Behringer SL4210 Manuale utente

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

Features Product Overview

The EUROCOM SL4210 is a professional surface-mount

loudspeaker system that is ideal for a wide variety of interior

xed installation applications involving background music,

AV playback, or distributed sound reinforcement. Oered

as part of the SL Series of complementary surface-mount

loudspeakers, the SL4210 delivers sound in a compact

package that ts easily and unobtrusively into limited space.

Power taps are provided for high-impedance operation at

1.25, 2.5, 5, or 10 W for 70 V systems, and 2.5, 5, or 10 W for

100 V systems.

Housed in a ported enclosure of low-resonance molded

composite, the SL4210 leaves behind the boxy shape

of traditional surface mount speakers, oering instead

a sleek look with smooth curves that enhance the

ambiance of any location. The front face is nished

with a detachable foam-backed wire-mesh steel grille,

availablein black or white, that is trimmed with an elegant

smoked-chrome rim. The innovative SL Series mounting

yoke (included) oers 180degrees pan, 90degrees tilt,

allowing for for optimum loudspeaker aiming.

Combining performance and versatility in a compact, stylish

loudspeaker that looks good anywhere, theEUROCOM SL4210

is an excellent choice for any surface-mounted installation

requiring top quality sound and exceptional value.

• High-performance, surface-mountable loudspeaker for

foreground music, AV playback and distributed sound

• Exceptional sound quality with wide frequency

bandwidth and uniform dispersion

• 10-Watt, 3.5" x 1.18" Loudspeaker driver provides

exceptionally wide frequency response and ultra-wide

150° dispersion

• Professional 5-pole Euroblock connector

• 70.7V taps @ 1.25, 2.5, 5 & 10 Watts,

100V taps @ 2.5, 5 & 10 Watts

• Contemporary composite enclosure for

low-resonance performance

• Included dual-axis mounting hardware provides

90° V and 180° H alignment

• Detachable powder-coated steel grille and

contemporary aesthetic compliments any decor

• Weather resistant design for use in indoors or

protected outdoor areas

• High-quality components and exceptionally rugged

construction ensure long life

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

Technical Specications

• Frequencyrange 120Hz-20kHz

(-10dB)

• Frequencyresponse 150Hz-18kHz

(±3dB)

• Nominaldispersion 150˚

• DirectivityFactor(Q) 3.0(avg.500Hz-16kHz)

• DirectivityIndex(DI) 4.7dB(avg.500Hz-16kHz)

• Sensitivity 80dB

(1W@1mpassive,

half-space)

• Maximumcontinuous 90dB@1m

SPL(passive)

• Maximumpeak 96dB@1m

SPL(passive)

• Transformer 70V:10W,5W,2.5W,1.25W

100V:N/C,10W,5W,2.5W

Transducers:

• Driver 3.5"x1.18"(30mmx90mm)

• Powerhandling 10WRMS

(longterm)

• Enclosure Plastic

• Grille Powder-coatedsteel

• Termination 5-pinEuroblockconnector

• Dimensions(HxWxD) appr.6x3.8x3.9"/152x97x101.5mm

• Weight appr.1.45lbs/0.66kg

• Includedaccessories PowdercoatedCbracketand

associatedhardware

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

The loudspeaker shall be a professional full-range loudspeaker system in a ported composite enclosure designed for

surface-mounting.

Driver for the loudspeaker system shall be a single 3.5" x 1.18" rectangular driver.

Enclosure for the loudspeaker system shall be constructed of low-resonance molded composite. The enclosure shall

be nished with durable, scu-free black or white paint. Thefront of the enclosure shall be protected with a detachable

wrap-around steel wire-mesh grille with foam backing. The back of the enclosure shall have a recessed receptacle in which

the connector shall belocated.

Mounting bracket shall be supplied with the loudspeaker system. The bracket shall allow aiming in both axes

(180 degrees pan, 90degrees tilt). The bracket shall mount to an included wallplate.

Electronics The loudspeaker system shall also include a transformer accessable via a 5 position euroblock connector that

sets the loudspeaker to operate at one of the supported wattages for high-impedance operation. Transformer taps at 70 V

shall be 10, 5, 2.5 and 1.25 W. Transformer taps at 100 V shall be 10, 5, and 2.5 W.

Connection to the loudspeaker system shall be via a 5-pin Euroblock connector on the input plate.

Performance criteria met by the loudspeaker system shall include:

• Sensitivity (1 W/1 m, half-space) of 80 dB

• Usable frequency range (-10 dB) of 120 Hz - 20 kHz

• Frequency response (-3 dB) of 150 Hz - 18 kHz

• Power Handling (pink noise) of 10 W RMS

• Maximum SPL (1 m) of 90 dB continuous and 96 dB peak

Physical characteristics of the loudspeaker system shallbe:

• Height x Width x Depth of 6 x 3.8 x 3.9" / 152 x 97 x 101.5 mm

• Net weight of not more than 1.45 lbs / 0.66 kg

The loudspeaker system shall be the BEHRINGER EUROCOM SL4210.

Architect’s and Engineer’s Specications

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH



Beamwidth VS. Frequency

Frequency Response, 1 W @ 1 M

Horizontal Oﬀ-Axis Frequency Response

Vertical Up Oﬀ-Axis Frequency Response

Vertical Down Oﬀ-Axis Frequency Response

Directivity Index, Q

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

Vertical 1/3 Octave Polars

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

Horizontal 1/3 Octave Polars

Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker

SL4210/SL4210-WH

Copyright © 2013 MUSIC Group IP Ltd. All rights reserved. BEHRINGER, KLARKTEKNIK, MIDAS, BUGERA, andTURBOSOUND are part of the MUSIC Group (music-group.com). The information contained herein is correct at the time of

printing.Technical speciﬁcations and appearance are subject to change without notice. Colors and speciﬁcations may vary from actual product. MUSIC Group IP Ltd. accepts no liability for any damages or loss which may be suﬀered

by any person who relies either wholly or in part upon any description, photograph or statement contained herein. All trademarks are the property of their respective owners. Products are sold through authorized Fulﬁllers and

Resellers only. Fulﬁllers and Resellers are not agents of MUSIC Group IP Ltd. or any of its aﬃliates and subsidiaries, and have absolutely no authority to bind MUSIC Group IP Ltd. by any express or implied undertaking or representation.

MUSIC Group IP Ltd. Trident Chambers,Wickhams Cay, P.O. Box 146, Road Town,Tortola, BritishVirgin Islands.

Dimensional Drawings

TOP FRONT SIDEREAR

114.00 mm [4.49 in]

49.00 mm [1.93 in]

114.00 mm [4.49 in]

4.50 mm [ 0.18 in]

97.00 mm [3.82 in]

152.00 mm [59.84 in]
