BREIL 1S13 Manuale utente
7
(0) (1) (2)
421
3
(C)
When reading this instruction booklet, keep the watch diagram on the left unfolded
and in full view. The symbols (A, B, etc.) on the diagram are those referred to in the
section describing the operating instructions.
Pendant la lecture de ce mode d’emploi, gardez le schéma d’illustration de la montre
ci-contre ouvert et bien en vue. Les symboles (A, B, etc.) utilisés dans les différents
chapitres du mode d’emploi correspondent à ceux indiqués sur ce schéma.
Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend gezeigte
Übersichtsdarstellung der Uhr ausklappen und im Blick behalten. Die in den
einzelnen Abschnitten der Gebrauchsanleitung verwendeten Zeichen (A, B, usw.)
entsprechen den Kennzeichnungen in dieser Übersicht.
Durante la lettura di questo manuale di istruzioni, tenere lo schema illustrativo
dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.) usati nelle sezioni delle
istruzioni sul funzionamento corrispondono a quelli indicati in questo schema.
Mientras lee este manual de instrucciones, mantenga el esquema ilustrativo del
reloj aquí presentado al lado izquierdo, abierto y bien visible. Los símbolos (A, B,
etc.) utilizados en las secciones de instrucciones sobre el funcionamiento,
corresponden a los que se utilizan en este esquema.
Durante a leitura deste manual de instruções, mantenha o esquema ilustrativo do
relógio aberto e à vista do lado esquerdo. Os símbolos (A, B, etc.) usados nas secções
das instruções de funcionamento, correspondem aos indicados neste esquema.
CONTENTS
A
B
C
D
MAIN COMPONENTS
SETTING THE TIME
SETTING THE DATE
PRECAUTIONS AND USEFUL INFORMATION
GUARANTEE TERMS AND CONDITIONS
3
3
3
4
39
ENGLISH
2
If your watch has a locking screw-type crown, first unscrew the crown.
1.
2.
3.
MAIN COMPONENTS
Hour hand
Minute hand
Second hand
(some models only)
A
1
2
SETTING THE
Stop the second hand at “0” by pulling out the crown (C) to position (1)
(position (2) if the model has a date display).
Tu rn the crown to adjust the hands to the correct time.
Restart the watch by pushing the crown (C) back to position (0).
B
SETTING THE DATE (some models only)
Pull out the crown (C) to position (1)
Rotate the crown until the required date appears.
Put the crown (C) back to position (0)
C
1.
2.
3.
3
3
Date
(some models only)
Crown
6
(C)
The words “WATER RESISTANT” may sometimes be abbreviated to “WATER RESIST”.
WATER RESISTANT
50M (5bar)
WATER RESISTANT
B
—
A—
—
Indication
Dial Case
Spray, sweat,
light rain,
washing, etc.
Swimming,
etc.
Use in
NO
YES
NO
NO
PRECAUTIONS AND USEFUL INFORMATION
D
In order to prevent water coming into contact with the internal mechanism, never pull
the crown out when the watch is wet.
If any watches designed for sportswear or use in water come into contact with salt
water or heavy sweating, they should be rinsed in fresh water and dried thoroughly.
Contact with water may cause a deterioration in the quality of some leather straps.
–
–
–
CWATER RESISTANT YES YES
DWATER RESISTANT
100M (10bar) WATER RESISTANT YES YES
E
WATER RESISTANT
200M (20bar) or more
WATER RESISTANT YES YES
Degree of water
resistance
4
*Always keep the crown in its normal position. *Fully tighten crown screw
Skin-diving Scuba diving
Water
Water-resistance
characteristics
NO
NO
NO
NO
Not water resistant. Must be kept away from water and moisture
Average water resistance. Can withstand spray, sweat,
light rain, washing, etc. during daily use
Suitable for skin-diving
As the internal parts of the watch can retain moisture, when the outside
temperature is lower than the inside, the watch glass may mist-up. This
phenomenon is purely temporary and should not create any problems. However,
if it persists for any length of time, the watch should be checked by the shop
where it was purchased or by the nearest Authorised Service Centre.
–
NO NO Can be worn while swimming but not diving
YES NO
Suitable for scuba diving
YES YES
5
6
Impact
This watch can withstand normal everyday impacts and shocks and those normally
imparted by non-contact sports such as golf and baseball. Serious damage, however,
may result if the watch is dropped or subjected to severe shock.
Magnetic fields
This watch is antimagnetic up to 60 gauss, and is therefore not affected by magnetic
fields produced by normal domestic appliances. If used near strong magnetic fields, its
operation may be temporarily affected.
Chemicals and gases
Avoid wearing the watch in the presence of strong gases or chemical substances.
Parts of the watch may discolour, dissolve or even break if brought into contact with
benzol or petroleum based products such as solvents, thinners, detergents,
adhesives etc.
Pay special attention to avoiding contact with chemicals.
The watch case and strap may discolour if they come into contact with mercury from a
broken thermometer or other equipment.
Keeping the watch clean
Use an absorbent soft cloth to clean off any dirt or damp from the watch glass.
Wearing the watch when the strap or back of the case is dirty can cause skin irritation.
Keeping the watch clean also keeps shirt cuffs clean.
7
Cleaning the watch strap.
•
•
•
Periodic inspection
In order to guarantee long trouble-free operation, it is advisable to have the watch
checked by an authorised assistance centre once every 12 months or two years.
If your watch is fitted with a quartz movement
Temperature
Do not leave the watch exposed to direct sunlight or temperature extremes for long
periods of time.
Long exposure, in fact, may adversely affect the operation of the watch and actually
shorten battery life, causing it to gain or lose time and affect its other functions.
Static electricity
The integrated circuits present inside the watch are sensitive to static electricity. If the
watch is exposed to intense electrical fields, the time display may temporarily lose
some of its accuracy.
Keep batteries out of the reach of children
In order to improve the product, the technical specifications may be modified without
prior notice.
Metal bands: use a toothbrush and soapy warm water to wash the dirt off.
Plastic or rubber straps: wash with water. Do not use solvents.
Leather straps: gently rub the face of the strap using a soft dry cloth. Clean the
opposite side with a cloth and alcohol.
INDEX
A
B
C
D
PIECES PRINCIPALES
COMMENT REGLER L’HEURE
COMMENT REGLER LA DATE
PRECAUTIONS D’UTILISATION ET INFORMATIONS UTILES
CONDITIONS DE VALIDITÉ DE LA GARANTIE
9
9
9
10
41
8
FRANÇAIS
