Bauhn HE214036 Manuale utente
Wi-Fi Power Point Controller
Model Number: HE214036
After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
INSTRUCTION MANUAL
Description goes here
The product is guaranteed to be free from defectsin workmanship and parts for a period
of 12 months from
the date of purchase.
Defectsthat occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded
at our discretion. The
benefits conferred by this warrantyare in addition to all rights and remediesin respect of
the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goodscome with guarantees that cannot be excluded under the Australian
Consumer Law.You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure doesnot amount to a major failure.
Wi-Fi Power Point Controller
Warranty Details
The product is guaranteed to be free from defects in workmanship and
parts for a period of 12 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benets conferred
by this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
3
After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Contents
Warranty 2
Contents 3
Welcome 4
General Safety Instructions 5
Product Features 6
Parts List / Technical Specications 7
Product Setup 8
Product Operation 17
Timers & Schedules 19
Troubleshooting Guide 27
FAQ’S 28
Repair and Refurbished Goods or Parts Notice 31
4After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Congratulations on choosing to buy a BAUHN® product. By doing so you
now have the assurance and peace of mind that comes with purchasing a
product made by one of the leading manufacturers. All products brought to
you by BAUHN® are manufactured to the highest standards of performance
and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 1 Year Warranty. We hope
you will enjoy using your purchase for many years to come.
Welcome
5
After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Read this manual thoroughly before rst use and keep it in a safe place for
future reference, along with the warranty card, purchase receipt and carton.
The safety precautions enclosed herein reduce the risk of re, electric shock
and injury when correctly adhered to. Follow all instructions and take notice
of all warnings to reduce the risk of re or electric shock.
• Indoor use only
• Do not exceed the maximum power rating 10A or 2400W
• Do not expose to water, dust, chemicals and moisture
• Keep away from heat sources and direct sunlight
• Children and inrm persons should use this device only under the
supervision of a responsible adult to control appliances safely
• Young children must be supervised to ensure they do not play with
this device.
• Do not operate or control heat producing devices connected to the
Wi-Fi Power Point Controller when unattended.
• Do not drop or subject the device to undue shock
• Do not attempt to service or disassemble. Attempting to open
or service the unit voids all warranties, express or implied. If you
experience problems with the device, discontinue use, unplug the
device from the wall outlet and contact Winplus After Sales Support
for assistance.
• Unplug this device during lightning storms or when unused for long
periods of time
General Safety Instructions
6After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Product Features
• Control the Wi-Fi Power Point Controller from anywhere, using your iOS
/ Android device*
• Check the current status of your Wi-Fi Power Point Controller from
anywhere, using your iOS / Android device*
• Easy to setup on your existing wireless network
• Set timers to activate your according to a schedule
• Control up to 150 Wi-Fi Power Point Controllers using one iOS / Android
device
• Gives you extra control to conserve energy
* Power Point Controller requires a Wi-Fi network. Mobile remote control
requires an iOS or Android device with Wi-Fi, 3G or 4G connection.
RATING: AC 240V 10A
TOTAL LOAD MUST NOT EXCEED 2400W
LED indicator
Socket
Operating button
7
After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Technical Specications
Voltage: 240V AC 50HZ
Max load current: 10A
Total load must not exceed 2400W
Working temperature: 0-50°C
Network: 802.11, b/g/n
Security: WPA-PSK / WPA2-PSK / WPA / WPA2 / WEP / WPS2 / WAPI
Encryption Type: WEP / TKIP / AES
Parts List
• Wi-Fi Power Point Controller
• Getting Started Guide
• Warranty Card
• Warranty Stickers
• Instruction Manual
8After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Product Setup
Before you can use your Wi-Fi Power Point Controller, it must be set
up using your Android/iOS device. Initial setup must be performed
using your home Wi-Fi network. Once it has been set up you can
control your power outlet via Wi-Fi/3G/4G.
Important: A current mobile service plan is required for correct
operation over 3G & 4G. Mobile data may be required for some
features. The supplier is not responsible for any charges incurred.
Please contact your network service provider for further information
about your current data plan and any associated charges.
Note: Consult your device’s instruction manual if you are unsure
how to download apps, connect to Wi-Fi or any other functions of
your Android or iOS device.
Software
The free SmartPoint App is available for Android and iPhone, and is required
to operate your Wi-Fi Power Point Controller.
1. Ensure your iOS / Android device is connected to the internet using your
home Wi-Fi network.
2. Open the App store on your phone.
3. Search for “SmartPoint” in the App store.
4. Download the SmartPoint controller App to your phone.
9
After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
Connecting the Wi-Fi Power Point Controller to your Wi-Fi network
Initial setup must be performed using your home Wi-Fi network.
1. Ensure your iOS / Android device is connected to your home Wi-Fi
network. Refer to your device manual for further details on connecting
your device to Wi-Fi.
2. Open the SmartPoint controller App on your iOS / Android device
3. Click the settings icon at the bottom of the screen, then select Smart
Setup
10 After Sales Support - Help Desk
Telephone: 1300 663 907
Internet: www.winplus.com.au
4. Your wireless network name (SSID) is shown in the smart setup screen
below is an empty eld to enter your Wi-Fi network password. Enter
your password into this box
SSID
