BARRON GROWLITE GRM Manuale utente

GRM

INSTALLATION INSTRUCTIONS

800.533.3948 • www.barronltg.com

40070003 REV 2 - 09/17 1

INSTALLATION INSTRUCTIONS

CABLE MOUNTED

Ceiling

Screw Hole

Electric drill

Drill holes at desired location to

mount steel cables.

Secure fixture to the end of the

steel cables, using appropriate

hardware.

Steel

Cable

Connect steel cables to ceiling,

using appropriate hardware for

mounting surface.

Adjust to desired height, clean off

dust and debris.

IMPORTANT SAFEGUARDS

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure the electricity connections conform to the National Electrical Code and local regulations if applicable.

• Do not mount near gas or electrical heaters.

• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by

unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition. Any

modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

SAVE THESE INSTRUCTIONS!

GRM

INSTALLATION INSTRUCTIONS

800.533.3948 • www.barronltg.com

40070003 REV 2 - 09/17 2

Open hole

Ceiling

Electric drill

Drill holes at desired location to

mount steel cables.

Metal clip

LED light

Install fixture to clips.

Adjust postion of fixture if needed,

clean off dust and debris.

CEILING MOUNTED

ELECTRICAL CONNECTIONS

1. Connect power cord to 120VAC outlet.

Open hole

Metal clip

Screw

Screw driver

Fasten clips to the ceiling tightly,

using appropriate hardware for

mounting surface.

Locking

screw and nut

(provided)
