Boston Acoustics P400 Manuale utente

Performance that flatters

any flat panel.

P4 Series

High Performance Loudspeakers for Flat Panels

Your Sound Solution™

Boston Acoustics, Inc. 300 Jubilee Drive Peabody MA 01960 USA phone 978.538.5000 fax 978.538.5100 bostonacoustics.com JAL-0904-DP-V01

P4 Series

Specifications

Specifications P400 P460 P450 P442 P430

Recommended Amplifier Power 15-125 watts per channel 15-200 watts 15-150 watts 15-150 watts 15-125 watts

Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms

Frequency Response (±3dB) 80Hz-20kHz 80Hz-20kHz 80Hz-20kHz 80Hz-20kHz 80Hz-20kHz

Bass Unit 41⁄2″(115mm) (x3) Four 41⁄2″(115mm) Dual 41⁄2″(115mm) Dual 41⁄2″(115mm) 41⁄2″(115mm)

41⁄2″(115mm) passive (x3) 41⁄2″(115mm) passive

Midrange —41⁄2″(115mm) 41⁄2″(115mm) 41⁄2″(115mm) —

Tweeter 1″(25mm) VR®1″(25mm) VRH.O.™ 1″(25mm) VRH.O. 1″(25mm) VRH.O. 1″(25mm) VR

with AMD™ (x3) with AMD with AMD with AMD with AMD

Crossover Frequency 2800Hz 300, 2800Hz 500, 2800Hz 500, 2800Hz 2800Hz

Dimensions (H x W x D) 40 x 55⁄8x 315⁄16″34 x 55⁄8x 315⁄16″28 x 55⁄8x 315⁄16″24 x 55⁄8x 315⁄16″18 x 55⁄8x 315⁄16″

(without bracket)* (1016 x 142 x 100mm) (864 x 142 x 100mm) (711 x 142 x 100mm) (610 x 142 x 100mm) (457 x 142 x 100mm)

Sensitivity [1 watt (2.83v) at 1m] 90dB 92dB 92dB 92dB 90dB

Weight 14.6lbs (6.7kg) 14.8lbs (6.8kg) 12lbs (5.4kg) 11lbs (5kg) 6.4lbs (3kg)

*Depth with bracket 43⁄4″(121mm)

All P4 Series speakers feature Boston’s proprietary MagnaGuard®magnetic shielding to protect picture tubes.

P4 Series Floor and Table StandsBravo®II

Specifications BravoII

Recommended Amplifier Power 15-125 watts

Nominal Impedance 8 ohms

Frequency Response (±3dB) 80Hz–20kHz

Bass Unit 41⁄2″(115mm) Copolymer

Tweeter 1″(25mm) black anodized aluminum dome with AMD

Crossover Frequency 2500Hz

Dimensions (H x W x D) 141⁄4x 61⁄2x 51⁄4″

(362 x 166 x 134mm)

Weight 5lbs (2.25kg)

Finish White, black, or silver textured ABS with matching metal grille

• Hides wires for a

clean appearance

• Sturdy cast base

ensures stability

• Stylish and sleek

metal construction

P4TS Table Stand

Designed for

table placement

P4FL Floor Stand

Designed for

floor placement

are trademarks and Boston, Boston Acoustics, BostonAcoustics.com, the Boston logo, Bravo, MagnaGuard, and VR are registered trademarks of Boston Acoustics, Inc.

2792m P-Series 8 page bro 9/1/04 1:31 PM Page 1

Simple elegance.

And a sound that’s truly stunning.

Boston P4 Series is an exceptional combination

of sound and style that’s unlike anything any-

one has ever seen – or heard – before. Made to

ﬁt the clean look and high performance of

today’s flat panel TVs, this line of loudspeakers

produces phenomenal sound. At the same time,

P4 speakers flatter a variety of decors with a

simple style that looks great on walls, tabletops,

or floor stands. Whether you’re looking for a

basic surround sound system or a full-blown

theater at home, P4 speakers offer a stunning

sound solution.

And for those looking for the ultimate in

simple elegance, there’s the P400. It’s a left,

center, and right channel in one incredible

speaker. This sleek unit transforms your favorite

movies and shows by providing an incredibly

accurate and truly amazing soundstage.

The Boston Sound™

Listening to a Boston

system is an audio experience more like a

live concert than a recording. It is the sound

the artist intended. Pure, natural, true-to-the-

original performance™

. The Boston Sound.

It is the sound recognized for its smooth,

octave-to-octave tonal balance from the deepest

bass to the highest treble. It is the legendary

performance distinguished as much by what

it doesn’t do as by what it does; not favoring

one frequency over another, instead presenting

the mids, highs and lows in perfect balance.

It is greater detail across the entire sonic

spectrum with no artiﬁcially generated coloring

or distortion at high volume. And, it is the

same consistent voice you hear no matter which

Boston speakers you’re listening to, or where.

2792m P-Series 8 page bro 9/1/04 1:31 PM Page 3

The P400 is the ultimate in high performance

flat panel sound. This revolutionary speaker

is the ﬁrst to provide left, center, and right

channels in one simply stunning unit. With its

multiple 41⁄2-inch neodymium mid-bass drivers

and three patented one-inch VR®aluminum

dome tweeters, this loudspeaker provides the

detail and clarity to impress even the most

discerning listener.

Elegantly encased in a sleek cabinet that’s the

same depth as standard plasma or LCDTVs,

this speaker provides the entire front soundstage,

eliminating the need for three separate speakers.

It can be wall mounted above or below a flat

panel TV, and once mounted, it can be angled

up or down to envelop the listener in sound.

The P400 can also be set on top of a TV, placed

on a table or credenza, or used with an optional

table stand for a clean look that complements

any room. It’s versatility and elegance that puts

flat panel sound on a whole new level.

The P400: high-end elegance

in a single speaker.

2792m P-Series 8 page bro 9/1/04 1:32 PM Page 5

The very versatile style of P4 Series –

perfect for all kinds of flat panels.

The Boston P4 Series has everything you need

to bring sleek style and incredible sound to

your home. Designed to ﬁt today’s flat panel

TVs perfectly, these high-output speakers are

engineered to deliver a flawless music and

movie experience. At just over four inches, their

depth matches today’s plasma and LCD TVs.

But good looks are only part of the story.

The P4 Series is high performance that’s also

highly versatile. Exceptionally engineered drivers

housed in extruded aluminum enclosures give

these speakers an extraordinary sound and a level

of structural integrity that virtually eliminates

unwanted vibrations.

And they’re as easy to set up as they are

on the ears. All P4 Series speakers feature wall-

mount brackets. And, optional floor stands

make it easy to match the elegance of large-screen

TVs. These speakers can also be placed, either

horizontally or vertically, on available table

stands, which look great on credenzas. For a

complete surround sound experience, simply

add additional P4 Series speakers as side and

rear channels. Or, for even greater placement

flexibility, use Boston Bravo®II multipurpose

speakers. They mount inconspicuously into

corners, or flush on the wall, and have the same

styling as P4 speakers for a flawless look. High

performance home theater systems simply are

not complete without a subwoofer. Boston

subwoofers are designed to perfectly complement

our P4 Series. It all adds up to a system that

takes stunning flat panel sound and makes it

better than ever.

P400P460 P450 P442 P430

All P4 speakers

come with metal

grilles in both

black and silver

Wall brackets

are included with

all P4 speakers

The speakers can

be angled ± 15°

Bravo®II speakers,

with matching

metal grilles, sound

and look great with

P4 speakers

Optional

table and

floor stands

The P400 provides

3 channels of

sound from a

single speaker

There’s a P4

speaker model

to match any

size television

Extruded aluminum

cabinets provide

elegant styling and

structural integrity

The Boston logo

plate rotates

for both vertical

and horizontal

positioning

2792m P-Series 8 page bro 9/1/04 1:32 PM Page 7
