOT burn charcoal briquette, lump charcoal, manufactured logs, driftwood, trash,
leaves, papers, cardboard, plywood, painted or stained or pressure treated wood.
Avoid using softwoods such as pine or cedar that can throw sparks.
12. DO NOT alter this fireplace in any manner.
13. DO NOT use this fireplace until it is COMPLETELY assembled and all parts are securely
fastened and tightened.
Save these instructions for future reference. If you are assembling this fireplace for someone else, give this
manual to him or her to save for future reference.
1. DO NOT use this fireplace without reading this entire document and all WARNINGS, cautions
and instructions.
3
Warnings
14. DO NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or
any other appliance.
15. DO NOT store or use an LP gas cylinder within10 feet (3.05m) of this fireplace while it is in
operation.
16. DO NOT use this fireplace near automobiles,trucks, vans or recreational vehicles.
17. DO NOT use in an explosive atmosphere. Keep outdoor area clean and free from
combustible materials, gasoline and other flammable liquids.
18. DO NOT use this fireplace under an overhead or near any unprotected combustible
constructions. Avoid using near or under overhanging trees and shrubs.
19. Always use this fireplace on a hard level non-combustible surface such as concrete, rock or
stone. An asphalt or blacktop surface may not be acceptable for this purpose. DO NOT use
on wooden decks.
20. Always empty this fireplace before each use.
21. DO NOT wear flammable or loose clothing when operating this fireplace.
22. DO NOT use in windy conditions.
.serifthgilerrotratsotdiulfrethgil,leufleseid,enesorek,enilosagesuTONOD.32
24. Keep all electrical cords away from a hot fireplace.
25. All surfaces of this fireplace are hot when in operation. To avoid burns, DO NOT touch fireplace
,sevolg,sredlohtop(raegevitcetorpgniraewerauoysselnudeloocyletelpmocsahtilitnu
BBQ mittens, hot pads etc). Never touch ashes or coals to see if they are hot.
26. DO NOT leave a lit fireplace unattended, especially around children and pets.
27. DO NOT attempt to move or store this fireplace until ashes and coals are completely
extinguished.
28. DO NOT remove ashes or coals until they are completely extinguished.
29. Use heat-resistant gloves or hot pads when contacting handles.
30. Use long, sturdy fireplace tools when adding or moving logs.
31. DO NOT place wood directly into bottom of the fireplace. Place wood only on the charcoal grid.
32. DO NOT overload the fireplace. DO NOT add additional firewood until the fire burns down.
33. DO NOT lean over this fireplace when lighting or when in use.
34. DO NOT place hot pit tools onto combustible surface such as grass, wooden deck or furniture.
35. Avoid breathing smoke from the fire and avoid getting it into your eyes.
36. This fireplace should be thoroughly inspected and cleaned on a regular basis.
37. After a period of storage and/or non-use, check for signs of damage and creosote build-up.
DO NOT operate until necessary repairs and/or clean up is executed.
38. Death, serious injury or damage to property may occur if the above is not followed exactly.
Tools Required
4
PictureDescription (Not included)
Phillips Head Screwdriver
Adjustable open end wrench
A
B
C
D
E
F
G
H
IJ
K
L
M
N
O
P
Q
Parts List
Part # Quantity
1A
1B
1C
D3
E
1
4
4
F
G
H
I
J
K
L
M
N
O
P
Q
1
1
Description Picture
Chimney cap
Roof
Panel 1
Connecting pole
Door spindle
Pin
Panel 2
Right door
Door holder
2
1
1
1
1
1
1
1
Door knob
Hook
Charcoal grid
Fire bowl
Base
Left door
Panel 3
Panel 4
5
Hardware
Picture Quantity
4
8
8
33
AA
BB
CC
DD
DescriptionHardware #
M5 x 35mm Bolt
M5 x 16mm Bolt
M5 x 12mm Bolt
ST5.5 x 13mm Bolt
1EE D6 Washer
4FF D5 Washer
12GG D5 Spring Washer
12HH M5 Nut
3II D6 Spring Washer
2JJ M6 Nut
NOTE: Before beginning assembly of product, make sure all parts are present. Compare parts
with package contents list and hardware contents above. If any part is missing or damaged,
do not attempt to assemble the product. Contact customer service for replacement parts.
6
Assembly Instructions
7
NOTE: Assemble the fireplace on a non-abrasive level surface.If missing parts please contact
customer service.
Step 1
Step 2
1
2
Attach Door knob (J) and Door
holder (I) to Right door (H) with
(2) D6 washer (EE), (2) D6 spring
washers (II), and M6 nut (JJ).
See Figure 2
Attach Door knob (J) to Left door (O)
with D6 spring washer (II) and M6
nut (JJ).
See Figure 1
Hardware Used
II D6 Spring Washer x 1
JJ M6 Nut x 1
JJ
JJ
EE
II
II
O
J
J
H
I
Hardware Used
II D6 Spring Washer x 2
x 1
JJ M6 Nut
EE D6 Washer
x 1
Assembly Instructions
8
Hardware Used
M5 x 12 Bolt x 3
ST5.5 x 13 Bolt x 10
D5 Spring Washer x 3
M5 Nut x 3
Step 3 3
Attach Panel 1 (C) and Panel 2 (G) to
Connecting pole (D) with
(10) ST5.5 x 13mm bolts (DD).
(3) M5 x 12mm bolts (CC), (3) D5 spring
washers (GG) and (3) M5 nuts (HH).
See Figure 3
CC
DD
GG
HH
D
G
C
DD
CC
DD
NOTE: Assemble the fireplace on a non-abrasive level surface.If missing parts please contact
customer service.
HH GG
Assembly Instructions
9
Step 4 4
Attach Panel 4 (Q) and Panel1 (C) to
Connecting pole (D) with
(10) ST5.5 x 13mm bolts (DD).
(2) M5 x 12mm bolts (CC), (2) D5 spring
washers (GG) and (2) M5 nuts (HH).
See Figure 4
Hardware Used
M5 x 12 Bolt x 2
ST5.5 x 13 Bolt x 10
D5 Spring Washer x 2
M5 Nut x 2
CC
DD
GG
HH
D
C
Q
DD
GG
HH
NOTE: Assemble the fireplace on a non-abrasive level surface.If missing parts please contact
customer service.
