BIPAC 7100
ADSL VPN Firewall Router
with 4-port Switch
Securely share your high speed ADSL connection
•High-speed Internet Access with ADSL
•Ease of Use with Quick Start Setup
•IPSec/IKE Virtual Private Network
•Universal Plug and Play (UPnP) Compliant
•SOHO Firewall Security with DoS Prevention
•Parental Control with URL Blocking and Packet Filtering
•Dynamic Domain Name System (DDNS)
•Integrated with 4-port Ethernet Switch
•Web-based Configuration, Management and Firmware Upgrade
•Ideal for residential users
High-speed Internet Access with ADSL
The BIPAC 7100 complies with ADSL standards for worldwide deployment and supports downstream rate of
up to 8Mbps and upstream rate of up to 1Mbps. It is designed for small office, home office and residential
users, enabling high-speed Internet connections. User can enjoy ADSL services and broadband multimedia
applications such as interactive gaming, video streaming and real-time audio much easier and faster than ever
before.
Ease of Use with Quick Start Setup
The Quick Start setup allows easy installation of the BIPAC 7100 series. With this simple Quick Start setup,
end users can enter the necessary ISP information and start surfing the Internet immediately.
SOHO Firewall Security and Parental Control
Along with the built-in NAT natural firewall feature, the BIPAC 7100 also provide advanced hacker pattern-
filtering protection. It can automatically detect and block Denial of Service (DoS) attacks, such as IP Spoofing,
Ping of Death, Land Attack, etc. Powered by URL blocking and packet filtering, the BIPAC 7100 supports
parental control to Internet access according to web addresses, web address keywords or the time of a day.
It ensures your family or company a safe surfing environment.
Easy Network Management
The Web-based User Interface makes the BIPAC 7100 extremely easy to install and manage your network.
With built-in DHCP server, system administrators can easily attach this security router into existing networ
and manage the IP assignment without re-configuring the other stations. The built-in diagnostic test tool is
extremely useful to troubleshoot the problem if necessary.
Virtual Private Network (VPN)
The BIPAC 7100 supports embedded IPSec VPN protocol (IKE, 3DES and DES), for establishing a private
encrypted tunnel over the public Internet to ensure transmission security between two or more sites.
Powerline WLAN
ADSL Router and Adapter
Security ADSL Router VoIP ADSL Modem/Router
Broadband Router
SHDSL Bridge / Router
Wireless Client Wireless ADSL Router ADSL Modem / Router
Feature & Specification
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple Protocol over AAL5 (RFC 2684, formerly
RFC 1483)
•Bridged or routed Ethernet encapsulation
•VC and LLC based multiplexing
•PPP over Ethernet (PPPoE)
•PPP over ATM (RFC 2364)
•Classical IP over ATM (RFC 1577)
•OAM F4/F5
Firewall
• Built-in NAT firewall
•Prevent DoS attacks including IP Spoofing,
Land Attack, Ping of Death, TCP SYN Flooding, etc.
•E-mail alert whenever detect attacks
•Packet filtering based-on MAC
address, IP address and port number
•URL blocking – string or domain
name detection in URL string
Virtual Private Network (VPN)
•Embedded IPSec/IKE
•DES and 3DES encryption for IPSec
•L2TP/PPTP/IPSec pass-through
Management
• Ease of use with Quick Start setup
•Web-based GUI for remote and local management
•Firmware upgraded via Web-based GUI and
FTP/TFTP
•System & intrusion detection log
•SNMP MIB support
•Support DHCP server/client/relay
•Diagnostic test utility
Operating Environment
•Operating temperature: 0 ~ 40 ºC
•Storage temperature: -20 ~ 70ºC
•Humidity: 20 ~ 95% non-condensing
All the specifications are subject to changes without prior notice.
Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei Hsien, Taiwan
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731,+886-2-2918-2895
www.billion.com
ADSL Compliance
• Compliant with ADSL Standards
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
•Sync. Rate: up to 8 Mbps for download rate and
1Mbps for upload rate
Network Protocols and Features
• NAT, static routing and RIP-1/2
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS relay and IGMP proxy
Hardware Specification
Physical Interface
•WAN: ADSL port
•Factory default reset button
•LAN: 4-port 10/100M auto-crossover (MDI/MDI-X)
Switch
•Power jack
•Power switch
Physical Specification
•Dimensions: 7.32" x 5.04" x 1.81"
(186mm x 128mm x 46mm)
Power Requirement
•Input: 12V DC, 1A
