Besantek BST-ET16 Manuale utente

BESANTEK GROUND TESTER









     



  ., .'

 

 120

MANUAL

Besantek Corporation

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

CONTENT

I.Attention ...................................................................................... 1

II. Brief Introduction........................................................................ 2

III. Specification.............................................................................. 3

1．Model................................................................................. 3

2. Ranges and Accuracy of Measurement.............................. 3

3. Specifications...................................................................... 4

IV. Structure of Meter...................................................................... 5

V. Liquid Crystal Display................................................................. 6

1. LCD Screen......................................................................... 6

2. Description of Special Symbols.......................................... 6

3. Examples Illustrated............................................................ 7

VI. Operating Method..................................................................... 8

1.Boot up................................................................................. 8

2．Shutdown........................................................................... 9

3．Resistance Measurement ............................................... 10

4．Current Measurement......................................................11

5．Date Lock/Release/Storage .............................................11

6．Data Access..................................................................... 12

7．Alarm Settings................................................................. 12

8．Access to Alarm Critical Value ........................................ 13

9．Clear Data ....................................................................... 13

VII. Measurement Principle.......................................................... 13

1. Principle of Resistance Measurement.............................. 13

2. Principle of Current Measurement.................................... 14

Ⅷ. Measurement Method of Earth Resistance............................ 14

1. Multi-Point Grounding System.......................................... 14

2. Limited Point Grounding System...................................... 15

3. Single-Point Grounding System........................................ 16

Ⅸ. Bill of Loading......................................................................... 18

Ⅹ. Parts List and Assembly Details............................................. 19

1. Parts List........................................................................... 19

2. Assembly Details............................................................... 20

Ⅺ.Trouble shooting...................................................................... 21

-1-

I. Attention

Thank you for purchasing this ground tester from our company. In

order to make better use of the product, please be certain:

----To read this user manual carefully.

----To comply with the operating cautions presented in

this manual.

1 Under any circumstances, use the Meter should pay special

attention to safety.

2 Pay attention to the measurement range of the Meter and the

using environment provided.

3 Pay attention to the text labeled on the panel and back plane

of the Meter.

4 Before booting up, the trigger should be pressed for 1-2 times

to ensure the jaws are well closed.

5 At Boot time, DO NOT press the trigger, nor clamp any wire.

6 Before the auto inspection is completed and the "OL Ω"

symbols are showed, the measured objects cannot be

clamped on.

7 The jaw planes contact must be maintained clean, and should

not be polished with corrosive and rough materials.

8 Avoid any impact onto this Meter, especially the Jaw contact

surface.

9 This Meter will have some buzzing sound in measurement

process, and it is normal.

10 The measurement current of the wire should not exceed the

upper limit of the Meter.

11 Please take out the batteries in the case of the Meter being

idle for a long time.

12 The dismantling, calibration and maintenance the Meter shall

be operated by the authorized staff.

13 If the continuing use of it would be dangerous, the Meter

should be stopped using immediately, and immediately sealed

for the treatment by the authorized agencies.

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

-2-

II. Brief Introduction

Its performance is mainly reflected in:

Breakthrough in self-test the boot a long time to wait, start

immediately into the test.

Breakthrough relay self-test mode, using the most

advanced processing algorithms and digital integration

technology, a fully intelligent.

Break the old product to heavy issues, more in line with

characteristics of handheld devices.

New design, panel operation with 6 buttons, better

performance.

An increase of sound and light alarm, "beep—beep--beep

--" alarm sound.

Increase the interference signal recognition indicator.

Improved anti-jamming capability and test stability.

Stored data: 99 Units.

Wider range: 0.01Ω-1200Ω

Lower power consumption: Maximum operating current

not exceeding 50mA.

The ground tester is widely used in the grounding resistance

measurement of the power, telecommunications, meteorology,

oilfield, construction and the industrial and electrical equipment. In

the measurement of a grounding system with loop current, does

not require breaking down the grounding wire, and need no

auxiliary electrode. It is safe, fast and simple in use.

The ground tester can measure out the faults beyond the

reach of the traditional methods, and can be applied in the

occasions not in the range of the traditional methods.

The ground tester can measure the integrated value of the

grounding body resistance and the grounding lead resistance.

-3-

III. Specification

1．Model

Model Jaw

specification Range of

measurement Range of

current Storage

function Alarm

function

BST-ET16 65mm×32mm 0.01Ω-1200Ω 0.0mA-20.0A 99 Units √

BST-ET17 φ32mm 0.01Ω-1200Ω 0.0mA-20.0A 99 Units √

BST-ET18 65mm×32mm 0.01Ω-1200Ω 0.0mA-30.0A 99 Units √

BST-ET19 φ32mm 0.01Ω-1200Ω 0.0mA-30.0A 99 Units √

Note: “√” means available.

2. Ranges and Accuracy of Measurement

Mode Range Resolution Accuracy

Resistance

0.010Ω-0.099Ω 0.001Ω ±（1%＋0.01Ω）

0.10Ω-0.99Ω 0.01Ω ±（1%＋0.01Ω）

1.0Ω-49.9Ω 0.1Ω ±（1%＋0.1Ω）

50.0Ω-99.5Ω 0.5Ω ±（1.5%＋0.5Ω）

100Ω-199Ω 1Ω ±（2%＋1Ω）

200Ω-395Ω 5Ω ±（5%＋5Ω）

400-590Ω 10Ω ±（10%＋10Ω）

600Ω-880Ω 20Ω ±（20%＋20Ω）

900Ω-1200Ω 30Ω ±（25%＋30Ω）

Current

(True-RMS)

0.00mA -9.00mA 0.05mA ±（2.5%＋2mA）

10.0mA -99.0mA 0.1mA ±（2.5%＋10mA）

100mA -300mA 1mA ±（2.5%＋20mA）

0.30A-2.99A 0.01A ±（2.5%＋0.1A）

3.0A-9.9A 0.1A ±（2.5%＋0.5A）

10.0A-20.0A 0.1 A ±（2.5%＋1 A）

20.0A-30.0A 0.1 A ±（2.5%＋1 A）

Resistance Measurement Frequency: ＞1KHz

Measured Current Frequency: 50Hz/60Hz

Setting Range of Resistance Alarm Critical Value: 1Ω-199Ω

Setting Range of Current Alarm Critical Value：1mA -499Ma

3. Specifications



 

 

 



 









 





   



 







°°



 

 

 

  

-4-

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

-5-

IV. Structure of Meter

1. Long Pincers Jaw : 65mmx32mm

2. Round Pincer Jaw : φ32mm

3. Trigger: to control opening and closing of jaw

4. HOLD Key: lock / Release display / Storage

5. ON/OFF Key: Boot Up / Shutdown /Quit /Clear Data

6. MEM Key: Data Access / Clear Data

7. AL Alarm Function Key: Alarm Open / Turn Off / Alarm Critical

Value Setting

8. Resistance Measure Switch Key Ω (Right Arrow Key)

9. Current Measure Switch Key A (Left Arrow Key)

10. Liquid Crystal Display (LCD)
