B&C Speakers Extended Range 6 XT 13 Manuale utente

3

B&C

High efficency full range, ideal for voice

reproduction in compact monitor

Specifications

Nominal Diameter 170 mm (6.5 in.)

Nominal Impedance 8 Ω

Minumum Impedance 5.6 Ω

Power Handling

Nominal1120 W

Continuous Program2240 W

Sensitivity (1W/1m) 96 dB

Frequency Range 100-20000 Hz

Voice Coil Diameter 8 mm (1.5 in.)

Winding Material Aluminium

Former Material Fiber Glass

Winding Depth 8 mm (5/16 in.)

Magnetic Gap Depth 6 mm (1/4 in.)

Flux Density 1.25 T

Thiele Small Parameters2

Fs 98 Hz.

Re 5.4 Ω

Qes 0.7

Qms 4.1

Qts 0.6

Vas 7 dm. (0.25 cu. ft.)

Sd 1 2 cm.2(20.5 sq. in.)

η00.9 %

X max ± 1 mm.

Mms 10 gr.

Bl 6.8 Tm

Le 0.6 mH

Mounting and Shipping Informations

Overall Diameter 187 mm. (7.4 in.)

Bolt Circle Diameter 172 mm. (6.7 in.)

Baffle Cutout Diameter 145 mm. (5.7 in.)

Depth 78 mm. ( .1 in.)

Flange and Gasket Thickness 11 mm. (7/16 in.)

Net Weight (1 unit) 2. Kg. (5.1 lb.)

Shipping Weight (4 units) 10.5 Kg (2 .1 lb.)

Shipping Box (4 units) 405x225x210 mm

(15.9x8.8x8. in.)

1 2 hours test made with continuous IEC 268 shaped pink noise signal (6 dB crest

factor) . Power calculated on rated minimum impedance. Loudspeaker in free air.

2 Power on Continuous Program is defined as dB greater than the Nominal

rating.

Applied RMS Voltage is set to 2.8 V for 8 ohms and 4V for 16 ohms Nominal

Impedance. Average SPL from 200 to 20000 Hz.

4 Thiele-Small parameters are measured after a high level 20 Hz sine wave precon-

ditioning test.

6 XT 13 |Extended ange

Speakers Coaxials HF Compression drivers Horns

Questo manuale è adatto per i seguenti modelli
