Braun 3105 Manuale utente
3105
InterFace Excel
3105
combi shave
foil shave
on/off
InterFace Excel
3105 NA cord KURTZ DESIGN 09.08.02
Type 5449
Modèle 5449
Modelo 5449
5449300_3105_NA_S1 Seite 1 Dienstag, 18. Oktober 2005 8:17 08
Thank you for purchasing a Braun product.
We hope you are completely satisfied with
your new Braun shaver.
If you have any questions, please call:
US residents 1-800-BRAUN-11
1-800-272-8611
Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun.
Nous espérons que vous serez pleinement
satisfaite de votre nouveau rasoir Braun.
Si vous avez des questions, veuillez appeler
Braun Canada : 1-800-387-6657
Gracias por haber comprado un producto
Braun.
Esperamos que Ud. quede completamente
satisfecha con su nueva afeitadora Braun.
Si Ud. tiene alguna duda,
en México, llame al: 01 (800) 508-5800
English 4
Français 10
Español 15
Internet
www.braun.com
5-449-300/00/X-05
USA/CDN/MEX
Printed in China
Imprimé en Chine
Impreso en China
5449300_3105_NA_S2 Seite 1 Dienstag, 18. Oktober 2005 8:19 08
7
1
3710
combi shave
foil shave
on/off
2a
2
3
4
fe
g
ab
5
oil
6
d
c
foil
on/off
No. 3600
3
5449300_3105_NA_S3 Seite 1 Dienstag, 18. Oktober 2005 8:23 08
4
English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should always
be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for an appliance that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in a shower when the appliance is
connected to an electrical outlet.
3. Do not place, store or charge the appliance where it can fall or be
pulled into a tub or sink. Do not place in or drop into water or other
liquid.
4. When not using for a longer period of time, unplug this appliance
from the electrical outlet.
5. Unplug this appliance before cleaning.
6. This appliance is provided with a special cord set with integrated
Safety Extra Low Voltage power supply. Do not exchange or
manipulate any part of it.
FOR HOUSEHOLD USE
SAVE THESE INSTRUCTIONS
5449300_3105_NA Seite 4 Dienstag, 18. Oktober 2005 8:54 08
5
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by,
on, or near children or invalids.
2. Use this appliance only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
3. The appliance should never be exposed to temperatures of less
than 32 ºF / 0 ºC and more than 105 ºF/+40ºC for longer than a
few hours. Be sure to completely dry appliance after use.
Keep cord and adapter dry at all times. Do not store in a damp
environment. To avoid damage do not wind the cord around the
appliance. It is important to check the cord for damage
periodically particularly at each end where the cord enters the
plug.
4. Never operate this appliance if it has a damaged cord or plug, if it
is not working properly, if it has been dropped or damaged, or
dropped into water. Return the appliance to a service center for
examination and repair.
5. Keep the cord away from heated surfaces.
6. Never drop or insert any object into any opening.
7. Do not use outdoors or operate where aerosol (spray) products
are being used or where oxygen is being administered.
8. Do not use this appliance with a damaged or broken foil,
as serious facial injuries may occur.
9. Always attach plug to appliance first, then to outlet.
To disconnect, turn all controls to «off», then remove plug from
outlet.
5449300_3105_NA Seite 5 Dienstag, 18. Oktober 2005 8:54 08
6
1 Description
1 Foil protection cap
2 Shaver foil
2a InterFace trimmer
3 Cutter block
4 Release buttons
5 Pop-out long hair trimmer
6 Switch
7 Shaver Socket
Technical specifications
• Wattage: 3 W
• Voltage range: 100–240 V ~ / 50 or 60 Hz
(automatic adaptation)
2 Shaving
Switch positions
off
foil shave = Shaver foil only (for difficult to reach areas, e.g. under
the nose).
combi shave = Combination shave (InterFace trimmer works in tandem
with the shaver foil to first cut the longer problem hairs,
which then allows the foil to shave the shorter hairs even
closer) (b).
trimmer = The long hair trimmer is activated (for trimming
sideburns, moustache and beard) (c).
Tips for the perfect shave
• It can take up to 14-21 days for your beard to adjust to the new
shaving system.
• Shave before washing your face or taking a shower, as skin tends to
swell after washing.
• The drier the skin, the closer the shaving results will be.
• Hold the shaver at right angles (90°) to the skin. Stretch your skin and
shave against the direction of beard growth.
• To maintain 100% shaving performance replace your foil and
cutterblock every 18 month or when worn.
5449300_3105_NA Seite 6 Dienstag, 18. Oktober 2005 8:54 08
7
3 Keeping your shaver in top shape
3.1 Cleaning
• After shaving, switch the shaver off. Press the release buttons, take off
the shaver foil (d) and gently tap it out on a flat surface (e).
• Then thoroughly clean the cutter block with the brush (f).
• Do not clean the shaver foil with the brush.
• If you have a very dry skin and you notice a reduced operation time of
the shaver, you should put a drop of light machine oil onto the InterFace
trimmer and shaver foil (g).
3.2 Replacing the shaving parts
• To maintain 100% shaving performance, replace your foil and cutter
block every 18 months or when worn. Change both parts at the same
time for a closer shave with less skin irritation.
(Shaver foil and cutter block: part no. 3600)
• Press the release buttons, take off the shaver foil. Replace the new
shaver foil in the right direction until it locks in place.
• To remove the cutter block, lift it off (g).
• To replace the cutter block, snap onto the holding studs.
Subject to change without notice.
5449300_3105_NA Seite 7 Dienstag, 18. Oktober 2005 8:54 08
8
FOR USA ONLY
2 year limited warranty (foil and cutter block excluded)
Braun warrants this Braun shaver (except foil and cutter block) to be
free of defects in material and workmanship for a period of two years
from the date of original purchase.
If the shaver exhibits such a defect, Braun will, at its option, either
repair or replace it for the consumer without charge.
Please call 1-800-Braun 11 (800-272-8611) to be referred to the
authorized Braun Service Center closest to you.
This warranty does not cover foils, cutter blocks or damage resulting
from accident, misuse, abuse, dirt, water, tampering, unreasonable
use, normal wear, servicing performed or attempted by unauthorized
service agencies or failure to provide reasonable and necessary
maintenance, including recharging.
ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO 2 YEARS
FROM DATE OF ORIGINAL PURCHASE.
IN NO EVENT WILL BRAUN BE RESPONSIBLE FOR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not
apply to you.
This warranty gives you specific legal rights, and you may also have
other legal rights which vary from state to state.
5449300_3105_NA Seite 8 Dienstag, 18. Oktober 2005 8:54 08
9
FOR CANADA ONLY
2 year limited warranty (foil and cutter block excluded)
In the event a Braun Shaver fails to function within 2 years from date
of purchase, because of defects in material or workmanship, and the
consumer returns the unit to an authorized service center, Braun
Canada, will, at its option, either repair or replace the unit without
additional charge to the consumer.
This guarantee does not cover any product, which has been
damaged by dropping, tampering, wrong current, servicing
performed or attempted by unauthorized service agencies, misuse or
abuse, kinks in the shaver foil as well as the normal wear of the
shearing parts.
Exclusion of Warranties: The foregoing warranty is the sole
warranty offered by Braun Canada. Braun Canada hereby disclaims
any implied warranty or merchantability or fitness for any particular
purpose. In no event will Braun Canada be responsible for
consequential damages resulting from the use of this product.
5449300_3105_NA Seite 9 Dienstag, 18. Oktober 2005 8:54 08
10
Français
PRÉCAUTIONS IMPORTANTES
Lors de l’utilisation d’appareils électriques, toujours prendre
les mesures de précaution suivantes :
Lire toutes les directives avant d’utiliser cet appareil.
DANGER
Pour réduire les risques de choc électrique, suivre les directives
suivantes :
1. Ne pas toucher l’appareil s’il est entré en contact avec de l’eau.
Le débrancher immédiatement.
2. Ne pas utiliser pendant le bain ou la douche lorsque l’appareil est
branché sur une prise de courant.
3. Ne pas placer ni ranger ni recharger l’appareil à un endroit d’où il
peut tomber ou glisser dans une baignoire ou un lavabo. Ne pas
immerger dans l’eau ni aucun autre liquide.
4. Débrancher l’appareil de la prise de courant s’il n’est pas utilisé
pendant une période prolongée.
5. Débrancher l’appareil avant le nettoyage.
6. Cet appareil comprend un cordon spécial muni d’un dispositif de
sécurité intégré assurant une alimentation très basse tension. Par
conséquent, il faut éviter d’échanger ou de manipuler les pièces.
POUR USAGE DOMESTIQUE
CONSERVER CES DIRECTIVES
5449300_3105_NA Seite 10 Dienstag, 18. Oktober 2005 8:54 08
