Bauhn S34B Manuale utente
User Guide
Manual
del usuario
OUTDOOR SPEAKER WITH
BLUETOOTH®TECHNOLOGY
ALTAVOZ
PARA
EXTERIORES
CON TECNOLOGÍA
BLUETOOTH®
English.....Page 3
Español.....Página 11
Contents
Important safety instructions.................................................................................4
General safety instructions....................................................................................5
Controls.................................................................................................................6
Using the speaker .................................................................................................7
Modes ...................................................................................................................8
Battery...................................................................................................................9
Contents..............................................................................................................10
Warranty card ......................................................................................................19
Warranty information ...........................................................................................20
AFTER SALES SUPPORT
service@801 service.net
4
1 866 558 8096
CAUTION:
To reduce the risk of electric shock, do not dismantle
this product. There are no user-serviceable parts inside.
Refer servicing to qualified personnel only.
EXPLANATION OF SYMBOLS:
The lightning flash within an equilateral triangle is intended to alert you
to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute an electric
shock to a person or persons.
The exclamation point within an equilateral triangle is intended to
alert you to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
To achieve the utmost in enjoyment and performance, and in order to become
familiar with its features, please read this user guide carefully before attempting
to operate this product. This will assure you years of trouble free performance and
listening pleasure.
IMPORTANT NOTES
This user guide should be retained for future reference.
Do not install the product in the following areas:
• Places exposed to direct sunlight or close to radiators.
• On top of other equipment that radiate too much heat.
• Blocking ventilation or in a dusty area.
• Areas where there is constant vibration.
• Near candles or other open ames.
Operate the product only as instructed in this guide.
For safety reasons, do not remove any covers or attempt to gain access to the inside
of the product. Refer any servicing to qualified personnel. Do not attempt to remove
any screws, or open the casing of the unit; there are no user-serviceable parts inside.
Refer all servicing to qualified service personnel.
Outdoor Speaker with Bluetooth® Technology Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AFTER SALES SUPPORT
1 866 558 8096
service@801 service.net
5
Outdoor Speaker with Bluetooth® Technology General Safety Instructions
All the safety and operating instructions must be read before the product is
operated.
All warnings on the product and in the user guide should be adhered to.
Install in accordance with the manufacturer’s instructions.
The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products, including amplifiers that produce heat.
Never push objects of any kind into this product through openings, as they may
touch dangerous voltage points or short-circuit parts that could result in a fire or
electric shock.
Only use attachments recommended by the product manufacturer, as they may
cause hazards.
Do not attempt to service this product yourself. Opening or removing covers may
expose you to dangerous voltage or other hazards.
Do not turn up the volume while listening to a section with very low level inputs or no
audio signals. If you do, the speaker may be damaged when a peak level section is
suddenly played.
WARNING:
This speaker is not intended for use by persons (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the speaker. THIS IS NOT A TOY.
• The unit is not intended to be operated by means of an external timer or separate
remote control system.
• Do not cover the ventilation opening with items such as newspaper, tablecloths,
curtains etc.
• Do not place this unit close to a strong magnetic eld.
• Do not attempt to clean the unit with chemical solvents as this might damage the
finish. Wipe with a clean, dry or slightly damp cloth.
• Do not place speaker too close to ears, it may cause damage to ear drums, espe-
cially in young children. Use this appliance only for its intended use as described
in this manual. Bauhn is not liable for any damage caused to iPod/MP3 player or
any other device. Do not place or store appliance where it can fall or be pulled into
a bath or sink. Do not place in or drop into water or any other liquids.
AFTER SALES SUPPORT
service@801 service.net
6
1 866 558 8096
Outdoor Speaker with Bluetooth® Technology Controls
LOCATION OF CONTROLS
1. Power ON/OFF
2. Play & Pause/ Pairing
3. Previous
4. Next
5. Volume down (-)
6. Volume up (+)
7. LED Bluetooth®(Blue)
8. LED charge (yellow)
9. LED display
10. AUX IN Jack
11. Micro USB charge port
AFTER SALES SUPPORT
1 866 558 8096
service@801 service.net
7
Outdoor Speaker with Bluetooth® Technology Using the Speaker
Turn on the unit
Press power button (1) for one second, the LED display (9) will flash
on as below.
BLUETOOTH
®
OPERATION
1. The LED display (9) will show “Bt” and the
LED Indicator (7) will flash at a slow speed.
2. Press and hold PAIR (2) button about 3
seconds and the LED display (9) will show
“PAIr”, and the LED Indicator (7) will ash
at a fast speed.
3. Turn on the Bluetooth
®
function on your
Bluetooth
®
device and start to scan. Select
and activate “Bauhn BT Outdoor” on the
menu list of your Bluetooth
®
device, the LED
display (9) will show “CONN”.
4. Adjust the volume button - (5) or + (6) of the
main unit to your desired level.
5. Adjust tracks using button previous (3)
or next (4).
Turn off the Bluetooth
®
function in your mobile
device to disconnect Bluetooth
®
. Unit will go
back to display Bt on display.
Note:
The Bluetooth
®
works best within a range of
30 Feet (9.144 meters).
BLUETOOTH
®
CONNECT
BLUETOOTH
®
PAIRING
BLUETOOTH
®
MODE
AFTER SALES SUPPORT
service@801 service.net
8
1 866 558 8096
Outdoor Speaker with Bluetooth® Technology Modes
LINE IN MODE OPERATION
(AUX MODE)
Connect the supplied 3.5mm cable
into the AUX IN jack (10) on the rear
panel of the speaker and connect the
other end into the audio source player.
Display will show LINE.
OFF MODE
The unit will go to power OFF mode automatically after 15 minutes if there
is no play mode selection. The LED display will turn completely off after
another 15 minutes in order to save power. You can press the power ON/OFF
(button 1) to resume using the unit.
POWER AND CHARGING OPERATION
The speaker can operate with the built-in rechargeable battery. To charge the
built-in battery, please reference below:
• Insert one end of supplied USB cable into the micro USB charge port (11)
on the rear panel of the unit. The USB connector needs to be connected
with universal USB power source like a laptop, PC etc.
• When the unit starts to charge, the front LED indicator (8) will turn yellow.
LED indicator (8) will turn off after the battery is fully charged.
• The battery charging time is about 3-5 hours.
• When you do not want to listen to music for a long period of time, we
suggest you press the Power ON/OFF button for 3 seconds to turn unit off
to save battery power.
AUX MODE
AFTER SALES SUPPORT
1 866 558 8096
service@801 service.net
9
Outdoor Speaker with Bluetooth® Technology Battery
Battery lifetime will last longer if you follow guidelines below for charging and storing.
• The speaker has a built-in rechargeable battery. Make sure the battery has been
fully charged before first use.
• The rst battery charge may take up to 10 hours. The battery will have a better
performance after 3 full charges and discharges. It is better to charge the unit only
after it is completely discharged.
• Recharge and store the unit within the temperature range of 40°F–95°F (05°C–35°C)
• Do not charge the battery for a period longer than 24 hours. Excessive charging may
shorten the battery’s life.
• Turn off the speaker if you are not going to use it for a long period of time.
The display will show ”LO-BATT” when the speaker’s battery power is too low. The
speaker will switch off automatically due to insufficient power. Please follow the user
guide for charging. The speaker cannot work if there is no power in the battery. You
may charge it for a while and then try to switch on again to resume playback.
Important note:
This device is equipped with an energy saving mode: if no signal is given during
15 minutes the device will switch automatically into standby mode in order to save
energy (ERP 2 standard). Please note that low volume setting in the audio source may
be recognized as “no audio signal”: this will affect the capability of signal detection
from the device and can also originate an automatic switch into standby mode. If this
happens, please reactivate the audio signal transmission or increase the volume setting
on the audio source player (MP3 player, etc.), in order to resume playback.
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end
of its life separately from your household waste. There are separate
collection systems for recycling. For more information, please
contact your local authority.
AFTER SALES SUPPORT
service@801 service.net
10
1 866 558 8096
Outdoor Speaker with Bluetooth® Technology Contents
CONTENTS:
Outdoor Speaker with Bluetooth
®
Technology
User Manual
AUX IN Audio Cable
USB Charge Cable
The Bluetooth
®
word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Hands (IP) Holdings
Pty Ltd is under license. Other trademarks and trade names are those
of their respective owners.
FCC STATEMENT:
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
Please note that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. In case of interference, try to correct the interference by one
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult an experienced radio/TV technician for help or contact our after sales
support line for help.
Indice
Lingue:
Altri manuali Bauhn Altoparlanti
Bauhn
Bauhn ASB2-0316 Manuale utente
Bauhn
Bauhn ASB-0319 Manuale utente
Bauhn
Bauhn AOBS-0216 Manuale utente
Bauhn
Bauhn ARSR-1116 Manuale utente
Bauhn
Bauhn ASBWS-0719 Manuale utente
Bauhn
Bauhn ASBB-114 Manuale utente
Bauhn
Bauhn M600D Manuale utente
Bauhn
Bauhn APPS-0322 Manuale utente
Bauhn
Bauhn ADS10-014 Manuale utente
Bauhn
Bauhn APPS-0721 Manuale utente
