B&C Speakers Midrange 6MD38 Manuale utente

6MD38 Midrange

LF Drivers LF Nd Drivers Coaxials HF Drivers Horns

240 W continuous program power capacity

38 mm (1.5 in) aluminium voice coil

150 - 6000 Hz response

96 dB sensitivity

Specification

Nominal Diameter 170 (6.5) mm (in)

Nominal Impedance (1) 8 Ohm

Minimum Impedence 6.5 Ohm

Nominal Power Handling (2) 120 W

Continuous Power Handling (3) 240 W

Sensitivity (1W/1m) (4) 96 dB

Frequency Range 150 - 6000 Hz

Voice Coil Diameter 38 (1.5) mm (in)

Winding Material Aluminium

Former Material Glass Fibre

Winding Depth 9 (0.35) mm (in)

Magnetic Gap Depth 6 (0.25) mm (in)

Flux Density 1.4 T

Thiele & Small Parameters

Fs 130 Hz

Re 5.7 Ohm

Qes 0.49

Qms 3.7

Qts 0.44

Vas 3 (0.1) dm3 (ft3)

Sd 132 (20.5) cm2 (in2)

Eta Zero 1.4 %

Xmax +/- 2 mm

Xvar +/- 4.5 mm

Mms 12 g

Bl 10.5 Txm

Le 0.25 mH

Mounting and Shipping Info

Overall Diameter 187 mm (7.4 in)

Bolt Circle Diameter 172 mm (6.7 in)

Baffle Cutout Diameter 145 mm (5.7 in)

Depth 82 mm (3.2 in)

Flange and Gasket Thickness 9 mm (0.35 in)

Net Weight 2.2 kg (4.8 lb)

Shipping Weight (4 units) 10.1 kg (22.2 lb)

Shipping Box (4 units) 405x225x210 mm

(15.9x8.8x8.3 in)

1For different impedances, please ask.

22 hours test made with continuous pink noise signal (6 dB crest factor).

Power calculated on rated minimum impedance.

3Power on Continuous Program is defined as 3 dB greater than the

Nominal rating.

4Applied RMS Voltage is set to 2.83V for 8 ohms or 2.0V for 4 ohms

Nominal Impedance
