User Guide for the

Portable PDA Keyboard

for Palm™m500

series Handhelds

P73836 F8P3501

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 1

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 2

Belkin Portable PDA Keyboard

Section Page

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installing the Driver . . . . . . . . . . . . . . . . . . . .4

Using the Keyboard . . . . . . . . . . . . . . . . . . . .5

Adjusting the Keyboard Settings . . . . . . . . . . .7

Keyboard Shortcuts . . . . . . . . . . . . . . . . . . . .11

FCC/CE/Warranty Statement . . . . . . . . . . . . .17

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 3

Introduction

Congratulations! You have just purchased the

definitive tool to extend your handheld computer’s

capabilities. The Belkin Portable PDA Keyboard will

give you an easy and convenient way to add data to

your Palm™m500 Series Handheld.

Designed for the mobile professional, the Belkin PDA

Keyboard weighs in at only seven ounces and folds

small enough to fit easily into a coat pocket or travel

case. With Plug-and-Play convenience, and

unparalleled compatibility, you’ll enjoy the

most reliable and flexible PDA keyboard

solution available.

For our complete selection of PDA accessories and

mobile enhancements, please visit us at belkin.com.

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 2

Features

• Application buttons accessible right from

the keyboard

• Built-in docking; no cables required

• Generous key spacing and comfortable key

travel to facilitate touch typing

• Folds to pocket-size, weighing less than

seven (7) ounces

• Plug-and-Play for simplicity

• Easy-to-install driver included

• Includes protective carrying case for keyboard

and adapter

• Quality and durability backed by a Belkin

Three-Year Limited Warranty

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 3

Installing the Driver

Note: Before beginning any installation procedure,

always backup your data in this case, perform a

HotSync™operation of your handheld’s

information to your computer.

Installing the Keyboard driver with

a Windows PC

1. Insert the Belkin PDA Keyboard Driver diskette

into the A: Drive.

2. Double-click on the My Computer icon on your

Windows Desktop.

3. Double-click on the Floppy (A:\) Driver icon.

4. Double-click on the belkin.prc icon, this will

launch the Palm

Desktop install tool.

5. Select the Driver

(belkin.prc) to be

installed by clicking

on it once.

6. Click Done. The Driver

will be installed on

your handheld the next

time you perform a

HotSync function.

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 4

Using the Keyboard

A – Open the Keyboard.

1. While holding the Keyboard,

depress the latch to open

the case.

2. Unfold the Keyboard to its full size.

3. Holding the red-bordered sides of the

Keyboard, slide the right half toward the left

until the two sides come together.

4. Slide the docking bracket out from the Keyboard

until it is fully extended. Lift the support bracket

up and push the rear support out into one of the

support slots. You can adjust the bracket support to

the desired viewing angle.

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 5

Using the Keyboard (continued)

5. Next, slide your handheld onto the

docking connector gently until it is

firmly in place. Your PDA will power

on automatically. Tilt it upward and

position the flat support to the

desired angle.

6. To remove the handheld after use, tilt

the PDA forward while holding down the

keyboard until you hear the connector “click”.

Then, gently lift off the keyboard.

7. Fold down the connector support

and slide in back to its storage

position.

8. Refold the Keyboard and place

it back into its protective

storage case.

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 6

Adjusting the Keyboard Settings

Adjust your keyboard for your specific uses

1. Select the Applications icon.

2. Select the Keyboard icon.

Key Repeat Rate: Select the position to designate the

speed at which a character is repeated when you

hold down the key (1 to 10, slow to fast).

Delay Until Repeat: Set the lag time from the

moment of depressing a key to the point at which it

begins being automatically repeated by the user

holding it down.

Test Repeat Setting: A

handy trial area in which

to apply the above

settings before exiting the

general settings screen.

Enable Key Clicks:

Enables a clicking

sound as you type.

Enable Keyboard: Enables

the keyboard. (The "on" position is the default.)

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 7

Adjusting the Keyboard Settings

Assigning combination commands

You can open applications Address Book, Memo Pad,

Date Book, and To Do List using the four buttons

located at the top right of your Portable PDA

Keyboard. You can also use combination commands

that you create and assign.

1. Select the Application icon.

2. Select the Keyboard icon.

3. Select the menu in the

upper-right corner of

the screen and choose Cmd Keys.

P73836-F8P3501-pkg.qxd 5/23/02 2:01 PM Page 8
