Blaupunkt LS 180 Manuale utente

LS 180

2.4GHz DIGITAL WIRELESS SOUNDBAR SYSTEM

LS 180

SAFETY INFORMATION

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL,

WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED

TO ALERT THE USER TO THE PRESENCE OF

UNINSULATED, "DANGEROUS VOLTAGE", WITH IN THE

PRODUCTS ENCLOSURE THAT MAY BE OF SUFFICIENT

MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC

SHOCK TO PERSONS.

THE EXCLAMATION POINT WITHIN AN EQUILATERAL

TRIANGLE IS INTENDED TO ALERT THE USER TO THE

PRESENCE OF IMPORTANT OPERATING AND MAINTE-

NANCE (SERVICING) INSTRUCTIONS IN THE LITERA-

TURE ACCOMPANYING THE APPLIANCE.

Safety Precautions

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK. DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CE Declaration of conformity

0179

Model number: LS 160

Trade name: Blaupunkt Competence Center Audio M3 Electronic GmbH

Responsible Party: M3 Electronic GmbH

Gutenbergstrasse 5,

D-65830 Kriftel,

Germany

Hereby, Blaupunkt Competence Center Audio M3 Electronic GmbH, declares

that this Class 1 equipment is in compliance with the essential requirement and

other relevant provisions of Directive 1999/5/EC. The declaration of confiormity

may be consulted at www.blaupunkt.com

Warning: This product can be used in all countries of the European Union and EFTA countries.

Letter of Conformity can be obtained from info@m3-electronic.de

LS 180

Caution: Please read carefully all the following important safeguards to en-

sure safe operation.

1. Read Instructions - All the safety and operating instructions should be

read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should be

retained for future reference.

3. Follow Instructions - All operating instructions should be followed.

4. Heed Warnings - All warnings on the appliance and in the operating

instructions should be adhered to.

5. Power Source - The appliance should be connected to a power supply

only of the type specified in the operating instructions or as marked on

the appliance.

6. Power-cord Protection - Power-supply cords should be routed so that

they are not likely to be walked on or pinched by items placed upon or

against them, pay particular attention to cords at plugs, convenience

receptacles, and the point where they exit from the appliance.

7. Water and Moisture - The appliance should not be used near water

(for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a

wet basement, or near a swimming pool, etc.)

8.Ventilation - The appliance should be situated so that its location or

position does not interfere with its proper ventilation. Do not use the

appliance on a bed, sofa, rug or similar surface that may block the

ventilation openings.

IMPORTANT SAFEGUARDS

LS 180

registers, stoves, or other appliances (including amplifiers) that produce heat.

10. Nonuse Periods - The power cord of the appliance should be unplugged

from the outlet when left unused for a long period of time.

11. Damage requiring service - The appliance should be serviced by qualified

service personnel when:

a/ The power-supply cord or the plug has been damaged; or

b/ Objects have fallen or liquid has been spilled into the appliance; or

c/ The appliance has been exposed to rain; or

d/ The appliance does not appear to operate normally or exhibits a marked

change in performance; or

e/ The appliance has been dropped, or the enclosure damaged.

12. Servicing - The user should not attempt to service the appliance beyond

that specified in the operating instructions. All other servicing should be

referred to qualified service personnel.

13. Clean only with dry cloth.

14. Do not defeat the safety purpose of the polarized or grounding type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug

does not fit into your outlet, consult and electrician for replacement of the

obsolete outlet.

15. Unplug this apparatus during lightning storms or when unused for

long periods of time.

9. Heat - Keep the appliance away from heat sources such as radiators, heat

LS 180

FRONT PANEL

1 2 3

1. : Power Standby STANDBY Button.

2.INPUT:Input Selection Button.

3.VOL-: Volume Downward Adjustment Button.

4.VOL+: Volume Upward Adjustment Button.

5. STANDBY:Subwoofer Standby Input Indicator.

LS 180

REAR PANEL

LS 180

1. AUX Stereo Audio Input.Right

2. AUX Stereo Audio Input.Left

4. TV Stereo Left Audio Input.

3. TV Stereo Right Audio Input.

6. AC Power Cord.( )SOUNDBAR

7. Power On/Off Switch.(SUBWOOFER)

8. AC Power Cord.(SUBWOOFER)

5. Power On/Off Switch.(SOUNDBAR )

REMOTE CONTROL

LS 180

1. : Power Standby.STANDBY

4.VOL-: Volume Downward Adjustment Button.

7.INPUT: Input Button . Selection

2.MUSIC: Music Mode .Selection

3.NORMAL: Normal Mode .Selection

5.BASS-: Bass Downward Adjustment Button.

6.TREBLE-: Treble Downward Adjustment Button.

9.RESET: Location Retrieval Button .

10.MOVIE: M ovie Mode .Selection

11.VOL+: Volume Upward Adjustment Button.

12.BASS-: Bass Upward Adjustment Button.

13.TREBLE-: Treble Upward Adjustment Button.

8.MUTE: Mute Function Button .

1.Replace the remote control battery when it no longer operates the

unit, or the range is reduced considerably.

2.Use only Cr2025 3V lithium batteries

3.Bear in mind that lighting & other room conditions, in addition to

battery age, can affect the operating range of an infrared remote control.

REMOTE CONTROL BATTERY REPLACEMENT

LS 180

SYSTEM CONNECTION

Video Out

Rear-R

Center

Woofer R ear -L Fr ont-L

Front-R

Video

RCA Cable

To Stereo Output

Audio Out

Video In

DVD Player

Opti cal

Audio Out

Rear -R

Cent er

Woof er Rear-L F ront-L

Coax ial Front -R

Video Out

Scart out

Vide o S-Video UVY

Manufactured under license from Dolby Laboratories.

"Doldy","Dolby Digital", and the double-D symbol are

trademarks of Dolby Laboratories. Confidential

Unpublished Works.

@1992-1997 Dolby Laboratories, Inc.

Apparatus Claims of U.S. Patent Nos.

4,631,603;4,577,216;4,819,098 and 4,907,093

licensed for limited viewing uses only.

RISK OF ELECTRIC SHOCK

DO NOT O PEN

WARN ING !

AC 100V~240V

50/60Hz

LS 180

OPERATION

A. Switch On/Off the Product

1. Before turning on the system, please connect it according to

the System Connection Instruction.

2. Connect AC power supply with this product.

(Caution: Power source must be consistent with this product.)

3. Press on the POWER switch button on the Rear Panel of the main

unit to switch on the system, the standby indicator will light up.

Then press the STANDBY button on the remote controller to enter

The normal status. Press the button on the remote controller once

again to keep power in standby status.

B. VOLUME Selection

1. Press the VOL+ on the front panel of the main u button nit

or VOL + button on the remote controller to maximize the

sound output.

2. Press the VOL- on the front panel of the main button unit

or VOL - button on the remote controller to minimize the

sound output.

C. MUTE Selection

1. Press the MUTE button on the remote controller once to

keep the performance silent.

Press the RESET button on the remote controller and it will reset

all settings including SW Speaker output, Surround Speaker output

to factory default settings.

D. RESET
