B-NIMBLE™ Stroller
User Guide
IMPORTANT: To ensure your child is as safe as possible, read all
instructions thoroughly before using this stroller. Store this manual for
future reference.
©2010 Britax Child Safety, Inc. All rights reserved. Printed in USA P399700_R3:08.10
This product and its components are subject to change without notice.
Warnings..2
Features..4
In.the.Box.5
Assembly..6
Operating.Instructions
Parking Brake 10
Leg Rest Adjustment 10
Recline Adjustment 11
Swivel Wheels 11
Folding the Stroller 12
Securing.Your.Child.14
Infant.Carrier.Mode
Attaching Britax Infant Car Seat Adapters 16
Removing Britax Infant Car Seat Adapters 16
Attaching the Infant Car Seat 17
Removing the Infant Car Seat 17
Rain.Cover.18
Care.and.Maintenance.19
Warranty.20
Table of Contents
2
Section Title
WARNING!
DEATH or SERIOUS INJURY can occur:
•
Never leave child unattended.
•
Avoid serious injury from falling or sliding out. Always use harness to
secure child.
•
Do not use stroller for an infant younger than 6 months without an
infant carrier.
•
Do not use stroller with a child who weighs more than 55 lbs (24.9
kg).
•
Do not use stroller with a child taller than 44 inches (111.8 cm).
•
Do not overload basket – Maximum weight in basket is 10 lbs (4.5
kg). Overloading the basket may cause the stroller to become
unstable.
• Do not overload the storage pouch - Maximum weight in storage
pouch is 1 lb (0.45 kg).
• Do not overload the cup holder - Maximum weight in cup holder is
1 lb (0.45 kg).
•
Always make certain that the stroller is fully open and locked before
use.
•
Assembly of this stroller must be performed only by an adult.
•
Do not hang or place items on the stroller handle or frame. They may
cause the stroller to become unstable.
•
Children must always be restrained to prevent standing or falling out
of stroller.
•
Only use Britax approved child restraints or carriers with this
stroller.
•
Do not allow children to climb on or play with the stroller.
•
Never use stroller on stairs or escalators.
3
Section Title
WARNING!
DEATH or SERIOUS INJURY can occur:
•
To avoid entrapment or pinching, do not fold or unfold when child is
in or near stroller.
•
Stroller is intended for walking speed only. Do not use while jogging,
skating, etc.
•
Always set the parking brake when stroller is not moving.
•
Only use accessories and replacement parts approved by Britax
Child Safety, Inc.
•
Read and understand these instructions before using this product.
To ensure proper use, store this user guide in a convenient place
so it can be consulted often. Failure to follow all warnings and
instructions could result in serious injury or death.
Infant.Car.Seat.Mode
•
The infant car seat adapters are ONLY compatible with Britax infant
car seat and ONLY models from 2009 or newer
•
Attempting to fit them into another infant car seat can damage the
car seat or cause the car seat to fall
•
Infant car seats MUST only be installed rear facing, or toward the
parent. Installing the car seat forward facing can cause the stroller to
become unstable.
4• Actual product may vary from images.
Canopy.with.Sun.Visor
Chassis.
Lock
On.right.side.
of.frame
Harness
Buckle
Leg.Rest
Front.Wheels
Rear.
Wheels
Frame.
Release.
Lever
Infant.
Car.Seat.
Adapter
Handles
Carry.
Strap
Frame.
Release.
Lever
Under-Seat.
Storage.
Basket
Swivel.
Wheel.
Locks
Features
5
B-NIMBLE.
Stroller
Canopy.with.
Sun.Visor
Front.Wheels
Rain.Cover
Cup.Holder
Infant.Car.Seat.
Receivers
Britax.Infant.Car.
Seat.Adapters
L R
In the Box
6
• Lift the chassis lock and pull
the frame apart
• Lift up on the handles and
pull them away from each
other
• Step down on the primary
frame lock pedal to lock the
stroller chassis
IMPORTANT: Ensure that the stroller
frame is locked before placing a child
in the seat
Unfolding the Stroller
WARNING: To avoid entrapment
or pinching, do not fold or unfold
when child is in or near stroller
Assembly
7
Front Wheels
Canopy
• Locate the right and left
wheels and ensure that the
swivel lock lever is locked
into place as shown before
placing wheels on stroller
• Press the wheel assembly
onto the mount at the front
of the stroller
NOTE: Pull down on wheel assembly
to ensure that it is locked
• Line up the
canopy mounts
with the brackets
on the frame and
slide them down
until they lock
into place
L
L
R
R
Assembly
8
Infant Car Seat
Receivers
• Place the infant car seat
receiver behind the stroller
frame and between the two
brackets as shown
TIP: The receiver should be pointing
upward, and the raised lines (Fig. A)
should be on the inside
• Slide the tab on the cup
holder into the slot in the
cup holder bracket
• Slide and hold the top
bracket up while closing the
receiver around the frame
and snapping it together
Cup Holder
NOTE: There is a left and right
receiver
Install as shown to ensure infant car
seat allignment
A
Assembly
