Belden Hirschmann GREYHOUND GRS1042 Manuale utente

Installation GREYHOUND Switch

Release

10/2020

Technical support

https://hirschmann-support.belden.com

User Manual

Installation

GREYHOUND Switch GRS1042/GRS1142

GREYHOUND Power supply module GPS1-C/GPS1-K/GPS3-P

GREYHOUND Media module GMM20/30/32/40/42

01.10.2020 Installation GREYHOUND Switch

Release

10/2020

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation GREYHOUND Switch

Release

10/2020 3

Contents

Important information 6

Safety instructions 7

About this Manual 17

Legend 18

1 Description 19

1.1 General device description 19

1.2 Device name and product code 22

1.2.1 Basic device 22

1.2.2 Power supply modules 24

1.2.3 Media modules 25

1.3 Device views 27

1.3.1 GRS1042 27

1.3.2 GRS1142 28

1.3.3 Power supply modules 30

1.3.4 Media modules 31

1.3.5 Port assignments 34

1.4 Power supply 35

1.5 Signal contact 37

1.6 Ethernet ports 37

1.6.1 1/2.5 Gbit/s F/O port 37

1.6.2 100/1000 Mbit/s F/O port 38

1.6.3 100 Mbit/s F/O port 38

1.6.4 10/100/1000 Mbit/s twisted pair port 39

1.6.5 Support of PoE(+) 39

1.6.6 Out-of-band management port 40

1.7 Pin assignments 40

1.8 Display elements 41

1.8.1 Device state 42

1.8.2 Port status 44

1.8.3 Media module status 46

1.9 Management interfaces 48

4Installation GREYHOUND Switch

Release

10/2020

1.9.1 V.24 interface (external management) 48

1.9.2 USB interface 49

1.9.3 SD card interface 50

2 Installation 51

2.1 Checking the package contents 51

2.2 Installing the SD card (optional) 51

2.3 Installing a power supply module 52

2.4 Installing a media module (optional) 53

2.5 Installing a cover panel (optional) 54

2.6 Installing and grounding the device 54

2.7 Connecting the terminal blocks 59

2.7.1 Supply voltage 59

2.7.2 Signal contact 64

2.8 Installing an SFP transceiver (optional) 65

2.9 Operating the device 66

2.10 Connecting data cables 66

2.11 Filling out the inscription label 66

3 Making basic settings 67

3.1 First login (Password change) 68

4 Monitoring the ambient air temperature 69

5 Maintenance and service 70

6Disassembly 71

6.1 De-installing a power supply module 71

6.2 Removing a media module 72

6.3 Removing an SFP transceiver (optional) 73

6.4 Removing the device 73

7 Technical data 74

7.1 General technical data 74

7.1.1 Basic device 74

7.1.2 Power supply modules 76

Installation GREYHOUND Switch

Release

10/2020 5

7.1.3 Media modules 77

7.2 Dimension drawings 78

7.3 EMC and immunity 82

7.4 Network range 85

7.5 Power consumption/power output 89

8 Scope of delivery, order numbers and

accessories 90

9 Underlying technical standards 93

A Further support 95

6Installation GREYHOUND Switch

Release

10/2020

Important information

Note: Read these instructions carefully, and familiarize yourself with the

device before trying to install, operate, or maintain it. The following notes may

appear throughout this documentation or on the device. These notes warn of

potential hazards or call attention to information that clarifies or simplifies a

procedure.

Symbol explanation

This is a general warning symbol. This symbol alerts you to

potential personal injury hazards. Observe all safety notes that

follow this symbol to avoid possible injury or death.

If this symbol is displayed in addition to a safety instruction of the

type “Danger” or “Warning”, it means that there is a danger of

electric shock and failure to observe the instructions will

inevitably result in injury.

This symbol indicates the danger of hot surfaces on the device.

In connection with safety instructions, non-observance of the

instructions will inevitably result in injuries.

DANGER

DANGER draws attention to an immediately dangerous situation, which will

inevitably result in a serious or fatal accident if not observed.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

CAUTION indicates a possible danger which, if not avoided, may result in

minor injuries.

NOTICE

NOTE provides information about procedures that do not involve the risk of

injury.

Installation GREYHOUND Switch

Release

10/2020 7

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious injury,

or equipment damage.

8Installation GREYHOUND Switch

Release

10/2020

Correct usage

Only use the device for those purposes specified in the catalog and in the

technical description. Only operate the device with external devices and

components that are recommended and permitted by the manufacturer.

The proper and safe operation of this product depends on proper handling

during transport, proper storage, assembly and installation, and

conscientious operation and maintenance procedures.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

Requirements for connecting electrical wires

Before connecting the electrical wires, always verify that the

requirements listed are complied with.

Requirements for connecting the signal contact

The following requirements apply without restrictions:

The electrical wires are voltage-free.

The cables used are permitted for the temperature range of the application case.

First connect the ground screw on the back of the device with the protective conductor

before you set up the other connections. When removing the connections, you remove the

protective conductor last.

Exclusively switch on the device when it is installed.

Relevant for North America:

Exclusively use 60/75 °C (140/167 °F) or 75 °C (167 °F) copper (Cu) wire.

Table 1: Requirements for connecting electrical wires

The following requirements apply without restrictions:

Limit the connected voltage with a current limitation or in accordance with its application.

Observe the electrical threshold values for the signal contact.

See “General technical data” on page 74.

Table 2: Requirements for connecting the signal contact

Installation GREYHOUND Switch

Release

10/2020 9

Requirements for connecting the supply voltage

Device variant Prerequisites:

All variants All of the following requirements are complied with:

The supply voltage corresponds to the voltage specified on the type plate

of the device.

The power supply conforms to overvoltage category I or II.

The power supply has an easily accessible disconnecting device (for

example a switch or a plug). This disconnecting device is clearly identified.

So in the case of an emergency, it is clear which disconnecting device

belongs to which power supply cable.

For supply voltage connections with protective conductor connection: First

connect the protective conductor before connecting the wires for the

supply voltage.

If your device comprises a 2nd supply voltage connection of this type: First

connect the protective conductor before connecting the wires for the

supply voltages.

Supply with DC voltage:

The wire diameter of the power supply cable is at least 1 mm² (North

America: AWG16) on the supply voltage input.

Supply with AC voltage:

The wire diameter of the power supply cable is at least 0.75 mm² (North

America: AWG18) on the supply voltage input.

The cross-section of the ground conductor is the same size as or bigger

than the cross-section of the power supply cables.

Use a power supply cable which is suitable for the voltage, the current and

the physical load.

Install an external fuse in the conductor that is not on ground potential.

Power supply

module

characteristic

value C

All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) as per IEC/EN 60950-1.

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Regarding the properties of this fuse:

See “Technical data” on page 74.

Table 3: Requirements for connecting the supply voltage

10 Installation GREYHOUND Switch

Release

10/2020

Power supply

module

characteristic

value K

All of the following requirements are complied with:

Supply with DC voltage:

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Connect the minus conductor to the ground potential. If the minus

conductor is not connected to the ground potential, also install an external

fuse in the minus conductor.

Regarding the properties of this fuse:

See “Technical data” on page 74.

Supply with AC voltage:

Install a fuse in the outer conductor of the power supply.

Connect the neutral conductor to the ground potential. If the neutral

conductor is not connected to the ground potential, also install an external

fuse in the neutral conductor.

Regarding the properties of this fuse:

See “Technical data” on page 74.

Power supply

module

characteristic

value P

All of the following requirements are complied with:

The power supply complies with the requirements for a safety extra-low

voltage (SELV) as per IEC/EN 60950-1.

The power supply is potential-free. For power supply modules capable of

PoE, exclusively use a potential-free SELV power supply.

Install a fuse suitable for DC voltage in the plus conductor of the power

supply.

Regarding the properties of this fuse:

See “Technical data” on page 74.

With redundant power supply: A positive grounding is prohibited.

Device variant Prerequisites:

Table 3: Requirements for connecting the supply voltage

Altri manuali per Hirschmann GREYHOUND GRS1042

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Belden Interruttore

Belden

Belden HIRSCHMANN RSP20 Manuale utente

Belden

Belden Hirschmann OCTOPUS 8TX PoE-EEC Manuale utente

Belden

Belden Hirschmann SPIDER Standard Line Series Manuale utente

Belden

Belden Hirschmann MACH104-PoEP Series Manuale utente

Belden

Belden Hirschmann SPIDER II 8TX Manuale utente

Belden

Belden Hirschmann MACH1040 Series Manuale utente

Belden

Belden HIRSCHMANN OCTOPUS OS24 Series Manuale utente

Belden

Belden grass valley GV FABRIC Manuale utente

Belden

Belden Telecast Fiber Systems THOR-SLG Manuale utente

Belden

Belden Hirschmann MACH4002 Series Manuale utente

Belden

Belden Hirschmann SPIDER 8TX EEC Manuale utente

Belden

Belden Grass Valley K-Frame Come usare

Belden

Belden Hirschmann RS20 Series Manuale utente

Belden

Belden Hirschmann MICE MS20 Manuale utente

Belden

Belden MAMMUTHUS MTM2800-PSU120 Manuale utente

Belden

Belden Hirschmann SPIDER-SL-20-01T1S29999SZ9HHHH Manuale utente

Belden

Belden Hirschmann MACH102 Series Manuale utente

Belden

Belden HIRSCHMANN BRS20 Manuale utente

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTS2948X-6Q-A Manuale utente

Belden

Belden HIRSCHMANN MACH 100 Series Manuale utente

Belden

Belden Hirschmann RS20 Series Manuale utente

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTS2948X-6Q-A Manuale utente

Belden

Belden ThinkLogical TLX12 Manuale utente

Belden

Belden Hirschmann IT MAMMUTHUS MTS26 Series Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
