Briggs & Stratton 30324 Guida all'installazione

Model / Modèle / Modelo

030324

Questions? Help is just a moment away!

Vous avez des questions? Vous n'avez pas besoin

d'aller loin pour trouver de l'aide!

Preguntas? La ayuda es justa un momento lejos!

Call: Generator Helpline

Appelez: Ligne d'assistance de Générateur

Llame: Línea Directa del Generador

1-800-743-4115 M-F 8-5 CT

BRIGGSandSTRATTON.COM

Illustrated Parts List

BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC

JEFFERSON, WISCONSIN, U.S.A.

Manual No. 199718A Revision C (03/19/2007)

EXPLODED VIEWS AND PARTS LISTS

EXPLODED VIEW - MAIN UNIT

reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power

Products Group, LLC.

EXPLODED VIEWS AND PARTS LISTS

EXPLODED VIEW - PARTS LIST

Item Part # Description

1 J197129GS KIT, Frame

2 194150GS KIT, Vibration Mount 45°

3 * WASHER, M8 Lock

4 190220GS HOUSING, Engine Adapter

5 * NUT, Hex M8 - 1.25

6 NSP ASSY., Alternator (see page 5)

7 * TPHMS, M8 - 1.25 x 35

8 96796GS WASHER, M8 Flat

9 67989GS NUT, M8 Flange Serrated

10 190274BGS SBHCS, 3/8-16 x 1.0 Lg

11 47480GS HHCS, 5/16-24 x 7

12 * HHCS, M8 1.25 x 25

14 189009GS BRACKET, Muffler

15 695398 GASKET, Exhaust

16 * HCS, M6 1.0 x 12

17 189008GS MUFFLER

18 * SHCS, 5/16 - 18 x 7/8"

19 83083GS SCREEN, Spark Arrest

20 B4986GS DECAL, Ground, Green

21 194153GS KIT, Vibration Mount

22 86494GS SCREW, Wing, M6 1 x 16

23 195094GS SCREW, 10-16 x .68, Self Drill

24 192793GS SHIELD, Heat

25 191190GS CAP

26 74908GS SCREW, M5-0.8 x 10 Taptite

28 * WASHER, Flat 1/2

29 94929GS SCREW, Hex Wash HD

30 226846 BRACKET, Oil Fill Tube

31 196830GS DECAL, Hot Muffler

34 195422GS COVER, RBC, Plastic w/Cap

35 199838GS KIT, Fuel Hose w/clamps (cut to fit)

37 192376GS SCREW, 12 - 24 x 1/2 THD Forming

40 192310GS KIT, Vibe Mount

41 192980GS KIT, Valve Tank

Item Part # Description

44 196181GS ASSY., Tank, Fuel, 5 Gallon (includes

items 41, 50, 51 & 52)

45 189420GS CAP, Fuel Gauge

48 195373GS WIRE, Ground

49 203650GS KIT, Wheel

50 188333GS DECAL, Fuel Tank

51 194799GS DECAL, Danger

52 189235GS DECAL, Start Instructions

53 192050GS E-RING

55 197798GS DECAL, Shut-Off, Fuel

56 J194907GS HANDLE

57 189456GS KIT, Handle Fastening

58 197641GS ASSY, Control Panel

59 * NUT, Palnut 3/16"

60 189117GS QUICK CONNECT, Fuel, 1/4 Barb

61 192695GS QUICK CONNECT, Fuel, 1/4 Barb

62 201079GS DECAL, CO Warning

63 189114GS KNOB, Fuel Tank Hold Down

72 192480GS DECAL, Warning, Fuel Line

Disconnect

900 § ENGINE

Parts Not Illustrated

BB3061GS OIL BOTTLE

197474GS CORDSET, Storm

MS3430 MANUAL, Engine

199718GS MANUAL, Operator’s

202180GS DECAL, Family, CA EVP

186208GS STABILIZER, 1oz Tube

197581GS TRAY, Overflow, Fuel

198419GS KIT, Decals Srv

* - Items without part numbers are common fasteners and

are available at your local hardware store.

§ - Contact Engine Manufacturer

EXPLODED VIEWS AND PARTS LISTS

EXPLODED VIEW AND PARTS LIST - CONTROL PANEL

Item Part # Description

1 197471GS PANEL, Control

2 197472GS COVER, Outlet Flip

3 188890GS COVER, Back Panel

4 197731GS OUTLET, 120V, 15/20A Dplx

5 189165GS NUT, 5/32 Pal

6 197729GS MODULE, Led

7 197958GS SCREW, 3 x 6, Tapping

8 202030GS BREAKER, Circuit, 20A

191481GS BOOT, Breaker Circuit (not shown)

9 43437GS OUTLET, 120/240V, 30A

10 22694GS HOUSING, Rcptcl, 6 Pin

11 82308GS SCREW, 3 x 18, Tapping

12 192241GS SCREW, 3.5 x 14, Tapping

EXPLODED VIEWS AND PARTS LISTS

EXPLODED VIEW AND PARTS LIST - ALTERNATOR

Item Part # Description

1 186059GS ADAPTER, Mounting, Alternator

2 191043GS ASSY, Rotor (Includes Item 12)

3 191042AGS STATOR

4 186060GS RBC, with O-Ring (p/n 189197GS)

5 86308CGS HHCS, M6 - 1.0 x 130 SEMS

6 91825GS ASSY, Holder, Rectifier/Brush

7 66849GS TAPTITE, M5 - 0.8 x 16

8 22694GS RECEPTACLE, 6 pin

9 81917GS PIN, Roll, 4mm x 10

10 193428AGS ASSY, Wire, Ground

11 194274GS HARNESS, Wire, Power

12 65791GS BEARING
