Brickcom FB-130Np Series Manuale utente

N-Series Superior Night Vision

1.3 Megapixel Fixed Box Network Camera

▪N-Series Sony Exmor 1.3M Indoor Fixed Box Camera

▪Brickcom WDR Enhancement ®technology inside

▪HDTV Quality (720p @ 30fps)

▪Intelligent Multi-Profile Sensor Management®for Different Environments

▪Best for Car-Plate Recognition

▪Removable IR-cut Filter /Auto Light Sensor for Day and Night

▪Two-wayAudio/Built-in SD/SDHC Memory Card Slot for Local Storage

▪1 DI/DO for External Alarm and Sensor Device

▪IEEE 802.11 a/b/g/n Compliance Wireless Connectivity (*)

▪WPS Function Support for Easy Wireless Network Setup (*)

▪Power over Ethernet

Status LED

Power Connector (AC24V In)

Power Connector (DC12V In)

Light Sensor

WPS LED (*)

SD/SDHC Card Slot

Reset Button

Build-in Microphone

Microphone/Line In

Ethernet RJ45 10/100 Socket

(Link/Power LED embedded)

DetachableAntenna

WPS Button (*)

Extension I/O Terminal Block

Audio Out

Auto Iris Connector

Photo Indication & Dimension Diagram

FB-130Np

WDR Enhancement®

POE

FB-130N Series

Hardware System

CPU: 500 MHz

Flash: 16M

RAM: 128M DDR

Image Sensor

Sensor Type : 1/3” Sony CMOS Sensor

Sensor Resolution : 1280 x 1024 pixel

Minimum Illumination : 0.1 Lux (F1.3,B/W)

0.5 Lux(F1.3,Color)

Day & Night

Support

Mechanical ICR , Triggered by Light sensor,

Scheduling, Digital Input

Communication

Ethernet : one 10/100Mbps RJ-45

IEEE 802.11a/b/g/n compliance (WFB-130N)

Supported Protocols : TCP/IP, UDP, ICMP,

DHCP, NTP, DNS,

DDNS, SMTP, FTP, HTTP, Samba, PPPoE,

UPnP, RTP, RTSP,

RTCP, Wireless 802.11 a/b/g/n (WFB-130N)

Power input

AC 24V

DC 12V / 1A (Power Supply)

PoE:802.3af Compliant

LEDs

FB-130N

Status/Ethernet(Power/Link)

WFB-130N

Status/WPS/Ethernet(Power/Link)

Power

consumption

5 watts

Environment

Operating Temperature : 0°C ~ 50°C (32°F

~122°F)

Operating Humidity : 10% ~ 80%

Dimension

124(L)*60 (W)*65(H) mm

Weight

FB-130N

Net: 380g (Without Lens)/0.83lb

Gross : 893G/1.97lb

WFB-130N

Net: 385g (Without Lens)/0.85lb

Gross: 903G/2.00lb

Certification

FCC, CE

Warranty

Limited 2-year warranty

Audio Streaming

2-way audio support

Audio

Compression

G.711, AMR (8 kHz, Mono, PCM)

Audio

Input/ Output

External microphone or line input (Unbalanced,

1.4 Vp-p, 1 Vrms)/Line Output

Video Image

Compression

H.264 / MPEG4 / MJPEG

Video Setting

Auto Exposure Control:

Sport, Normal, Night Vision, User Defined

Auto Gain Control: 1X~5X

Shutter Speed: 1/32000~1s

S/N Ratio

Above 50dB

Image Resolution

1.3M

- 1280x1024@25fps

-1280x720@30fps

M13VG288IR

2.2x Manual zoom/focus, DC iris

YV2.1x2.8SR4A-SA2L

2.1x Vari-focal Lens with DC Iris

CI-803C

Camera Bracket

FB-130N Series

FB-130Np

WFB-130Np

Wireless (11a/b/g/n dual band WiFi)



Auto Iris Support



WPS Button



DWRT-600N

Dual Band Wireless Router

PS-7242IL-AF

24-port 10/ 100M PoE Web Smart Ethernet

Switch

Camera

Video

Audio

General

Network Equipment Options

Camera Accessories Options

names and products are trademarks or registered trademarks of their respective

companies. We reserve the right to introduce modifications without notice.

Work Best With
