Beta Three ES306 Manuale utente

ED-B3-MA-060303-001

Beta Three

USER'S MANUAL

S306

FULL RANGE PROFESSIONALSPEAKER

70Hz-18KHz

93dB

3KHz

140 140

160W

NL4 1 , +1 -1

22kg

FULL RANGE PROFESSIONAL SPEAKER

26kg

Features

Specifications

Fequency Response(-3dB)

Sensitivity(1m/1W)

Crossover Frequency:

Dispersion(H V):

Rated Power(RMS):

Rated Impedance:

DC Impedance

THD

Input Connectors

Net Weight(2Pcs):

Gross Weight:

Dimensions (W D H):

Packaging Dimensions 2pcs/pack(W D H):

Three transducers two way full range

High SPL, high sensitivity speaker

Two 6" woofer with big power

One 1" compression driver with PEI diaphragm

Drived by single amplifier

140 140 wide dispersion can get the better covering

Computer anolog design bring better frequency response

and phase

Flexible and convenient installation mode

Used for full range sound reinforcement, language

reinforcement for meeting system, background music, bar,

dance hall and other public avenues

Suitable to be as monitor and sound compensation for any

big audio project and touring performance

Can work with 3 high energy subwoofer( B118D) when

used for high quality replaying music

Three transducers two way phase-reversed full range

professional speaker,professional and efficient

transducers, computer simulating design.

212 194 541mm

User s manual

8 Ohm

6.4 Ohm

631 541 303mm

FULL RANGE PROFESSIONAL SPEAKER

Installation drawing

M8 expanding bolt

Bracket

Rubber gasket

M8 screw

Wall

Speaker

Ground

Speaker

Ground

Speaker

expanding bolt

Bracket

M8 screw

Rubber gasket

Ceiling

212

541

194

User s manual

Cabinet Dimension

FULL RANGE PROFESSIONAL SPEAKER

RRUser sM anual

S306

Beta Three
