Braven 105 Manuale utente

QUICK START GUIDE

10 5

2Full manual and troubleshooting: braven.com/manuals

ENGLISH

+ VOLUME UP / SKIP

TRACK (press and hold)

O PAIRING / ANSWER-

END CALL / PAUSE-

RESUME MUSIC

SILICONE FLAP

PULLS BACK

- VOLUME DOWN / SKIP

BACK (press and hold)

BRAVEN CHARGING

PORT

BATTERY / PAIRING

INDICATOR LIGHT

-Full battery = light off

-Red LED ashes 1x every

second at ≤10%

-LED remains solid red when

charging, then turns off

RESET BUTTON

STRAP

3.5 MM AUDIO-IN JACK

¼-20 THREADED

MOUNTING INSERT

GET TO KNOW YOUR BRAVEN

ENG

ENGLISH

TURN ON & BLUETOOTH®AUTO-PAIRING

1. Long press on “O” button powers on 105

and automatically begins pairing mode.

LED behind grill will blink rapidly.

2. Activate Bluetooth®on the phone or

device you are pairing with (see your

device’s instruction manual for information

on activating its Bluetooth®settings).

3. Go to your phone or device’s Bluetooth®

settings and select “BRAVEN 105” from

the list.

4. If asked for a passcode, enter “0000”

5. You will hear a single beep when

BRAVEN 105 is paired with your device.

NOTE: Braven 105 only remembers 1

device.

NOTE: If your BRAVEN does not have

an active Bluetooth®connection and

is left on, it will shut itself off after 30

minutes. To restart your BRAVEN you

will need to press and hold the power

button for 2-3 seconds.

4Full manual and troubleshooting: braven.com/manuals

ENGLISH

NEW DEVICE PAIRING

SPEAKERPHONE

1. If you’d like to pair BRAVEN 105 to a new

device, long press “O” to turn off speaker.

Once speaker is off, long press “O” until

you hear the speaker power on and hear

the pairing sound.

2. Activate Bluetooth®on the phone or

device you are pairing with (see your

device’s instruction manual for information

on activating its Bluetooth®settings).

NOTE: Speaker can ONLY go into paring mode

or be put into pairing mode when the speaker is

rst turned on. • Press the “O” button to answer a call

over the speaker. Press the “O” button

again to end the call.

3. Go to your phone or device’s Bluetooth®

settings and select “BRAVEN 105” from

the list.

4. If asked for a passcode, enter “0000”

5. You will hear a single beep when

BRAVEN 105 is paired with you device.

ENG

ENGLISH

CHARGING YOUR BRAVEN WATERPROOF FEATURES

• Before using your BRAVEN for the

rst time, charge the unit until the LED

battery indicator light behind the grill

turns off.

• To charge your BRAVEN, plug

the included USB-to-Micro- USB

cable into a wall power adapter (not

included) or into a powered USB port

on a computer. Plug the Micro-USB

connector end of the cable into the

BRAVEN charging port.

• The BRAVEN 105 is IPX7 waterproof,

and is designed to withstand rainfall,

waterjets, water splashing, and dunk in

the pool.

• IMPORTANT To ensure your BRAVEN

105 speaker is prepared for use in

a wet environment, remove all cable

connections and tightly close the

silicone ap which guards the charging

port and AUX input on the back of

the speaker. If this ap is not securely

fastened to the speaker, BRAVEN 105

will not be waterproof.

6Full manual and troubleshooting: braven.com/manuals

ENGLISH

ATTACHING AND MOUNTING YOUR BRAVEN

• Integrated strap allows you to attach

your BRAVEN 105 to a backpack, or bar.

• Included Action Mount allows you to

attach BRAVEN 105 to most GoPro*

mounting systems.

ENG

ENGLISH

• ¼-20 threaded mounting insert is

compatible with tripods, and other

mounts with ¼-20 posts.

• Use included desk stand at the ofce,

dorm, or next to the kitchen sink.

*GoPro is a registered trademark or registered trademark of GoPro, Inc.

8Full manual and troubleshooting: braven.com/manuals

ENGLISH

REMOVING 105 FROM STAND

1. Locate pin 2. Remove pin 3. Separate from stand

Note: Store stand

in safe place

ENG

ENGLISH

REMOVING ACTION MOUNT FROM 105

1. Slide out

strap end and

thread through

action mount

2. Slide out

action mount

3. Store action

mount safely

4. Slide in

strap end

5. Enjoy!

10 Full manual and troubleshooting: braven.com/manuals

ENGLISH

ATTACHING 105/ACTION MOUNT TO STAND

1. Select preferred

angle

2. Line action

mount with stand

3. Insert pin to

secure to stand

4. Rock out!
